380v 220V U 22kw Purlin Forming Machine Metal Sheet Roof Panel Tile Making
380v 220V U 22kw Purlin Forming Machine Metal Sheet Roof Panel Tile Making
Specifications
Brand Name :
DLY
Model Number :
C U Z machine
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
30sets/month
Delivery Time :
40 days
Packaging Details :
naked or wooden
name :
Purlin Roll Forming Machine
Warranty :
12 months
Condition :
new
Weight :
12500kgs
Type :
Steel Frame & Purlin Machine
Production capacity :
10-25 m/min
Power(w) :
22kw
Roller material :
GCr15
Description

380V U Purlin Roll Forming Machine Metal Sheet Roof Panel Tile Making Machine

1. Description of C U Z Purlin Roll Forming Machine

Machine Parts
1) CZ purlin machine punching system
with 3 cylinder(one cyinder for single hole and 2 cylinders for dual-holes.


2) interchange cz cold rolled purlins machine rollers
Rollers manufactured from high quality bearing steel GCr15, CNC lathes, Heat Treatment.with black treatment or Hard-Chrome Coating for options.With feeding material guide, body framemade from 400# H type steel by welding


3) interchange cz cold rolled purlins machine post cutter
No need to change cutter for different size,made by high quality mold steel Cr12 with heat treatment, Cutter frame made from high quality 30mm steel plate by welding. Pre-punching & Pre-cutting, stop to punch, stop to cut
hydraulic motor:7.5KW, Hydraulic pressure range: 0-16Mpa


4)interchange cz cold rolled purlins machine decoiler
Manual Decoiler: one set
Un-powered,manually control steel coil inner bore shrinkage and stop
Max. feeding width: 500mm, coil ID range 470mm±30mm
Capacity: Max. 5Ton


5)interchange cz cold rolled purlins machine exit rack
Un-powered,two unit (3m*2)

2. Specifications of C U Z Purlin Roll Forming Machine

Profile Web Flange Lip Thickness
C 80-300mm 40-80mm 10-25mm 1.2-3.2mm
Z 120-300mm 40-80mm 10-25mm 1.2-3.2mm
Yield strength 195Mpa 235Mpa 345Mpa 550Mpa
Thickness 1.2mm-3.2mm 1.2mm-3.0mm 1.2mm-2.7mm 1.2mm-2.5mm
Slotted hole Round hole
14x26mm(HOR.) D14mm
16x26mm(HOR.) D16mm

Equipment series Post-punch Post-cut
Phase/voltage/frequency Customize
Driven type Servo-motor
CZ inter-change type Manual
Size inter-change type Electric
Pre-cutter Optional
Flange punch Optional
Decoiler Manual decoiler
Hydraulic decoiler (Optional)
Production capacity Maximum 35m/min
Length tolerance ±1.5mm

3. Profiles of ​C U Z Purlin Roll Forming Machine

380v 220V U 22kw Purlin Forming Machine Metal Sheet Roof Panel Tile Making

4.​ FAQ

● What is your machine warranty?

some quick-wear parts will be container together with machine.

if some parts damaged within one year, we will send new one to you for free, just freight up to you.

● Is it complicated to operate the machine?

It is very easy, the machine is automatic, one or two persons can operate it, we provide machine use training.

● How many different profile roofing one machine can produce?

One machine can produce one or two different profiles.

5. Detail photos of ​C U Z Purlin Roll Forming Machine

380v 220V U 22kw Purlin Forming Machine Metal Sheet Roof Panel Tile Making

380v 220V U 22kw Purlin Forming Machine Metal Sheet Roof Panel Tile Making380v 220V U 22kw Purlin Forming Machine Metal Sheet Roof Panel Tile Making
