Low Load Brinell HBS-62.5 Digital Hardness Tester
Low Load Brinell HBS-62.5 Digital Hardness Tester
Specifications
Supply Ability :
50, 000PCS/Year
Payment Terms :
L/C, T/T, Western Union
Place of Origin :
CHINA
MOQ :
1 Piece
Price :
negotiation
Brand Name :
HARDRULER
Delivery Time :
7 working days
Model Number :
HBS-62.5
Certification :
CE
Packaging Details :
Standard exporting package
Measuring Range :
HB
Application :
Metal, Ceramics and Glass
Standard :
ISO, ASTM, GB/T
Calibrating Method :
Standard Hardness Test Blocks
Rated Voltage :
110V/220V
Support Language :
English
Customized :
Customized
Testing Range :
Hbw8~Hbw650
Loading Control :
Automatic(Loading, Dwell, Unloading)
Lens & Indenter Switch :
Motorized
Resolution :
0.0005mm(5X) 0.00025mm(10X)
Dwell Time :
Adjustable 0~95s
Magnification of Microscope :
Observation:5X/10X Measurement: 5X/10X
Magnification of Eyepiece :
10X, with Digital Encoder
Max. Height of Specimen :
170mm
HS Code :
9024102000
Description

Usage
HBS-62.5 low load Brinell hardness tester is used to determine the Brinell hardness of unquenched steel, cast iron, non-ferrous metals and soft bearing alloys, etc. It is especially suitable to determine the Brinell hardness of soft metal materials and small parts.

Features & Advantage
1. Accurate reliable and durable tester at a very cheap price
2. Closed loop load technology enhances the accuracy
3. Brinell video microscope system optional
4. Accuracy conforms to EN-ISO 6506, ASTM E10, GB/T231.2

Specifications

Product name Digital Low Load Brinell Hardness Tester
Model HBS-62.5M
Brinell scales HBW5/62.5, HBW2.5/62.5, HBW2.5/31.25, HBW2.5/15.625, HBW2.5/6.25, HBW1/30, HBW1/10, HBW1/5
Testing load Kgf 5, 6.25, 10, 15.625, 30, 31.25, 62.5
N 49.03, 61.29, 98.07, 153.2, 294.2, 306.5, 612.9
Testing range HBW8~HBW650
Loading control Automatic(loading, dwell, unloading)
Lens & indenter switch Motorized
Resolution 0.5μm(5x) 0.25μm(10x)
Dwell time Adjustable 0~95s
Magnification of microscope Observation:5x/10x
measurement: 5x/10x
Magnification of eyepiece 10x, with digital encoder
Max. height of specimen 170mm
Instrument throat 130mm
Dimension (L*W*H) 530*220*580mm
Gross/Net weight 70kg/50kg
Power supply 220V or 110V AC, 50 or 60Hz
Accuracy conforms to EN-ISO 6506, ASTM E10, GB/T231.2
