Specifications
Brand Name :
TCS
Model Number :
JQB2438 series3
Certification :
ISO9001、ISO14001、ROHS、REACH
Place of Origin :
China
MOQ :
500PCS
Price :
negotiate
Payment Terms :
T/T
Supply Ability :
100000+pcs per month
Delivery Time :
20-25 days
Packaging Details :
Carton with foam pad
Media :
Air
Voltage :
DC3.0-24V
Power :
3REF W
Flow :
0.5-3.5LPM
Pressure :
0-65Kpa
Application :
Other
Other :
Consulting service
pump body material :
POM
Color :
White
Description

DC 3V 12V 370 Micro Air Pump For Vacuum Suction Device DC 24V Mini Vacuum Pump

Quick Detail:

Warranty: A year

Voltage: 3V/6V/12V/24V

Place of Origin: Guangdong, Shenzhen, China

Model Number: JQB2438 series3

Theory: DC Brush Motor Micro Pump

Rated power: 3W

Steam Inlet: 5

Application: Breast pump, Vacuum suction device, Other

Voltage: DC3.0-24.0V

Customized Support: OEM, ODM, OBM

​Description:

This is an air pump, the maximum flow is 4.5LPm, and its structure is the Diaphragm Pump. This air pump can be used in baby products such as breast pumps, but also in medical devices, beauty equipment, and other products.

Specification:

Item
Air pump
Brand name
TCS
Model NO.
JQB2438-3
Place of Origin
Shenzhen,China
Application
Breast pump, Vacuum suction device,Massager, Red wine preservation
Horsepower
Consulting service
Power Source
Electric
Pressure
Max.-53.3Kpa
Structure
DIAPHRAGM PUMP
Outlet Size
Consulting service
Voltage
DC3.0~24v
Power
3.0W
Certification
REACH&ROSH
Flow
>2.7LPM
Noise
<60DB
Life test
300 hours
Environment
0-50℃,75% RH
DC 3V 12V 24V Micro Air Pump POM Electric 370 Mini Vacuum Pump

Application:
DC 3V 12V 24V Micro Air Pump POM Electric 370 Mini Vacuum Pump

FAQ:

Q1. Can I have a sample order for Air Pump?

A: Yes, we welcome sample order to test and check quality.

Q2. What about the lead time?

A: 3-5 days for Sample preparing ,20-25working days for mass production.

Q3. Do you have any MOQ limit for Air Pump order?

A: Yes,1000pcs MOQ, 1-10pcs for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?

A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order for solenoid valves?

A: Firstly let us know your requirements or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms the samples and places deposit for formal order.

Fourthly We arrange the production.

Q6. What are the terms of trade?

A: FOB, EXW

Q7: Do you offer guarantee for the products?

A: Yes, we offer 1 years warranty to our products.

Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.

Secondly, during the guarantee period, we will send new air pump with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
