High Precision Portable Reference Standard For Single Phase Meter Calibration With 10-420V Voltage Range
High Precision Portable Reference Standard For Single Phase Meter Calibration With 10-420V Voltage Range
High Precision Portable Reference Standard For Single Phase Meter Calibration With 10-420V Voltage Range
High Precision Portable Reference Standard For Single Phase Meter Calibration With 10-420V Voltage Range
Specifications
Brand Name :
GENY
Model Number :
YC2000A
Certification :
ISO, CE
Place of Origin :
CHINA
Payment Terms :
L/C, T/T, D/P
Supply Ability :
300/Year
Model NO. :
YC2000A
Accuracy :
0.3%
Power Supply :
External power supply Test lead power
Accessories Included :
Optional
Range :
10-420V
Error :
±0.1%
Description

Single Phase Portable Meter Tester for Calibration with High Precision within Voltage Range10v – 420V for Fieldwork

Specifications:

Range 10-420V
Error ±0.1%
Harmonic 2nd -- 51st
Range (direct connection) --
Range (clamp CT)

100A

5A,500A,1000A,2000A (option)
Error (direct connection) --
Error (clamp CT)

±0.3% (5A, 100A)

±0.5% (other)
Harmonic 2nd -- 51st
Active power (direct connection) --
Active power (clamp CT)

±0.3% (5A, 100A)

±0.5% (other)
Reactive power (direct connection) --
Reactive power (clamp CT) ±0.5%
Active energy (direct connection) --
Active energy (clamp CT)

±0.3% (5A, 100A)

±0.5% (other)
Reactive energy (direct connection) --
Reactive energy (clamp CT) ±0.5%
Range 0º – 360º
Error ±0.1º
Range 45Hz – 65Hz
High frequency output(CH) --
Low frequency output(CL) 800imp/kWh
Pulse ratio 1:1
Output level 5V
Input channel 1
Input level 5 -- 10V
Input frequency Max. 100Hz
Resolution 3.5”TFT color (320×240)
Vector diagram N/A
Waveform Yes
Energy accumulation Yes
CT ratio test Yes
Local parameter input Yes
Wiring emulation N/A
Self-calibration N/A
Recorder check Yes
Data storage Yes
Data storage qty 1000
External extend memory N/A
Screen printing N/A
Communication port RS232
Communication with PC Yes
Upload data Yes
External mini printer N/A
External keyboard N/A
Voltage Supply way

External power

test lead power
Voltage Supply 50-420V, 50/60Hz
Ambient temperature -25°C -- +45°C
Relative humidity 40% -- 95%
Dimensions (W×H×D) (mm) 190×140×50
Weight (kg) 0.7kg

Features&Functions

  • High accuracy 0.3%
  • External power supply or test lead power , suit for Fieldwork
  • With 2pcs clamp CT to test ratio of current transformer.
  • (Optional)
  • Large size display screen, direct viewing and convenient
  • Internal communication port for PC control
  • Multi power supply ways for different testing occasions.
  • Large capacity storage device for mass memory

Description:

1. Current direct connection for high accuracy calibration

2. External power supply or test lead power, suit for fieldwork

3. With 2pcs clamp CT to test ratio of current transformer. (Optional)

Applications:

1. Nation-level utility companies

2. Governmental bureaus of metrology

3. Big energy meter manufacturers

Primary Competitive Advantages:

1. High quality product

2. High stability

3. Friendly interface

4. Convenient operation
