High Power 150W 2000RPM Bldc Brushless Motor 0.5N.M 24V For Smart Bathroom
High Power 150W 2000RPM Bldc Brushless Motor 0.5N.M 24V For Smart Bathroom
High Power 150W 2000RPM Bldc Brushless Motor 0.5N.M 24V For Smart Bathroom
High Power 150W 2000RPM Bldc Brushless Motor 0.5N.M 24V For Smart Bathroom
High Power 150W 2000RPM Bldc Brushless Motor 0.5N.M 24V For Smart Bathroom
High Power 150W 2000RPM Bldc Brushless Motor 0.5N.M 24V For Smart Bathroom
High Power 150W 2000RPM Bldc Brushless Motor 0.5N.M 24V For Smart Bathroom
High Power 150W 2000RPM Bldc Brushless Motor 0.5N.M 24V For Smart Bathroom
High Power 150W 2000RPM Bldc Brushless Motor 0.5N.M 24V For Smart Bathroom
High Power 150W 2000RPM Bldc Brushless Motor 0.5N.M 24V For Smart Bathroom
Specifications
Brand Name :
Secore
Model Number :
BLS-9282I
Certification :
ISO9001
Place of Origin :
Shenzhen
MOQ :
100
Price :
Negotiated The Price
Payment Terms :
T/T, D/A
Supply Ability :
100000pcs per month
Delivery Time :
8-10 working days
Packaging Details :
20pcs per carton or as request
Model number :
BLS-9282I
Motor size :
OD93mm *L82mm
No load speed :
3200rpm
Speed rated :
2000 R/min
Rated Torque :
5098g.cm /5kg.cm /0.5N.m
Rated current :
7.1A
Commutation :
Ec commutating
Shaft OD :
15mm or customize
Motor type :
150 bldc motor, 0.5N brushless motor, high torque bldc
Typical application :
automation equipment, fitness machine, electric gate
Description

High Power 150W 2000RPM Brushless Motor 0.5N.M 24V Bldc Motor For Smart Bathroom

Features of BLDC Motor BLS-9282:

  2. Diameter: 93mm
  3. Length: 82mm
  4. Shaft OD: 15mm D shaft or customization
  5. Tailor: voltage,speed,torque, shaft, housing material, encoder, brake etc.

Motor Model BLS-9282I Unit
Nominal voltage 24 V
No load speed ±12% 3200 rpm
Max cont.torque 0.5 N.m
Rated Speed 2000 rpm
Rated Current 7.2 A
Stall Torque 1.36 N.m
Stall current 17 A


  1. Dimension of the bldc motor:


High Power 150W 2000RPM Bldc Brushless Motor 0.5N.M 24V For Smart Bathroom

Performance curve:

High Power 150W 2000RPM Bldc Brushless Motor 0.5N.M 24V For Smart Bathroom
Customization

High Power 150W 2000RPM Bldc Brushless Motor 0.5N.M 24V For Smart Bathroom

How to choose the most suitable motor?

1. voltage: determine the working condition of the motor application

2. speed: the revolution per minute you need running at the rated voltage

3. torque: how much N.m you need at the rated voltage, how much N.m you need when it stops running

4. size restriction: dimensions of your mounting space

5. output shaft: it can be customized as per different installation requests, shaft diameter, length, threaded shaft, D shaft, dual flat shaft, single flat shaft, spring shaft, keyway shaft etc.
