37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque
37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque
37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque
37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque
37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque
37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque
37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque
37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque
37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque
37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque
Specifications
Brand Name :
TYHE
Model Number :
TJP37RK
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
37mm
Voltage :
3-24V
Speed :
20rpm 25rpm 30rpm 50rpm or Customized
Torque :
1.5N.m
Gear material :
Powder metallurgy, steel
Commutation :
Brush
Type :
Gear Motor, Micro Motor
Usage :
Popcorn machine
Keywords :
37GB3530R 37mm Powder Gears 6v 7v 12v 18kg Torque Brushed Dc Gear Motor
Description

Products Description

37GB3530R 37mm Powder Gears 6v 7v 12v 18kg Torque Brushed Dc Gear Motor

2D drawing

37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque


37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
ZY3530 12 5500 60 4400 0.23 3.81 1.76 62.69 11.43 1.72
ZY3530 12 6500 65 5200 0.31 4.18 2.28 61.18 12.54 2.00
ZY3530 12 7300 67 5840 0.36 4.35 2.66 61.78 13.05 3.10
ZY3530 12 9000 90 7200 0.43 4.31 3.25 63.47 12.93 3.50
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 12V-5500RPM Input 12V-6500RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
22.5 81 6.5 676.9 1.42 20.06 60.18 800.0 1.84 22.01 66.02
22.5 81 7.6 578.9 1.42 23.45 70.36 684.2 1.84 25.73 77.20
22.5 73 9.3 473.1 1.28 25.87 77.60 559.1 1.66 28.38 85.13
22.5 73 11.8 372.9 1.28 32.82 98.46 440.7 1.66 36.01 108.02
22.5 73 15.2 289.5 1.28 42.28 126.83 342.1 1.66 46.38 139.14
22.5 73 20.4 215.7 1.28 56.74 170.22 254.9 1.66 62.25 186.75
24.5 65.6 27.5 160.0 1.15 68.73 206.20 189.1 1.49 75.41 226.22
24.5 65.6 35.6 123.6 1.15 88.98 266.93 146.1 1.49 97.62 292.85
24.5 65.6 41.6 105.8 1.15 103.97 311.92 125.0 1.49 114.07 342.21
24.5 65.6 57.7 76.3 1.15 144.21 432.64 90.1 1.49 158.22 474.65
26.5 59 73.4 59.9 1.04 165.00 494.99 70.8 1.34 181.02 543.06
26.5 59 83 53.0 1.04 186.58 559.73 62.7 1.34 204.69 614.08
26.5 59 97 45.4 1.04 218.05 654.14 53.6 1.34 239.22 717.66
26.5 59 111 39.6 1.04 249.52 748.55 46.8 1.34 273.75 821.24
26.5 59 119 37.0 1.04 267.50 802.50 43.7 1.34 293.48 880.43
26.5 59 130 33.8 1.04 292.23 876.68 40.0 1.34 320.61 961.82
29.5 53 194 22.7 0.93 391.74 1175.23 26.8 1.21 429.79 1289.36
29.5 53 226 19.5 0.93 456.36 1369.09 23.0 1.21 500.68 1502.04
29.5 53 259 17.0 0.93 523.00 1569.00 20.1 1.21 573.79 1721.37
29.5 53 277 15.9 0.93 559.35 1678.04 18.8 1.21 613.67 1841.00
29.5 53 303 14.5 0.93 611.85 1835.54 17.2 1.21 671.27 2013.80
29.5 53 316 13.9 0.93 638.10 1914.30 16.5 1.21 700.07 2100.20
29.5 53 346 12.7 0.93 698.68 2096.03 15.0 1.21 766.53 2299.59
29.5 53 382 11.5 0.93 771.37 2314.12 13.6 1.21 846.28 2500.00
32.5 47.8 452 9.7 0.84 823.17 2469.52 11.5 1.09 903.11 2500.00
32.5 47.8 528 8.3 0.84 961.58 2500.00 9.8 1.09 1054.97 2500.00
32.5 47.8 604 7.3 0.84 1099.99 2500.00 8.6 1.09 1206.82 2500.00
32.5 47.8 665 6.6 0.84 1211.08 2500.00 7.8 1.09 1328.70 2500.00
32.5 47.8 733 6.0 0.84 1334.92 2500.00 7.1 1.09 1464.56 2500.00
32.5 47.8 808 5.4 0.84 1471.51 2500.00 6.4 1.09 1614.42 2500.00
32.5 47.8 890 4.9 0.84 1620.85 2500.00 5.8 1.09 1778.26 2500.00
32.5 43 1232 3.6 0.75 2018.39 2500.00 4.2 0.98 2214.40 2500.00
32.5 43 1408 3.1 0.75 2306.73 2500.00 3.7 0.98 2500.00 2500.00
32.5 43 1552 2.8 0.75 2500.00 2500.00 3.4 0.98 2500.00 2500.00
32.5 43 1711 2.6 0.75 2500.00 2500.00 3.0 0.98 2500.00 2500.00
32.5 43 2077 2.1 0.75 2500.00 2500.00 2.5 0.98 2500.00 2500.00
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 12V-7300RPM Input 12V-9000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
22.5 81 6.5 898.5 2.15 22.90 68.71 1107.7 2.63 22.69 68.08
22.5 81 7.6 768.4 2.15 26.78 80.34 947.4 2.63 26.53 79.60
22.5 73 9.3 628.0 1.94 29.53 88.60 774.2 2.37 29.26 87.78
22.5 73 11.8 494.9 1.94 37.47 112.41 610.2 2.37 37.13 111.38
22.5 73 15.2 384.2 1.94 48.27 144.80 473.7 2.37 47.82 143.47
22.5 73 20.4 286.3 1.94 64.78 194.34 352.9 2.37 64.18 192.55
24.5 65.6 27.5 212.4 1.75 78.47 235.42 261.8 2.13 77.75 233.26
24.5 65.6 35.6 164.0 1.75 101.59 304.76 202.2 2.13 100.65 301.96
24.5 65.6 41.6 140.4 1.75 118.71 356.13 173.1 2.13 117.62 352.85
24.5 65.6 57.7 101.2 1.75 164.65 493.96 124.8 2.13 163.14 489.42
26.5 59 73.4 79.6 1.57 188.38 565.14 98.1 1.92 186.65 559.95
26.5 59 83 70.4 1.57 213.02 639.06 86.7 1.92 211.06 633.18
26.5 59 97 60.2 1.57 248.95 746.85 74.2 1.92 246.66 739.98
26.5 59 111 52.6 1.57 284.88 854.64 64.9 1.92 282.26 846.79
26.5 59 119 49.1 1.57 305.41 916.24 60.5 1.92 302.61 907.82
26.5 59 130 44.9 1.57 333.65 1000.94 55.4 1.92 330.58 991.73
29.5 53 194 30.1 1.41 447.27 1341.80 37.1 1.72 443.15 1329.46
29.5 53 226 25.8 1.41 521.04 1563.13 31.9 1.72 516.25 1548.76
29.5 53 259 22.5 1.41 597.12 1791.37 27.8 1.72 591.63 1774.90
29.5 53 277 21.1 1.41 638.62 1915.87 26.0 1.72 632.75 1898.25
29.5 53 303 19.3 1.41 698.57 2095.70 23.8 1.72 692.14 2076.43
29.5 53 316 18.5 1.41 728.54 2185.61 22.8 1.72 721.84 2165.52
29.5 53 346 16.9 1.41 797.70 2393.11 20.8 1.72 790.37 2371.10
29.5 53 382 15.3 1.41 880.70 2500.00 18.8 1.72 872.60 2500.00
32.5 47.8 452 12.9 1.27 939.84 2500.00 15.9 1.55 931.20 2500.00
32.5 47.8 528 11.1 1.27 1097.87 2500.00 13.6 1.55 1087.78 2500.00
32.5 47.8 604 9.7 1.27 1255.90 2500.00 11.9 1.55 1244.35 2500.00
32.5 47.8 665 8.8 1.27 1382.73 2500.00 10.8 1.55 1370.02 2500.00
32.5 47.8 733 8.0 1.27 1524.13 2500.00 9.8 1.55 1510.11 2500.00
32.5 47.8 808 7.2 1.27 1680.07 2500.00 8.9 1.55 1664.63 2500.00
32.5 47.8 890 6.6 1.27 1850.58 2500.00 8.1 1.55 1833.56 2500.00
32.5 43 1232 4.7 1.14 2304.46 2500.00 5.8 1.40 2283.27 2500.00
32.5 43 1408 4.1 1.14 2500.00 2500.00 5.1 1.40 2500.00 2500.00
32.5 43 1552 3.8 1.14 2500.00 2500.00 4.6 1.40 2500.00 2500.00
32.5 43 1711 3.4 1.14 2500.00 2500.00 4.2 1.40 2500.00 2500.00
32.5 43 2077 2.8 1.14 2500.00 2500.00 3.5 1.40 2500.00 2500.00

Please let us know your requirements and we will provide you with transmission solutions.

37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque

37GB3530R 18kg DC Spur Gear Motor 7V 6V DC Motor High Torque
