Specifications
Brand Name :
VANFORGE
Certification :
ISO9001, ISO10012, ISO14001, OHSAS18001, ABS, BV, DNV, Lloyd, NK
Place of Origin :
China
MOQ :
5 metric tons
Payment Terms :
L/C, T/T
Supply Ability :
5000 metric tons per month
Delivery Time :
60 days
Packaging Details :
Seaworthy package for export
Material :
Alloy steel
Process :
Hot rolled
Treatment :
Quenched
Surface :
Black, peeled
Shape :
Round
Length :
Cut to length on request
Price :
Negotiable
Description

Hot rolled ocean anchor chain steel round bar

Chemical composition, %, max.

Steel grade C Si Mn P S
SBC 300 0.13 0.04 0.50 0.040 0.040
SBC 490 0.25 0.15-0.40 1.00-1.50 0.040 0.040
SBC 690 0.36 0.15-0.55 1.0-1.90 0.040 0.040

For SBC 690, such elements as Ni, Cr, Mo and V other than given in the table above may be added, as required.

Mechanical properties

Steel grade

Tensile strength

N/mm2

Elongation

%

Contraction

%

 Condition of test specimen
SBC 300 300 min 30 min. - As rolled
SBC 490 490 min 22 min. - As rolled or normalized
SBC 690 690 min 17 min. 40 min. Heat treatment of quenching and tempering or the like

The shape, dimensions, masses and tolerances of steel bars shall be in accordance with JIS G 3191.

Appearance of steel bars shall be in accordance with clause 9 of JIS G 3191

The chemical composition of steel bars shall be obtained by the cast analysis, and the general

matters concerning the analytical test and the sampling method for the analytical samples shall conform to clause 8 of JIS G 0404

The general matters pertaining to mechanical tests shall be in accordance with clause 9 of JIS G 0404

Method of tension test JIS Z 2241

Method of bending test JIS Z 2248

Method of impact test JIS Z 2242

Marking

The steel bar which has passed the inspection shall be marked with the following information by an appropriate method on each steel bar or on each bundle. However, part of the following information may be omitted, as agreed on between the purchaser and the manufacturer.


Product size range
Diameter: 40mm - 150mm
Length: on request
