Specifications
Brand Name :
VANFORGE
Certification :
ISO9001:2015, ABS, BV, CCS, DNV GL, NKK
Place of Origin :
China
MOQ :
5 metric tons
Payment Terms :
L/C, T/T
Supply Ability :
3000 metric tons per month
Delivery Time :
15 days
Packaging Details :
In bundles, standard seaworthy packing for export
Material :
Low alloy steel
Process :
Hot rolled
Shape :
Flat plate
Surface treatment :
Plain and smooth
Length :
Up to 12000mm
Condition :
Thermomechanically rolled
Price :
Negotiable
Description

Description

420ML structural steel is a thermomechanically rolled structural steel plate that provides high strength at low temperatures. 420ML structural steel meets or exceeds the requirements of S420ML in EN 10025-4.

Dimension Range

420ML structural steel is available in thicknesses of 7.00-63.00 and in widths up to 3300mm depending on the thickness. More detailed dimensions are provided in the dimension program.

Mechanical Properties

Thickness

(mm)

Yield strength ReH

(min MPa)

Tensile strength Rm

(MPa)

Elongation A

(min %)
7.00 - 16.00 420 520 - 680 19
16.01 - 40.00 400 520 - 680 19
40.01 - 63.00 390 500 - 660 19

The tensile test is made transversally to the rolling direction in compliance with EN 10025-4.

Impact Properties

Test temperature Min. impact energy for longitudinal Charpy V- notch test
-60 °C 40 J

The impact test is made longitudinally to the rolling direction in compliance with EN 10025-4.

Chemical Composition (Ladle analysis), %, max

C Si Mn P S Al Nb V Ti
0.14 0.50 1.60 0.020 0.015 0.02 0.05 0.10 0.05

Thickness

420ML structural steel is delivered with tolerances that correspond to ¾ of EN 10029:2011 Class A as default value.

Length and Width

Width tolerances -0/+4-10mm depending on the thickness. Length tolerances -0/+15-25mm depending on length.

Shape

According to EN 10029.

Flatness

Maximum flatness deviation 6 mm/m.

Surface

According to EN 10163-2 Class A3.

Delivery Conditions

Thermomechanically rolled (M).

Fabrication and Other Recommendations

Minimum inner bending radius is 1.0 x t transverse to the rolling direction and 1.5 x t longitudinal to the rolling direction up to max 20mm in thickness.

Appropriate health and safety precautions must be taken when bending, welding, cutting, grinding or otherwise working on the product.
