PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear Motor
PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear Motor
PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear Motor
PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear Motor
PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear Motor
PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear Motor
PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear Motor
PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear Motor
PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear Motor
PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear Motor
PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear Motor
PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear Motor
Specifications
Brand Name :
TYHE
Model Number :
TJP37RQ
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
37mm diameter
Voltage :
12v 24v or customize
Speed :
5000rpm or Customized
Torque :
1.5N.m
Commutation :
Brush /brushes /brushed
Type :
DC gear motor, micro motor
Keywords :
PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 watt DC Gear Motor
Description

Products Description

Speed Adjustable Th4260bl 6v 12v 24v 5000 Rpm High Torque Low Rpm 9.6w High Speed Brushless Dc Motor For Drill Tool

2D drawing

PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear Motor


PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear Motor

Specifications

Model Rated Voltage (V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output Power eff Torque Current
rpm mA rpm A mN.m W % mN.m A
4260BL 12 3000 230 2400 0.90 27.50 6.91 64.13 82.50 5.53
4260BL 12 7000 500 5600 2.00 27.40 16.07 66.95 82.20 12.50
4260BL 24 3000 110 2400 0.44 28.30 7.11 67.35 84.90 2.75
4260BL 24 5000 190 4000 0.76 28.50 11.94 65.45 85.50 4.75
4260BL 24 7000 250 5600 1.00 28.30 16.59 69.14 84.90 6.25

PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear Motor

Please let us know your requirements and we will provide you with transmission solutions.

PMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear MotorPMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear MotorPMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear MotorPMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear MotorPMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear MotorPMDC 37mm 6v 12v 20v 24v 80 Rpm 20kg 30kg Load Permanent Magnet High Torque High Rpm 3w 5 Watt DC Gear Motor
