Low Backlash Steel Gear Chain 60mm Diameter High Power 40watts 12v 24v Dc Gear Reduction Motor
Low Backlash Steel Gear Chain 60mm Diameter High Power 40watts 12v 24v Dc Gear Reduction Motor
Low Backlash Steel Gear Chain 60mm Diameter High Power 40watts 12v 24v Dc Gear Reduction Motor
Low Backlash Steel Gear Chain 60mm Diameter High Power 40watts 12v 24v Dc Gear Reduction Motor
Low Backlash Steel Gear Chain 60mm Diameter High Power 40watts 12v 24v Dc Gear Reduction Motor
Low Backlash Steel Gear Chain 60mm Diameter High Power 40watts 12v 24v Dc Gear Reduction Motor
Low Backlash Steel Gear Chain 60mm Diameter High Power 40watts 12v 24v Dc Gear Reduction Motor
Low Backlash Steel Gear Chain 60mm Diameter High Power 40watts 12v 24v Dc Gear Reduction Motor
Low Backlash Steel Gear Chain 60mm Diameter High Power 40watts 12v 24v Dc Gear Reduction Motor
Low Backlash Steel Gear Chain 60mm Diameter High Power 40watts 12v 24v Dc Gear Reduction Motor
Specifications
Brand Name :
TYHE
Model Number :
TJZ60RT
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
60mm
Voltage :
12-24V
Speed :
Customized
Torque :
10N.m
Gear material :
Steel
Commutation :
Brush brushes brushed
Type :
Gear Motor, Micro Motor
Usage :
kitchen appliances
Keywords :
Low Backlash Steel Gear Chain 60mm Diameter High Power 40watts 12v 24v Dc Gear Reduction Motor
Description

Products Description

Low Backlash Steel Gear Chain 60mm Diameter High Power 40watts 12v 24v Dc Gear Reduction Motor

2D drawing

Low Backlash Steel Gear Chain 60mm Diameter High Power 40watts 12v 24v Dc Gear Reduction Motor


Low Backlash Steel Gear Chain 60mm Diameter High Power 40watts 12v 24v Dc Gear Reduction Motor

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
RS775 12 5000 580 4000 1.77 31.60 13.24 62.31 94.80 10.80
RS775 12 7000 760 5600 2.81 38.00 22.28 66.16 114.00 20.00
RS775 24 3500 160 2800 0.59 29.50 8.65 61.08 88.50 4.20
RS775 24 5000 230 4000 0.84 31.00 12.98 64.15 93.00 5.98
DC Motor With Gearbox Technical Data (1.25M)
Gearbox parameters 12V-5000RPM Input 12V-7000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
28.5 81 5.8 689.7 10.72 148.46 445.37 965.5 18.05 178.52 535.57
28.5 81 6.8 588.2 10.72 174.05 522.16 823.5 18.05 209.30 627.91
28.5 81 7.9 506.3 10.72 202.21 606.63 708.9 18.05 243.16 729.49
28.5 81 8.8 454.5 10.72 225.24 675.73 636.4 18.05 270.86 812.59
28.5 81 9.8 408.2 10.72 250.84 752.52 571.4 18.05 301.64 904.93
28.5 81 10.5 381.0 10.72 268.76 806.27 533.3 18.05 323.19 969.57
28.5 81 11.6 344.8 10.72 296.91 890.74 482.8 18.05 357.05 1071.14
33.5 73 18.6 215.1 9.66 429.06 1287.19 301.1 16.27 515.96 1547.89
33.5 73 24.0 166.7 9.66 553.63 1660.90 233.3 16.27 665.76 1997.28
33.5 73 28.0 142.9 9.66 645.90 1937.71 200.0 16.27 776.72 2330.16
33.5 73 33.6 119.0 9.66 775.08 2325.25 166.7 16.27 932.06 2796.19
36 65.6 60.0 66.7 8.68 1243.78 3731.33 93.3 14.62 1495.68 4487.04
36 65.6 71.0 56.3 8.68 1471.80 4415.40 78.9 14.62 1769.89 5309.66
36 65.6 83.0 48.2 8.68 1720.56 5161.67 67.5 14.62 2069.02 6207.07
36 65.6 91.0 44.0 8.68 1886.39 5659.18 61.5 14.62 2268.45 6805.34
36 65.6 100.0 40.0 8.68 2072.96 6218.88 56.0 14.62 2492.80 7478.40
36 65.6 108.0 37.0 8.68 2238.80 6716.39 51.9 14.62 2692.22 8076.67
36 65.6 118.0 33.9 8.68 2446.09 7338.28 47.5 14.62 2941.50 8824.51
40 59 191.0 20.9 7.81 3561.00 10683.01 29.3 13.15 4282.22 12846.66
40 59 226.0 17.7 7.81 4213.54 12640.63 24.8 13.15 5066.92 15000.00
40 59 265.0 15.1 7.81 4940.66 14821.98 21.1 13.15 5941.30 15000.00
40 59 288.0 13.9 7.81 5369.47 15000.00 19.4 13.15 6456.96 15000.00
40 59 345.0 11.6 7.81 6432.18 15000.00 16.2 13.15 7734.90 15000.00
40 59 379.0 10.6 7.81 7066.08 15000.00 14.8 13.15 8497.18 15000.00
DC Motor With Gearbox Technical Data (1.25M)
Gearbox parameters 24V-3500RPM Input 24V-5000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
28.5 81 5.8 482.8 7.01 138.59 415.77 689.7 10.52 145.64 436.91
28.5 81 6.8 411.8 7.01 162.49 487.46 588.2 10.52 170.75 512.24
28.5 81 7.9 354.4 7.01 188.77 566.31 506.3 10.52 198.37 595.11
28.5 81 8.8 318.2 7.01 210.28 630.83 454.5 10.52 220.97 662.90
28.5 81 9.8 285.7 7.01 234.17 702.51 408.2 10.52 246.08 738.23
28.5 81 10.5 266.7 7.01 250.90 752.69 381.0 10.52 263.66 790.97
28.5 81 11.6 241.4 7.01 277.18 831.55 344.8 10.52 291.28 873.83
33.5 73 18.6 150.5 6.31 400.55 1201.65 215.1 9.48 420.92 1262.75
33.5 73 24.0 116.7 6.31 516.84 1550.52 166.7 9.48 543.12 1629.36
33.5 73 28.0 100.0 6.31 602.98 1808.94 142.9 9.48 633.64 1900.92
33.5 73 33.6 83.3 6.31 723.58 2170.73 119.0 9.48 760.37 2281.10
36 65.6 60.0 46.7 5.67 1161.12 3483.36 66.7 8.52 1220.16 3660.48
36 65.6 71.0 39.4 5.67 1373.99 4121.98 56.3 8.52 1443.86 4331.57
36 65.6 83.0 33.7 5.67 1606.22 4818.65 48.2 8.52 1687.89 5063.66
36 65.6 91.0 30.8 5.67 1761.03 5283.10 44.0 8.52 1850.58 5551.73
36 65.6 100.0 28.0 5.67 1935.20 5805.60 40.0 8.52 2033.60 6100.80
36 65.6 108.0 25.9 5.67 2090.02 6270.05 37.0 8.52 2196.29 6588.86
36 65.6 118.0 23.7 5.67 2283.54 6850.61 33.9 8.52 2399.65 7198.94
40 59 191.0 14.7 5.10 3324.36 9973.07 20.9 7.66 3493.39 10480.17
40 59 226.0 12.4 5.10 3933.53 11800.59 17.7 7.66 4133.54 12400.62
40 59 265.0 10.6 5.10 4612.33 13836.98 15.1 7.66 4846.85 14540.55
40 59 288.0 9.7 5.10 5012.64 15000.00 13.9 7.66 5267.52 15000.00
40 59 345.0 8.1 5.10 6004.73 15000.00 11.6 7.66 6310.05 15000.00
40 59 379.0 7.4 5.10 6596.50 15000.00 10.6 7.66 6931.91 15000.00

Please let us know your requirements and we will provide you with transmission solutions.

Low Backlash Steel Gear Chain 60mm Diameter High Power 40watts 12v 24v Dc Gear Reduction Motor

Low Backlash Steel Gear Chain 60mm Diameter High Power 40watts 12v 24v Dc Gear Reduction Motor
