12.7mm Seamless Titanium Tube with 15mm and 24.5mm Hydraulic Test, Designed for Long Life Span
12.7mm Seamless Titanium Tube with 15mm and 24.5mm Hydraulic Test, Designed for Long Life Span
Specifications
Brand Name :
LHTI
Model Number :
LH-01
Certification :
ISO9001
Place of Origin :
BaoJi Shaanxi China
MOQ :
If in stock, sample is available; If not in stock,100kgs of each size
Price :
USD $19.5-$28.5 / kg
Payment Terms :
Western Union, T/T, L/C, D/A, D/P
Supply Ability :
100 tons per month
Delivery Time :
7-25 working days
Packaging Details :
Standard exporting packaging, plywood case outside
Dimention :
OD(5-114)X(0.3—10)XL1200mmMax
Processing Service :
Bending, Cutting
Coporation :
trading and manufacture
Titanium Coil Tube :
ASTM B861/B338
Applications :
Pressure Vessel Equipment and boilers
Processing :
Seamless
Corrosion Resistance :
High
Corrosionresistance :
Excellent
Inside Diameter :
4~268mm
Application :
Aerospace, Chemical Industry, Medical, etc.
Package :
wooden cases
Thickness :
0.5mm-10mm
Color :
Metallic
Colour :
Silver
Grade :
Gr1, Gr2, Gr5
Description

12.7mm Seamless Titanium Tube with 15mm and 24.5mm Hydraulic Test, Designed for Long Life Span

Product Description:

Our titanium tubes, manufactured to ASTM B338 standards, adhere to stringent quality requirements. We produce these tubes with strict compliance to ensure precise dimensions, accurate chemical composition, optimal physical properties, and high-quality surfaces. Our comprehensive quality inspections include hydraulic tests, flaw detection, ultrasonic testing, and flattening tests, all conducted in accordance with ASTM B338 standards. We also welcome third-party testing from organizations such as TUV, SGS, BV, or others, upon customer request.

12.7mm Seamless Titanium Tube with 15mm and 24.5mm Hydraulic Test, Designed for Long Life Span12.7mm Seamless Titanium Tube with 15mm and 24.5mm Hydraulic Test, Designed for Long Life Span12.7mm Seamless Titanium Tube with 15mm and 24.5mm Hydraulic Test, Designed for Long Life Span

Product information:

Name Titanium pipe / tube
Material Gr1,Gr2
Standard ASTM B338
Type Seamless/welded
OD 12.7mm 15mm 19.1mm 24.5mm 33.4mm 38.1mm 45mm 57mm, or as customer's request
Wall Thickness 0.5-1.5mm , or as customer's request
Length Max 16000mm
Technique Rolled
status Annealed
Certificate EN 10204/3.1B,
Raw Materials Certificate
100% Radiography Test Report
Third Party Inspection Report---TUV,BV,SGS etc
Application Heat Exchangers,Chemical industry

Chemical composition (Wt%)

ASTM No. Fe max O max N max C max H max Pd Al Bal
Grade 1 0.2 0.18 0.03 0.1 0.015 - - Ti
Grade 2 0.3 0.25 0.03 0.1 0.015 - - Ti

Physical Properties (Min)

ASTM Grade Alloy Composition Tensile Strength Yield Strength Elongation min %
ksi Mpa ksi Mpa
Grade 1 Unalloyed Ti ("Pure") 35A -CP1 35 240 25 170 30
Grade 2 Unalloyed Ti ("Pure") 50A -CP2 58 400 40 275 25
