11.1V 560KV Brushless Motor For Remote Control Quadcopter Aircraft
11.1V 560KV Brushless Motor For Remote Control Quadcopter Aircraft
11.1V 560KV Brushless Motor For Remote Control Quadcopter Aircraft
11.1V 560KV Brushless Motor For Remote Control Quadcopter Aircraft
11.1V 560KV Brushless Motor For Remote Control Quadcopter Aircraft
11.1V 560KV Brushless Motor For Remote Control Quadcopter Aircraft
11.1V 560KV Brushless Motor For Remote Control Quadcopter Aircraft
11.1V 560KV Brushless Motor For Remote Control Quadcopter Aircraft
Specifications
Brand Name :
SECORE
Model Number :
BLS-4250
Certification :
CE ROHS
Place of Origin :
Shenzhen
MOQ :
20
Price :
Negotiated The Price
Payment Terms :
T/T, D/A
Supply Ability :
10000pcs per month
Delivery Time :
10-12 working days
Packaging Details :
50pcs per carton or as request
Work voltage :
11.1V-36V
KV :
500-820KV
Rated torque :
1-2N.m
Motor sizes :
42*50mm ( diameter*length)
Shaft :
5*20mm
Max Power :
560W
Thrust :
2800g
Typical application :
RC quadcopter aircraft, scooter, rc car
Description

11.1V 560KV High Temperature Resistance Brushless Motor For Remote Control Quadcopter Aircraft

Specification of Secore BLS4250 Brushless outrunner Motor for pruner :

BLS-4250 brushless motor, suitable for Remote control dualcopter quadcopter Aircraft, RC car, scooter etc.

Motor diameter: 42mm height 50mm, Shaft diameter 5mm

It adopts high-temperature micro ball-bearing, NdFeB N45SH magnet, silicon steel can be 0.2mm thickness, SUS 420 stainless steel shaft, machining accuracy 0.006-0.012mm. soft silicon rubber cable, high and low temperature resistance and environmental friendly, insulation and high temperature resistance, soft and fireproof, shrinkable tube.

Motor Model number BLS-4250 Dimension 42*50mm
( diameter * length )
Motor type EC motor Rotor external rotor
Motor Name RC aircraft motor Hass sensor no ( optional )
Rated voltage 11.1V-36V KV(RPM/V) 500-820kv or custom
max lipo cell 3-6S Output shaft 5mm OD
Max power 560W weight 0.208kg

Tested performance:

model 4250-2 kv:720 no load current: 2.5A
tested paddle test voltage loaded current loaded speed thrust remark
12*6 11.1 19.1 6988 1.15
14.8 30.5 8670 1.9
18.5 44.5 9960 2.5 106℃ / 10mn
13*6.5 11.1 25.3 6444 1.62
14.8 42 8040 2.4 106℃ / 60s
18.5 56.6 9000 3.25
14*7 11.1 29.6 6109 1.65
14.8 48 7449 2.8 111℃ / 5mn
18.5 61 8166 3.45

model 4250-1 kv: 820 no load current: 3.2A
tested paddle test voltage loaded current loaded speed thrust remark
11*5.5 11.1 20.7 7909 1.1
14.8 33.7 9959 1.8
18.5 50 11675 2.85
12*6 11.1 27.2 7449 1.2
14.8 45.8 9300 2.35 88℃ / 10mn
18.5 59.8 10336 2.9
13*6.5 11.1 34.7 6904 1.75
14.8 56 8369 2.45 120℃ / 10mn
18.5 70 9330 3.3

11.1V 560KV Brushless Motor For Remote Control Quadcopter Aircraft
