300MM H - Beam Garage Door Frame Roll Forming Machine Fly Saw Cutting
300MM H - Beam Garage Door Frame Roll Forming Machine Fly Saw Cutting
300MM H - Beam Garage Door Frame Roll Forming Machine Fly Saw Cutting
300MM H - Beam Garage Door Frame Roll Forming Machine Fly Saw Cutting
Specifications
Brand Name :
ZBR
Model Number :
ZBR-D-30
Certification :
CE, SGS, ISO9001
Place of Origin :
Jiangsu
MOQ :
1 SET
Price :
Negotiated
Payment Terms :
Negotiated
Supply Ability :
10 sets per month
Delivery Time :
30 days
Packaging Details :
export package
cutting :
fly saw cutting
Main Frame :
300 H Steel Welded
Export Markets :
North America, South America, Eastern Europe, Afri
After-sales Service Provided :
Overseas third-party support available
Wall Plate THK :
16mm
Name :
Door Frame Metal Machine
Description

300MM H - Beam Garage Door Frame Roll Forming Machine Fly Saw Cutting

Roll Shutter Door Roll Forming Machine/Rolling Shutter Price
Technical Parameters (depending on specific requirements of users)


Suitable steel plate
Type
Color steel plate

thickness
0.3-1.2mm

Feeding width
As users needs

Effective width
As users needs

Production speed
8-12m/min

Roller stand
14 rows

Diameter
52mm

Main power
3kw

Pump power
3kw

Side panel of machine
14mm

Roller material
Carbon Steel 45#

Blade material
Cr12, qunched, Cr-plating size 0.05mm

Control system
PLC Delta Inverter

Main structure of the machine
300mm H-Beam



Components


No.
Item
Unit
Qty

1
Manual decoiler
set
1

2
Main roll forming machine
set
1

3
PLC control box
set
1

4
Supporter table
set
1



Service and Terms

Terms of Payment: 30% of the total contract value paid by T/T as down payment, the rest 70% of the total contract value to be paid by T/T after inspection by buyer in seller's factory while before delivery.
Delivery: 30 days after receipt of advance payment
Service: we send technician to your country to fix the machine.The buyer should bear all the cost including: visa, Roundtrip tickets and suitable accommodation, also buyer should pay salary 80USD/day.
Warranty: 12 months limited warranty
During warranty: parts are free but buyer pay for the shipping fee
