Vehicles Power Supply Copper Core PCB Electric Car Charging Station Power Control
Vehicles Power Supply Copper Core PCB Electric Car Charging Station Power Control
Vehicles Power Supply Copper Core PCB Electric Car Charging Station Power Control
Vehicles Power Supply Copper Core PCB Electric Car Charging Station Power Control
Vehicles Power Supply Copper Core PCB Electric Car Charging Station Power Control
Vehicles Power Supply Copper Core PCB Electric Car Charging Station Power Control
Vehicles Power Supply Copper Core PCB Electric Car Charging Station Power Control
Vehicles Power Supply Copper Core PCB Electric Car Charging Station Power Control
Vehicles Power Supply Copper Core PCB Electric Car Charging Station Power Control
Vehicles Power Supply Copper Core PCB Electric Car Charging Station Power Control
Vehicles Power Supply Copper Core PCB Electric Car Charging Station Power Control
Vehicles Power Supply Copper Core PCB Electric Car Charging Station Power Control
Vehicles Power Supply Copper Core PCB Electric Car Charging Station Power Control
Vehicles Power Supply Copper Core PCB Electric Car Charging Station Power Control
Specifications
Brand Name :
FR4 With copper
Model Number :
new energy pcb
Certification :
Rohs ISO9001
Place of Origin :
China
MOQ :
1 piece
Price :
200-400 USD per square meter
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
20000 square meter per month
Delivery Time :
7-10 days
Packaging Details :
Vacuum Package
Material :
FR4 with copper
Solder mask :
blue
Silkscreen :
white
Use :
new energy vehicles
Thickness :
3.0mm
Copper thickness :
3oz
Description

New energy PCB , New energy vehicles,power supply, electric car charging station, power control.

PCB Type Material Type Material Brand
Single side pcb
Double side pcb
Multilayer pcb
Single side pcb		 CEM-1
FR-4
Aluminum
Copper
Ceramic		 SY
KB
IL
LianMao
HongRen
Arlon
KingWong
VT
Laird
5052 Series
The advantage of us
1 We have our own, independent of the wastewater treatment system.Make sure there will be a very big development space and the stability of the production environment in the futurer
2 Flexible operation, can be in the production of small batches.Also can produce large quantities.Can save production quickly.
3 The urgent double sample production for 24 hours, The urgent Multilayer sample production for 48 hours.completely according to customer requirements
About the Files
1 You have gerber files or PCB files
2 You have PCB samples. send to us the sample. we will help for free copy it
How to calculate the price
1 For example, your double sided PCB size is 100 mm * 200 mm wide, long double sided PCB price is $60 a square meters.So the calculation results 100MM*200MM*$60/1000000=$1.2
1 inch=25.4mm
About the transportation.
All the quotation does not include the transportation cost
1 You find a freight forwarding company to help you, When we finished the PCB ,We wiill send to your forwarder company directly .You directly to the transport charges paid to forwarder company
2 We help you responsible for transport, freight included in the price.According to how much money a kilogram computation.
3 In order to save costs.The best is you have familiar forwarder company


Process Capability

Material Type: FR4/Aluminum/Ceramic/CEM-1/Copper/polytef
Board Thickness: 0.2-6.0mm
Min Line Width/spacing:0.08mm
Max working size:520*620mm(21.25x24.5inch)
Min thickness Board for HAL surface finished:0.4mm
Min thickness 4 layer: 0.4mm
Min/Max layer count : 1/20
Min SMD Pitch : 0.125mm
Layer to Layer registration:<0.1mm
Differential impedance:+/-10%
Plating spect ratio: <8:1
Surface Finished: LF-HASL ,Immersion Gold/Tin/Silver ./Plating Gold/OSP,
Solder Mask:Green , Red, Blue,White, Black,Yellow.

Cooper thickness: 0.5-12OZ
Min hole size: 0.25mm( finished hole size)
Drilling accuracy:+/-0.05
Min Inner layer thickness:0.1mm
Certificate: Rohs, Iso9001, UL(in certification)
Min thickness 6 layer:0.6mm
Lamination evenness :+/-0.05mm
Min Dam Between Fine Pitch: >0.1mm
Impedance control:+/-5%
Board bow/twist tolerance:<0.7%
Plating COV: <10%
PTH backlight : 9-9.5 level
Plating extensibility:>15%

Copper clad aluminum plate has been widely used in LED lights, microelectronics and other fields.It has the incomparable advantage over traditional ceramic substrates:
(1) can be greatly reduced the quality of the power module, meet the needs of lightweight development module, and the traditional module of heat dissipation copper plate and ceramic substrate density is bigger, heavier quality;
(2) can make the power module encapsulation easier, save ceramic substrate and copper cooling plate screen printing process, such as the production cycle is shorten, conducive to module automation production.
(3) has good thermal conductivity and dielectric properties;
(4) copper clad aluminum plate than the cooling copper plate and DBC ceramic substrates are much lower price, can make the power module of the production cost greatly reduced.
