24V IP67 Waterproof Brush Motor 63mm OD For 1m Submerged Aquaculture
24V IP67 Waterproof Brush Motor 63mm OD For 1m Submerged Aquaculture
24V IP67 Waterproof Brush Motor 63mm OD For 1m Submerged Aquaculture
24V IP67 Waterproof Brush Motor 63mm OD For 1m Submerged Aquaculture
24V IP67 Waterproof Brush Motor 63mm OD For 1m Submerged Aquaculture
24V IP67 Waterproof Brush Motor 63mm OD For 1m Submerged Aquaculture
24V IP67 Waterproof Brush Motor 63mm OD For 1m Submerged Aquaculture
24V IP67 Waterproof Brush Motor 63mm OD For 1m Submerged Aquaculture
Specifications
Brand Name :
SECORE
Model Number :
SC63120
Certification :
RoHS
Place of Origin :
Shenzhen
MOQ :
100
Price :
Negotiated The Price
Payment Terms :
T/T, D/A
Supply Ability :
100000pcs per month
Delivery Time :
9-12 working days
Packaging Details :
500pcs per carton or as request
Product name :
Waterproof DC motor
Nominal voltage :
24V
No load speed :
4000rpm ±10%
Rated speed :
3200rpm ±10%
Rated torque :
2kg.cm ( 0.2N.m, 1.77lb.in )
Output Power :
80W
Motor size :
OD63mm * L120mm
Application :
Aquaculture, robotics
Description

24V IP67 Waterproof Brush Motor 63mm Aquaculture Motor 1M Submerged

Main specification cases:

Model Number: DC-SC63120
Voltage range: DC 18V, 24V, customized 220V, 230V
High Speed: 4000rpm , or tailor-made
Features: High speed, high torque, steady running, low noise
Model number VOLTAGE NO LOAD AT MAXIMUM EFFICIENCY Lifetime
Nominal constant SPEED CURRENT SPEED CURRENT TORQUE
Volts ±10% r/min mA ±10% r/min mA N.m kg.cm H
SC-63120 24V 4000 650 3200 2800 0.2 2.04 2000


Motor dimensions

24V IP67 Waterproof Brush Motor 63mm OD For 1m Submerged Aquaculture

Test report of waterproofing motor SC63120 :

24V IP67 Waterproof Brush Motor 63mm OD For 1m Submerged Aquaculture

What specifications are needed for the motor?

  1. you must compute the size of the motor, how to install it (how to fix it in the system);
  2. the power, start & rated torque and speed of the motor are required;
  3. the industrial environment that the motor operates in must also be considered: different environment (explosion, humidity, corrosion, high and low temperatures, etc.) may have different design.

For harsh environments, like a waterproof, dustproof and shockproof enclosure needs to be reviewed, please contact us for further details.
