Specifications
Brand Name :
VIC-TECH
Model Number :
25BYJ412-1L
Certification :
ROHS
Place of Origin :
China
MOQ :
1Unit
Price :
$5~7/unit
Payment Terms :
MoneyGram, Western Union,Credit Card,T/T, L/C
Supply Ability :
10000Units/month
Delivery Time :
15-30 work days
Packaging Details :
Standard export package, or can be customized
Type :
Gear Motor
Torque :
High Torque
Construction :
Permanent Magnet
Continuous current(a) :
customized
Voltage(v) :
5V
Description

3.2v High Quality stepper motor valve 25PM linear motor valve for precise position control such as valves

25BYJ412-1L stepper motor is mainly used in the fields of printer, valve, fluid control, position control, etc. This motor has the characteristics of small size, high precision and high strength.

The stepping motor has a built-in reduction gearbox to achieve a reduction ratio of 1:10, improve the torque, and finally use the output ejector with a stop-stop structure, so that the ram can be moved back and forth without rotation. General thrust

More than 10 kg.

At the same time, the external wiring part can be used according to customer requirements for various types and lengths of connecting lines, or FPC FFC.The shape of the mounting plate and the angle of the outlet can be adjusted according to customer needs!

Our team has more than 10 years of stepper motor design, development and production experience, so we can achieve product development and auxiliary design according to the special needs of customers!Customer needs are our efforts, please feel free to contact us!

Micro Dc Geared Stepper Motor 25PM Linear Motor Valve For Precise Position Control 25BYJ 412L

Mechanical Dimension:MM

Micro Dc Geared Stepper Motor 25PM Linear Motor Valve For Precise Position Control 25BYJ 412L

Typical Applications

  • Saliva Analyzer
  • Blood Analyzer
  • Welding Machine
  • Intelligent Security Products
  • Fiber Fusion Splicer
  • Digital Electronics

Specifications

Product Name 25 mm geared stepper motor
Model 25BYJ412-1L
Resistance 100 mΩ±7%/phase
Starting Frequency 500 pps ,400 PPS min. (AT 5V DC)
Response Frequency 900 pps ,450PPS min. (AT 5V DC)
Detent Torque 29.4mN.m
Operating Temperature Range -0~+55 ℃
OEM & ODM SERVICE

AVAILABLE

Torque Curve For Reference

Type of Wire Connect

Motor input method with Pin type,FPC, PCB, Lead wire etc.

These can be customized according to customer needs.

Micro Dc Geared Stepper Motor 25PM Linear Motor Valve For Precise Position Control 25BYJ 412L

Micro Dc Geared Stepper Motor 25PM Linear Motor Valve For Precise Position Control 25BYJ 412L

Type of Fixture Cover

The regular models are shown in the figure, and the special sizes can be customized.

Micro Dc Geared Stepper Motor 25PM Linear Motor Valve For Precise Position Control 25BYJ 412L

Product Detail Presentation

Micro Dc Geared Stepper Motor 25PM Linear Motor Valve For Precise Position Control 25BYJ 412L

Micro Dc Geared Stepper Motor 25PM Linear Motor Valve For Precise Position Control 25BYJ 412L

Micro Dc Geared Stepper Motor 25PM Linear Motor Valve For Precise Position Control 25BYJ 412L
