Ppgl Plc 15kw Metal Roofing Roll Forming Machine With 10m Speed
Ppgl Plc 15kw Metal Roofing Roll Forming Machine With 10m Speed
Specifications
Brand Name :
DLY
Model Number :
Roll Forming Machine Metal Roofing
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
30sets/month
Delivery Time :
40 days
Packaging Details :
naked or wooden
name :
Sheet Metal Profiling Machine
Power :
7.5kw
Weight :
5000kgs
Shafts Diameter :
70mm/75mm/80mm
voltage :
380V/50HZ
Dimension(L*W*H) :
6m*1.5m*1.6m
After-sales Service Provided :
Engineers available to service machinery overseas
Type :
Tile Forming Machine
Description

PPGL Plc 15kw Roll Forming Machine Metal Roofing With 10m Speed​

1. Description of Sheet Metal Profiling Machine

sheet metal profiling Machine offers a profitable solution for space and energy, combines Roofing, Wall Cladding, Corrugated profiles in one machine.Base on stable and durable performance, we knows well on various Roofing profile in different markets. Maximize cover width, Logo embossing, Anti-capillary grooves, we also offer customized product for client to supply their innovative idea to market.
this serious including Roofing, Wall Cladding, Corrugated profiles for both Coated Coil (PPGI/PPGL) and Galvanized Coil (GI/GL).

2. Specifications of Sheet Metal Profiling Machine

Machine details
Roller material
Forming rollers adopt 45# steel,after balance correction.And surface of rollers is grinded,polished and hard chromium plating
with high precision.To ensure the smoothness of the chamfer, reduce the friction between the plate and rollers, and reduce the
damage of the paint surface of the plate.
Shaft material
Shafts of forming adopt 45# steel,after balance correction,are grinded,polished with high precision.
Stainless steel dust shield is mounted on the outside of the bearings.
Diameter of shaft
72mm or as your requirement
Main frame
400 H steel
Productivity
20-25m/min
Hydraulic station power
5.5 KW
Hydraulic pressure
10-12MPa
Controlling system
famous PLC computer control
Material of cutting table
Cr 12 mould steel with quenched treatment
Hydraulic oil
40# hydraulic oil
Electric tension
380V 50 Hz 3 Phase or as your requirements

3. FAQ of Sheet Metal Profiling Machine

1. Does one machine can only produce one style panel profile?
Not exactly.For wider and double layer making machine. It can produce more than 6 kinds of panels.

2. Do you have after sales support?
Yes, we are happy to give advice and we also have skilled technicians available across the world.We need your machines running in order to keep your business running.

3. What can you do if the machine broken?
Our machine's warranty period is 12months,if the broken parts can't repair,we can send the new parts replace the broken parts freell,but you need pay the express cost yourself.if after warranty period,we can through negotiationfor to solve the problems,and we supply the technical support for the whole life of the equipment.

4. Can you be responsible for transport?
Yes,please tell me the destination port or address.we have rich experience in transport.

4. details of Sheet Metal Profiling Machine

Ppgl Plc 15kw Metal Roofing Roll Forming Machine With 10m SpeedPpgl Plc 15kw Metal Roofing Roll Forming Machine With 10m SpeedPpgl Plc 15kw Metal Roofing Roll Forming Machine With 10m SpeedPpgl Plc 15kw Metal Roofing Roll Forming Machine With 10m Speed
