Automatic Z Purlin Roll Forming Machine 5 Tons Manual Uncoiler PLC Control
Automatic Z Purlin Roll Forming Machine 5 Tons Manual Uncoiler PLC Control
Automatic Z Purlin Roll Forming Machine 5 Tons Manual Uncoiler PLC Control
Automatic Z Purlin Roll Forming Machine 5 Tons Manual Uncoiler PLC Control
Automatic Z Purlin Roll Forming Machine 5 Tons Manual Uncoiler PLC Control
Automatic Z Purlin Roll Forming Machine 5 Tons Manual Uncoiler PLC Control
Specifications
Brand Name :
DingBo
Model Number :
DBCZ
Certification :
CE,ISO,SGS
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
1
Price :
USD20,000-USD40,000
Payment Terms :
TT/LC
Supply Ability :
10sets/month
Delivery Time :
Shipped in 30-70 days after payment
Packaging Details :
Export standard sea package with film and steel
Raw material :
Galvanized Sheet
Roller driven type :
Chain Transmission
Control system :
PLC
Roller material :
High-grade 45# Steel
Shaft material :
High Grade No.45 Forged
Voltage :
380V 50Hz 3phases
Product name :
Automatic Z Purlin Roll Forming Machine 5 Tons Manual Uncoiler PLC Control
Color :
Customers Requirement
Description

Automatic Z Purlin Roll Forming Machine 5 Tons Manual Uncoiler PLC Control

Main feature

We are professional manufacturer of all kinds of roll forming machine, this C channel roll forming machine is use for making solar photovoltaic stents, which is very hot recently in China, even the worldwide, all the machines according to the customer's requirements.

Working flow

Decoiler ---- Feeding --- Levelling--- Punching --- Cutting ---Roll forming--- Run out table

Technical parameters

1. Steel Sheet Thickness: 1.5-3.0mm (depend on requirement )

2. Hydraulic power: 5.5Kw

3. Transmission way: Chain

4. Material of blade: Cr12, quenching treatment

5. Capacity of Decoiler: 5 ton

6. Forming Speed: 10-15m/min

7. Roller stations: about18 stations main roller

8. Roller Material: GCr15 grade steel, quenching treatment

9. Roller Diameter:80mm

10. Principal Axis: 45# high grade steel with quenching treatment

11. Main Motor Power: 15 Kw

Main components

No. Item Unit Qty
1 Manual decoiler set 1
2 Main roll forming machine set 1
3 Main machine of composting set 1
4 PLC control box set 1
5 Supporter table set 1

Machine picture

Automatic Z Purlin Roll Forming Machine 5 Tons Manual Uncoiler PLC Control

Automatic Z Purlin Roll Forming Machine 5 Tons Manual Uncoiler PLC Control
