DIN 2576 ASME SA182 PN40 Flat Welding Flange , Stainless Steel Welding Neck Flange
DIN 2576 ASME SA182 PN40 Flat Welding Flange , Stainless Steel Welding Neck Flange
DIN 2576 ASME SA182 PN40 Flat Welding Flange , Stainless Steel Welding Neck Flange
DIN 2576 ASME SA182 PN40 Flat Welding Flange , Stainless Steel Welding Neck Flange
DIN 2576 ASME SA182 PN40 Flat Welding Flange , Stainless Steel Welding Neck Flange
DIN 2576 ASME SA182 PN40 Flat Welding Flange , Stainless Steel Welding Neck Flange
DIN 2576 ASME SA182 PN40 Flat Welding Flange , Stainless Steel Welding Neck Flange
DIN 2576 ASME SA182 PN40 Flat Welding Flange , Stainless Steel Welding Neck Flange
Specifications
Brand Name :
VANFORGE
Certification :
ISO9001, ISO10012, ISO14001, OHSAS18001, ABS, BV, DNV, Lloyd, NK, PED
Place of Origin :
China
MOQ :
10 pcs
Payment Terms :
L/C, T/T
Supply Ability :
3000 pcs per month
Delivery Time :
30 days
Packaging Details :
Seaworthy package for export
Material :
Austenitic stainless steels, duplex stainless steels
Process :
Forged, machined
Treatment :
Stress-relieved
Surface :
Bright
Application :
Petrochemical, chemical, paper and pulp
Feature :
High precision
Standard :
ANSI, ASTM, ASME, EN, DIN, JIS, GOST
Price :
Negotiable
Description

EN 1092-1 type 01 DIN 2576 ASME SA182 PN40 forged stainless steel plane welding flange

Stainless steel plane welding flanges PN 10, 16 and 40 according to EN 1092-1 latest edition. Base material according to EN 10222-5/ASTM/ASME A/SA 182.

Vanforge's EN plane welding flanges are corrosion tested according to EN ISO 3651-2 latest edition and PMI checked. The stainless plane welding flanges are certified according to EN 10204/3.1.

  • Austenitic stainless steels: ASTM 304/304L and ASTM 316/316L
  • Duplex stainless steel: UNS S31803 / EN 1.4462
  • Super-duplex stainless steel: UNS S32750 / EN 1.4410

DIN 2576 ASME SA182 PN40 Flat Welding Flange , Stainless Steel Welding Neck Flange

Plane welding flanges PN 40

EN 1092-1, type 01

Material EN 1.4306/1.4307 (ASTM 304L) and EN 1.4404 (ASTM 316L). Annealed, fully machined.

Product code example:

FFPW-316L-33.7-PN40

● = Standard

Pipe

d1

d5

Tol.

D

b

k

Drilling template

d2

Weight

ASTM

ASTM
DN mm mm mm mm mm Holes Thread mm kg/pce 304L 316L
15
-		 20.0
21.3		 21.0
22.0		 +0.5/-0
-		 95
-		 14
14		 65
65		 4
-		 M 12
-		 14
-		 0.670
0.670		 -
-		 ●
●
20
-		 25.0
25.9		 26.0
27.5		 +0.5/-0
-		 105
-		 16
16		 75
75		 4
-		 M 12
-		 14
-		 0.940
0.936		 -
-		 ●
●
25
-		 30.0
33.7		 31.0
34.5		 +0.5/-0
-		 115
-		 16
16		 85
85		 4
-		 M 12
-		 14
-		 1.140
1.110		 -
-		 ●
●
32
-		 38.0
42.4		 39.0
43.5		 +0.5/-0
-		 140
-		 18
18		 100
100		 4
-		 M 16
-		 18
-		 1.860
1.820		 -
-		 ●
●
40
-		 44.5
48.3		 45.5
49.5		 +0.5/-0
-		 150
-		 18
18		 110
110		 4
-		 M 16
-		 18
-		 2.110
2.080		 -
-		 ●
●

Production facilities:

DIN 2576 ASME SA182 PN40 Flat Welding Flange , Stainless Steel Welding Neck Flange

DIN 2576 ASME SA182 PN40 Flat Welding Flange , Stainless Steel Welding Neck Flange

DIN 2576 ASME SA182 PN40 Flat Welding Flange , Stainless Steel Welding Neck Flange

DIN 2576 ASME SA182 PN40 Flat Welding Flange , Stainless Steel Welding Neck Flange

DIN 2576 ASME SA182 PN40 Flat Welding Flange , Stainless Steel Welding Neck Flange
