Large Flow Electric Micro Vacuum Pump 10LPM - 15LPM Mini Diaphragm Vacuum Pump
Large Flow Electric Micro Vacuum Pump 10LPM - 15LPM Mini Diaphragm Vacuum Pump
Large Flow Electric Micro Vacuum Pump 10LPM - 15LPM Mini Diaphragm Vacuum Pump
Large Flow Electric Micro Vacuum Pump 10LPM - 15LPM Mini Diaphragm Vacuum Pump
Large Flow Electric Micro Vacuum Pump 10LPM - 15LPM Mini Diaphragm Vacuum Pump
Large Flow Electric Micro Vacuum Pump 10LPM - 15LPM Mini Diaphragm Vacuum Pump
Large Flow Electric Micro Vacuum Pump 10LPM - 15LPM Mini Diaphragm Vacuum Pump
Large Flow Electric Micro Vacuum Pump 10LPM - 15LPM Mini Diaphragm Vacuum Pump
Large Flow Electric Micro Vacuum Pump 10LPM - 15LPM Mini Diaphragm Vacuum Pump
Large Flow Electric Micro Vacuum Pump 10LPM - 15LPM Mini Diaphragm Vacuum Pump
Specifications
Brand Name :
TCS
Model Number :
JQB5177 series2
Certification :
ISO9001、ISO14001、ROHS、REACH
Place of Origin :
China
MOQ :
500PCS
Price :
negotiate
Payment Terms :
T/T
Supply Ability :
100000+pcs per month
Delivery Time :
20-25 days
Packaging Details :
Carton with foam pad
Voltage :
AC/DC 110.0V~220.0V
Power :
29REF W
Flow :
10-15LPM
Negative pressure :
-70-75Kpa
Positive pressure :
180-250Kpa
Media :
Air
Structure :
Vacuum Pump
Pressure :
Low Pressure
Application :
General, Beauty device, Massager, Other
Description

Large Flow Diaphragm Pump Beauty Instrument Micro Air Pump Vacuum Preservation Machine Adult Toys Micro Vacuum Pump

Quick Detail:

Warranty: 1 year

Voltage: AC/DC110.0-220.0V

Place of Origin: Guangdong, Shenzhen, China

Model Number: JQB5177 series2

Negative pressure: -70-75Kpa

Positive pressure: 180-250Kpa

Material: Stainless Steel

Application: General, Beauty machine, Vacuum fresh machine, Other

​Description:

This is a pump with an air medium. The power supply of this pump can use AC current as well as DC current, and the voltage range is DC110.0-220.0V. Voltage range in -70-75Kpa, 180-250Kpa, power in 29REF W. Product use can be used in massage, medical beauty, medical, beauty, home appliances, etc.

Specification:

Item
Air pump
Brand name
TCS
Model NO.
JQB5177-2
Place of Origin
Shenzhen, China
Application
Beauty machine Beauty massager, Massager breast pump vacuum fresh-keeping machine
Horsepower
Consulting service
Power Source
Electric
Pressure
-70~-75Kpa 180~250Kpa
Structure
DIAPHRAGM PUMP, Vacuum Pump
Outlet Size
Consulting service
Voltage
AC/DC110.0-220.0V
Power
29W
Certification
REACH&ROSH
Flow
10-15LPM
Noise
<60DB
Life test
300 hours
Environment
0-50℃,75% RH
Large Flow Electric Micro Vacuum Pump 10LPM - 15LPM Mini Diaphragm Vacuum Pump

Application:
Large Flow Electric Micro Vacuum Pump 10LPM - 15LPM Mini Diaphragm Vacuum Pump

FAQ:

Q1. Can I have a sample order for Air Pump?

A: Yes, we welcome sample order to test and check quality.

Q2. What about the lead time?

A: 3-5 days for Sample preparing ,20-25working days for mass production.

Q3. Do you have any MOQ limit for Air Pump order?

A: Yes,1000pcs MOQ, 1-10pcs for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?

A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order for solenoid valves?

A: Firstly let us know your requirements or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms the samples and places deposit for formal order.

Fourthly We arrange the production.

Q6. What are the terms of trade?

A: FOB, EXW

Q7: Do you offer guarantee for the products?

A: Yes, we offer 1 years warranty to our products.

Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.

Secondly, during the guarantee period, we will send new air pump with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
