ISO9001 Small Permanent Magnet Motor 1.5V 3V 6V 120rpm 500 Rpm DC Geared Motor
ISO9001 Small Permanent Magnet Motor 1.5V 3V 6V 120rpm 500 Rpm DC Geared Motor
ISO9001 Small Permanent Magnet Motor 1.5V 3V 6V 120rpm 500 Rpm DC Geared Motor
ISO9001 Small Permanent Magnet Motor 1.5V 3V 6V 120rpm 500 Rpm DC Geared Motor
ISO9001 Small Permanent Magnet Motor 1.5V 3V 6V 120rpm 500 Rpm DC Geared Motor
ISO9001 Small Permanent Magnet Motor 1.5V 3V 6V 120rpm 500 Rpm DC Geared Motor
ISO9001 Small Permanent Magnet Motor 1.5V 3V 6V 120rpm 500 Rpm DC Geared Motor
ISO9001 Small Permanent Magnet Motor 1.5V 3V 6V 120rpm 500 Rpm DC Geared Motor
ISO9001 Small Permanent Magnet Motor 1.5V 3V 6V 120rpm 500 Rpm DC Geared Motor
ISO9001 Small Permanent Magnet Motor 1.5V 3V 6V 120rpm 500 Rpm DC Geared Motor
Specifications
Brand Name :
TYHE
Model Number :
TJZ37RO
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
37mm
Voltage :
3-24V
Speed :
60rpm customized
Torque :
2.5N.m
Gear material :
Powder metallurgy gear, steel gears
Commutation :
Brush brushes brushed
Type :
Gear Motor, Small Micro Motor
Keywords :
Powerful Gearmotor 1.5v 3v 6v 12 V 24v 1rpm 500 Rpm 120rpm Small Dc Geared Motor Ce Rohs
Description

Products Description

Powerful Gearmotor 1.5v 3v 6v 12 V 24v 1rpm 500 Rpm 120rpm Small Dc Geared Motor Ce Rohs

2D drawing

ISO9001 Small Permanent Magnet Motor 1.5V 3V 6V 120rpm 500 Rpm DC Geared Motor


ISO9001 Small Permanent Magnet Motor 1.5V 3V 6V 120rpm 500 Rpm DC Geared Motor

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
ZY3864 12 5000 300 4000 1.10 19.70 8.25 62.51 59.10 6.50
ZY3864 12 6000 380 4800 1.37 20.30 10.20 62.15 60.90 7.98
ZY3864 24 4500 130 3600 0.46 18.20 6.86 62.83 54.60 2.60
ZY3864 24 5000 160 4000 0.55 19.50 8.17 61.88 58.50 3.10
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 12V-5000RPM Input 12V-6000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
22.5 81 4.6 869.6 6.68 73.40 220.21 1043.5 8.26 75.64 226.91
22.5 81 5.9 678.0 6.68 94.15 282.44 813.6 8.26 97.01 291.04
22.5 73 8.4 476.2 6.0 120.80 362.40 571.43 7.45 124.48 373.44
22.5 73 10.6 377.4 6.0 152.44 457.32 452.83 7.45 157.08 471.24
22.5 73 13.5 296.3 6.0 194.14 582.43 355.56 7.45 200.06 600.17
24.5 65.6 19.3 207.3 5.41 249.42 748.25 248.7 6.69 257.01 771.04
24.5 65.6 24.4 163.9 5.41 315.33 945.98 196.7 6.69 324.93 974.79
24.5 65.6 31.6 126.6 5.41 408.37 1225.12 151.9 6.69 420.81 1262.43
26.5 59 45.0 88.9 4.9 523.04 1569.11 106.67 6.02 538.97 1616.90
26.5 59 57.0 70.2 4.9 662.51 1987.53 84.21 6.02 682.69 2048.07
26.5 59 73.6 54.3 4.9 855.45 2500.00 65.22 6.02 881.51 2500.00
29.5 53 105.0 38.1 4.37 1096.31 2500.00 45.7 5.41 1129.70 2500.00
29.5 53 133.0 30.1 4.37 1388.65 2500.00 36.1 5.41 1430.95 2500.00
29.5 53 172.0 23.3 4.37 1795.85 2500.00 27.9 5.41 1850.55 2500.00
32.5 47.8 245.0 16.3 3.9 2307.07 2500.00 19.59 4.88 2377.33 2500.00
32.5 47.8 310.0 12.9 3.9 2500.00 2500.00 15.48 4.88 2500.00 2500.00
32.5 47.8 401.0 10.0 3.9 2500.00 2500.00 11.97 4.88 2500.00 2500.00
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 24V-4500RPM Input 24V-5000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
22.5 81 4.6 782.6 5.56 67.81 203.44 869.6 6.62 72.66 217.97
22.5 81 5.9 610.2 5.56 86.98 260.93 678.0 6.62 93.19 279.57
22.5 73 8.4 428.6 5.0 111.60 334.81 476.19 5.96 119.57 358.72
22.5 73 10.6 339.6 5.0 140.83 422.49 377.36 5.96 150.89 452.67
22.5 73 13.5 266.7 5.0 179.36 538.08 296.30 5.96 192.17 576.52
24.5 65.6 19.3 186.5 4.50 230.43 691.28 207.3 5.36 246.89 740.66
24.5 65.6 24.4 147.5 4.50 291.32 873.95 163.9 5.36 312.12 936.37
24.5 65.6 31.6 113.9 4.50 377.28 1131.84 126.6 5.36 404.23 1212.68
26.5 59 45.0 80.0 4.0 483.21 1449.63 88.89 4.82 517.73 1553.18
26.5 59 57.0 63.2 4.0 612.07 1836.20 70.18 4.82 655.79 1967.36
26.5 59 73.6 48.9 4.0 790.32 2370.95 54.35 4.82 846.77 2500.00
29.5 53 105.0 34.3 3.64 1012.83 2500.00 38.1 4.33 1085.18 2500.00
29.5 53 133.0 27.1 3.64 1282.92 2500.00 30.1 4.33 1374.56 2500.00
29.5 53 172.0 20.9 3.64 1659.11 2500.00 23.3 4.33 1777.62 2500.00
32.5 47.8 245.0 14.7 3.3 2131.40 2500.00 16.33 3.90 2283.65 2500.00
32.5 47.8 310.0 11.6 3.3 2500.00 2500.00 12.90 3.90 2500.00 2500.00
32.5 47.8 401.0 9.0 3.3 2500.00 2500.00 9.98 3.90 2500.00 2500.00

Please let us know your requirements and we will provide you with transmission solutions.
