Specifications
Brand Name :
TYHE
Model Number :
TJP60FR
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
60*60mm square cover
Voltage :
24v or customized
Speed :
50rpm Customized
Torque :
10N.m
Gear material :
Steel gears
Commutation :
brushed
Type :
DC Gear Motor, Mini Motor
Keywords :
Customizable Oem Odm Od60mm 24v 24 Volt 12v 50rpm 60w Dc Gear Motor Ce Rohs
Description

Products Description

Customizable Oem Odm Od60mm 24v 24 Volt 12v 50rpm 60w Dc Gear Motor Ce Rohs

2D drawing

OEM ODM Square Cover 60W DC Spur Gear Motor 24 Volt 12V 50rpm


OEM ODM Square Cover 60W DC Spur Gear Motor 24 Volt 12V 50rpm

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
ZY5078 12 4000 560 3200 2.17 49.32 16.53 63.37 147.96 16.00
ZY5078 12 5500 850 4400 3.30 55.23 25.45 64.26 165.69 24.30
ZY5078 12 6000 1030 4800 4.00 60.19 30.25 63.11 180.57 29.40
ZY5078 12 6500 1300 5200 4.98 69.52 37.85 63.30 208.56 36.40
DC Motor With Gearbox Technical Data (1.25M)
Gearbox parameters 12V-4000RPM Input 12V-5500RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
28.5 81 6.5 492.3 13.39 259.67 779.01 676.9 20.61 290.79 872.36
28.5 81 7.6 421.1 13.39 303.61 910.84 578.9 20.61 340.00 1019.99
28.5 81 8.3 385.5 13.39 331.58 994.74 530.1 20.61 371.31 1113.93
28.5 81 9.9 323.2 13.39 395.50 1186.49 444.4 20.61 442.89 1328.67
28.5 81 10.8 296.3 13.39 431.45 1294.35 407.4 20.61 483.15 1449.46
28.5 81 12.8 250.0 13.39 511.35 1534.05 343.8 20.61 572.62 1717.87
28.5 81 14.1 227.0 13.39 563.28 1689.85 312.1 20.61 630.78 1892.35
33.5 73 20.7 154.6 12.06 745.27 2235.82 212.6 18.58 834.58 2503.74
33.5 73 24.3 131.7 12.06 874.89 2624.66 181.1 18.58 979.72 2939.17
33.5 73 26.4 121.2 12.06 950.50 2851.49 166.7 18.58 1064.39 3193.18
33.5 73 27 118.5 12.06 972.10 2916.29 163.0 18.58 1088.58 3265.75
33.5 73 31.5 101.6 12.06 1134.11 3402.34 139.7 18.58 1270.01 3810.04
33.5 73 34.3 93.3 12.06 1234.92 3704.77 128.3 18.58 1382.90 4148.71
33.5 73 34.7 92.2 12.06 1249.32 3747.97 126.8 18.58 1399.03 4197.09
33.5 73 41 78.0 12.06 1476.15 4428.44 107.3 18.58 1653.03 4959.10
33.5 73 45 71.1 12.06 1620.16 4860.49 97.8 18.58 1814.31 5442.92
36 65.6 66.3 48.3 10.84 2145.06 6435.19 66.4 16.69 2402.11 7206.32
36 65.6 77.7 41.2 10.84 2513.90 7541.70 56.6 16.69 2815.14 8445.42
36 65.6 86 37.2 10.84 2782.44 8347.31 51.2 16.69 3115.86 9347.57
36 65.6 101 31.7 10.84 3267.75 9803.24 43.6 16.69 3659.32 10977.96
36 65.6 111 28.8 10.84 3591.29 10773.86 39.6 16.69 4021.63 12064.88
36 65.6 131 24.4 10.84 4238.36 12715.09 33.6 16.69 4746.25 14238.74
36 65.6 144 22.2 10.84 4658.96 13976.89 30.6 16.69 5217.25 15000.00
40 59 212 15.1 9.75 6168.95 15000.00 20.8 15.01 6908.17 15000.00
40 59 249 12.9 9.75 7245.60 15000.00 17.7 15.01 8113.84 15000.00
40 59 270 11.9 9.75 7856.68 15000.00 16.3 15.01 8798.14 15000.00
40 59 276 11.6 9.75 8031.27 15000.00 15.9 15.01 8993.65 15000.00
40 59 323 9.9 9.75 9398.91 15000.00 13.6 15.01 10525.18 15000.00
40 59 351 9.1 9.75 10213.68 15000.00 12.5 15.01 11437.58 15000.00
40 59 355 9.0 9.75 10330.07 15000.00 12.4 15.01 11567.92 15000.00
40 59 420 7.6 9.75 12221.50 15000.00 10.5 15.01 13685.99 15000.00
40 59 462 6.9 9.75 13443.65 15000.00 9.5 15.01 15000.00 15000.00
DC Motor With Gearbox Technical Data (1.25M)
Gearbox parameters 12V-6000RPM Input 12V-6500RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
28.5 81 6.5 738.5 24.50 316.90 950.70 800.0 30.66 366.02 1098.07
28.5 81 7.6 631.6 24.50 370.53 1111.59 684.2 30.66 427.97 1283.90
28.5 81 8.3 578.3 24.50 404.66 1213.97 626.5 30.66 467.38 1402.15
28.5 81 9.9 484.8 24.50 482.66 1447.99 525.3 30.66 557.48 1672.44
28.5 81 10.8 444.4 24.50 526.54 1579.63 481.5 30.66 608.16 1824.48
28.5 81 12.8 375.0 24.50 624.05 1872.15 406.3 30.66 720.78 2162.35
28.5 81 14.1 340.4 24.50 687.43 2062.29 368.8 30.66 793.99 2381.96
33.5 73 20.7 231.9 22.08 909.53 2728.59 251.2 27.63 1050.52 3151.55
33.5 73 24.3 197.5 22.08 1067.71 3203.13 214.0 27.63 1233.22 3699.65
33.5 73 26.4 181.8 22.08 1159.98 3479.95 197.0 27.63 1339.79 4019.37
33.5 73 27 177.8 22.08 1186.34 3559.03 192.6 27.63 1370.24 4110.72
33.5 73 31.5 152.4 22.08 1384.07 4152.21 165.1 27.63 1598.61 4795.84
33.5 73 34.3 139.9 22.08 1507.10 4521.29 151.6 27.63 1740.71 5222.13
33.5 73 34.7 138.3 22.08 1524.67 4574.02 149.9 27.63 1761.01 5283.03
33.5 73 41 117.1 22.08 1801.49 5404.46 126.8 27.63 2080.73 6242.20
33.5 73 45 106.7 22.08 1977.24 5931.72 115.6 27.63 2283.73 6851.20
36 65.6 66.3 72.4 19.85 2617.83 7853.49 78.4 24.83 3023.62 9070.86
36 65.6 77.7 61.8 19.85 3067.96 9203.87 66.9 24.83 3543.52 10630.55
36 65.6 86 55.8 19.85 3395.68 10187.04 60.5 24.83 3922.04 11766.12
36 65.6 101 47.5 19.85 3987.95 11963.85 51.5 24.83 4606.12 13818.35
36 65.6 111 43.2 19.85 4382.80 13148.39 46.8 24.83 5062.17 15000.00
36 65.6 131 36.6 19.85 5172.49 15000.00 39.7 24.83 5974.27 15000.00
36 65.6 144 33.3 19.85 5685.79 15000.00 36.1 24.83 6567.14 15000.00
40 59 212 22.6 17.85 7528.57 15000.00 24.5 22.33 8695.56 15000.00
40 59 249 19.3 17.85 8842.51 15000.00 20.9 22.33 10213.18 15000.00
40 59 270 17.8 17.85 9588.27 15000.00 19.3 22.33 11074.54 15000.00
40 59 276 17.4 17.85 9801.34 15000.00 18.8 22.33 11320.64 15000.00
40 59 323 14.9 17.85 11470.41 15000.00 16.1 22.33 13248.43 15000.00
40 59 351 13.7 17.85 12464.75 15000.00 14.8 22.33 14396.90 15000.00
40 59 355 13.5 17.85 12606.80 15000.00 14.6 22.33 14560.96 15000.00
40 59 420 11.4 17.85 14915.08 15000.00 12.4 22.33 15000.00 15000.00
40 59 462 10.4 17.85 15000.00 15000.00 11.3 22.33 15000.00 15000.00

Please let us know your requirements and we will provide you with transmission solutions.
