Specifications
Brand Name :
TYHE
Model Number :
TJP37FH
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
37mm square cover
Voltage :
3-24v or customized
Speed :
25rpm customized
Torque :
1.65N.m
Gear material :
Powder metallurgy, Steel
Commutation :
Brush
Type :
DC Gear Motor, Micro Motor
Keywords :
Low Noise D37 3 Volt 6v 12v 24v 25 Rpm High Speed 1000rpm 0.5w 10kg Cm Mini Dc Gear Motor For Led Light
Description

Products Description

Low Noise D37 3 Volt 6v 12v 24v 25 Rpm High Speed 1000rpm 0.5w 10kg Cm Mini Dc Gear Motor For Led Light

2D drawing

D37mm 3 Volt 6V 0.5w 10kg Cm Micro DC Gear Motor 25Rpm 1000rpm Low Noise


D37mm 3 Volt 6V 0.5w 10kg Cm Micro DC Gear Motor 25Rpm 1000rpm Low Noise

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
ZY3324 6 7000 80 5600 0.37 2.35 1.38 62.78 7.05 2.95
ZY3324 12 5000 32 4000 0.12 2.12 0.89 64.07 6.36 0.81
ZY3324 24 3500 12 2800 0.03 1.78 0.52 62.73 5.34 0.20
ZY3324 24 5000 17 4000 0.06 2.27 0.95 63.73 6.81 0.44
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 6V-7000RPM Input 12V-5000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
25.5 81 8.2 682.9 1.12 15.61 46.83 487.8 0.72 14.08 42.24
25.5 81 9.5 589.5 1.12 18.08 54.25 421.1 0.72 16.31 48.94
25.5 73 14.7 381.0 1.01 25.22 75.65 272.1 0.65 22.75 68.25
25.5 73 22.3 251.1 1.01 38.26 114.77 179.4 0.65 34.51 103.53
25.5 73 24.5 228.6 1.01 42.03 126.09 163.3 0.65 37.92 113.75
27.5 65.6 27.2 205.9 0.90 41.93 125.79 147.1 0.58 37.83 113.48
27.5 65.6 34.4 162.8 0.90 53.03 159.09 116.3 0.58 47.84 143.52
27.5 65.6 44.5 125.8 0.90 68.60 205.80 89.9 0.58 61.89 185.66
27.5 65.6 52.0 107.7 0.90 80.16 240.49 76.9 0.58 72.32 216.95
27.5 65.6 57.0 98.2 0.90 87.87 263.61 70.2 0.58 79.27 237.81
27.5 65.6 63.0 88.9 0.90 97.12 291.36 63.5 0.58 87.62 262.85
29.5 59 80.3 69.7 0.81 111.34 334.01 49.8 0.52 100.44 301.32
29.5 59 104.0 53.8 0.81 144.20 432.59 38.5 0.52 130.08 390.25
29.5 59 121.0 46.3 0.81 167.77 503.30 33.1 0.52 151.35 454.04
29.5 59 134.0 41.8 0.81 185.79 557.37 29.9 0.52 167.61 502.82
29.5 59 147.0 38.1 0.81 203.82 611.45 27.2 0.52 183.87 551.60
29.5 59 162.0 34.6 0.81 224.61 673.84 24.7 0.52 202.63 607.89
32.5 53 187.0 29.9 0.73 232.91 698.73 21.4 0.47 210.11 630.34
32.5 53 242.0 23.1 0.73 301.41 904.23 16.5 0.47 271.91 815.73
32.5 53 283.0 19.8 0.73 352.48 1057.43 14.1 0.47 317.98 953.94
32.5 53 312.0 17.9 0.73 388.60 1165.79 12.8 0.47 350.56 1051.69
32.5 53 344.0 16.3 0.73 428.45 1285.36 11.6 0.47 386.52 1159.56
32.5 53 379.0 14.8 0.73 472.04 1416.13 10.6 0.47 425.84 1277.53
32.5 53 417.0 13.4 0.73 519.37 1558.12 9.6 0.47 468.54 1405.62
35.5 47.8 437.0 12.8 0.66 490.88 1472.65 9.2 0.42 442.84 1328.51
35.5 47.8 565.0 9.9 0.66 634.66 1903.99 7.1 0.42 572.55 1717.65
35.5 47.8 660.0 8.5 0.66 741.38 2224.13 6.1 0.42 668.82 2006.45
35.5 47.8 728.0 7.7 0.66 817.76 2453.29 5.5 0.42 737.73 2213.18
35.5 47.8 802.0 7.0 0.66 900.89 2500.00 5.0 0.42 812.71 2438.14
35.5 47.8 884.0 6.3 0.66 993.00 2500.00 4.5 0.42 895.81 2500.00
35.5 47.8 974.0 5.7 0.66 1094.09 2500.00 4.1 0.42 987.01 2500.00
35.5 47.8 1073.0 5.2 0.66 1205.30 2500.00 3.7 0.42 1087.34 2500.00
32.5 43 1540.0 3.6 0.59 1556.17 2500.00 2.6 0.38 1403.86 2500.00
32.5 43 1698.0 3.3 0.59 1715.83 2500.00 2.4 0.38 1547.90 2500.00
32.5 43 1871.0 3.0 0.59 1890.65 2500.00 2.1 0.38 1705.60 2500.00
32.5 43 2062.0 2.7 0.59 2083.65 2500.00 1.9 0.38 1879.72 2500.00
32.5 43 2272.0 2.5 0.59 2295.86 2500.00 1.8 0.38 2071.16 2500.00
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 24V-3500RPM Input 24V-5000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
25.5 81 8.2 341.5 0.42 11.82 35.47 487.8 0.77 15.08 45.23
25.5 81 9.5 294.7 0.42 13.70 41.09 421.1 0.77 17.47 52.40
25.5 73 14.7 190.5 0.38 19.10 57.30 272.1 0.69 24.36 73.08
25.5 73 22.3 125.6 0.38 28.98 86.93 179.4 0.69 36.95 110.86
25.5 73 24.5 114.3 0.38 31.84 95.51 163.3 0.69 40.60 121.80
27.5 65.6 27.2 102.9 0.34 31.76 95.28 147.1 0.62 40.50 121.51
27.5 65.6 34.4 81.4 0.34 40.17 120.50 116.3 0.62 51.23 153.68
27.5 65.6 44.5 62.9 0.34 51.96 155.89 89.9 0.62 66.27 198.80
27.5 65.6 52.0 53.8 0.34 60.72 182.16 76.9 0.62 77.43 232.30
27.5 65.6 57.0 49.1 0.34 66.56 199.67 70.2 0.62 84.88 254.64
27.5 65.6 63.0 44.4 0.34 73.56 220.69 63.5 0.62 93.81 281.44
29.5 59 80.3 34.9 0.31 84.33 252.99 49.8 0.56 107.55 322.64
29.5 59 104.0 26.9 0.31 109.22 327.66 38.5 0.56 139.29 417.86
29.5 59 121.0 23.1 0.31 127.07 381.22 33.1 0.56 162.06 486.17
29.5 59 134.0 20.9 0.31 140.73 422.18 29.9 0.56 179.47 538.40
29.5 59 147.0 19.0 0.31 154.38 463.14 27.2 0.56 196.88 590.63
29.5 59 162.0 17.3 0.31 170.13 510.40 24.7 0.56 216.97 650.90
32.5 53 187.0 15.0 0.28 176.42 529.25 21.4 0.50 224.98 674.94
32.5 53 242.0 11.6 0.28 228.30 684.91 16.5 0.50 291.15 873.45
32.5 53 283.0 9.9 0.28 266.98 800.95 14.1 0.50 340.48 1021.43
32.5 53 312.0 9.0 0.28 294.34 883.02 12.8 0.50 375.37 1126.10
32.5 53 344.0 8.1 0.28 324.53 973.59 11.6 0.50 413.87 1241.60
32.5 53 379.0 7.4 0.28 357.55 1072.65 10.6 0.50 455.97 1367.92
32.5 53 417.0 6.7 0.28 393.40 1180.19 9.6 0.50 501.69 1505.08
35.5 47.8 437.0 6.4 0.25 371.82 1115.45 9.2 0.45 474.17 1422.51
35.5 47.8 565.0 5.0 0.25 480.72 1442.17 7.1 0.45 613.06 1839.18
35.5 47.8 660.0 4.2 0.25 561.55 1684.66 6.1 0.45 716.14 2148.42
35.5 47.8 728.0 3.8 0.25 619.41 1858.23 5.5 0.45 789.92 2369.77
35.5 47.8 802.0 3.5 0.25 682.37 2047.12 5.0 0.45 870.22 2500.00
35.5 47.8 884.0 3.2 0.25 752.14 2256.43 4.5 0.45 959.19 2500.00
35.5 47.8 974.0 2.9 0.25 828.72 2486.15 4.1 0.45 1056.85 2500.00
35.5 47.8 1073.0 2.6 0.25 912.95 2500.00 3.7 0.45 1164.27 2500.00
32.5 43 1540.0 1.8 0.22 1178.72 2500.00 2.6 0.41 1503.19 2500.00
32.5 43 1698.0 1.6 0.22 1299.65 2500.00 2.4 0.41 1657.42 2500.00
32.5 43 1871.0 1.5 0.22 1432.06 2500.00 2.1 0.41 1826.28 2500.00
32.5 43 2062.0 1.4 0.22 1578.25 2500.00 1.9 0.41 2012.72 2500.00
32.5 43 2272.0 1.2 0.22 1738.99 2500.00 1.8 0.41 2217.70 2500.00

Please let us know your requirements and we will provide you with transmission solutions.
