Specifications
Brand Name :
TYHE
Model Number :
TJZ42FG
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
42mm square cover
Voltage :
12-24V
Speed :
10-850rpm
Torque :
5N.m
Gear material :
Steel gears
Commutation :
Brush
Type :
DC Gear Motor, Micro Motor
Usage :
Welding machine
Keywords :
All steel gears Customizable 42mm Size 5N.m 24v 12v Dc Gear Motor Low Rpm
Description

Products Description

All Steel Gears Customizable 42mm Size 5N.M 24v 12v Dc Gear Motor Low Rpm

2D drawing

All steel gears Customizable 42mm Size 5N.m 24v 12v Dc Gear Motor Low Rpm


All steel gears Customizable 42mm Size 5N.m 24v 12v Dc Gear Motor Low Rpm

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
RS555 12 5700 290 4560 1.07 17.20 8.21 63.81 51.60 7.65
RS555 12 6500 310 5200 1.42 19.50 10.62 62.24 58.50 11.48
RS555 24 5000 150 4000 0.49 17.50 7.33 62.12 52.50 3.20
RS555 24 6000 160 4800 0.53 16.80 8.44 66.18 50.40 3.50
DC Motor With Gearbox Technical Data (0.7M)
Gearbox parameters 12V-5700RPM Input 12V-6500RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
25.7 81 2.5 1824.0 6.65 34.83 104.49 2080.0 8.60 39.49 118.46
25.7 81 3.1 1471.0 6.65 43.19 129.57 1677.4 8.60 48.96 146.89
25.7 81 3.8 1200.0 6.65 52.94 158.82 1368.4 8.60 60.02 180.06
25.7 81 4.8 950.0 6.65 66.87 200.62 1083.3 8.60 75.82 227.45
25.7 81 6.1 747.5 6.65 84.99 254.96 852.5 8.60 96.35 289.05
25.7 73 6.8 670.6 6.00 85.38 256.14 764.7 7.75 96.80 290.39
25.7 73 8.3 549.4 6.00 104.21 312.64 626.5 7.75 118.15 354.45
25.7 73 10.3 442.7 6.00 129.33 387.98 504.9 7.75 146.62 439.86
25.7 73 12.8 356.3 6.00 160.72 482.15 406.3 7.75 182.21 546.62
25.7 73 16.4 278.0 6.00 205.92 617.76 317.1 7.75 233.45 700.36
25.7 65.6 18.2 250.5 5.39 205.35 616.06 285.7 6.97 232.81 698.44
25.7 65.6 22.2 205.4 5.39 250.49 751.46 234.2 6.97 283.98 851.95
25.7 65.6 27.4 166.4 5.39 309.16 927.48 189.8 6.97 350.50 1051.50
25.7 65.6 34.2 133.3 5.39 385.89 1157.66 152.0 6.97 437.49 1312.46
25.7 65.6 43.8 104.1 5.39 494.20 1482.61 118.7 6.97 560.29 1680.87
29.5 59 48.6 93.8 4.85 493.19 1479.58 107.0 6.26 559.14 1677.43
29.5 59 59.3 76.9 4.85 601.78 1805.33 87.7 6.26 682.25 2046.74
29.5 59 73.0 62.5 4.85 740.80 2222.41 71.2 6.26 839.87 2519.60
29.5 59 91.2 50.0 4.85 925.50 2776.49 57.0 6.26 1049.26 3147.77
29.5 59 117.0 39.0 4.85 1187.32 3561.95 44.4 6.26 1346.09 4038.26
29.5 59 120.0 38.0 4.85 1217.76 3653.28 43.3 6.26 1380.60 4141.80
32.7 53 130.0 35.1 4.35 1185.08 3555.24 40.0 5.63 1343.55 4030.65
32.7 53 158.0 28.9 4.35 1440.33 4320.98 32.9 5.63 1632.93 4898.79
32.7 53 195.0 23.4 4.35 1777.62 5000.00 26.7 5.63 2015.33 5000.00
32.7 53 243.0 18.8 4.35 2215.19 5000.00 21.4 5.63 2511.41 5000.00
32.7 53 311.0 14.7 4.35 2835.08 5000.00 16.7 5.63 3214.19 5000.00
32.7 53 323.0 14.1 4.35 2944.47 5000.00 16.1 5.63 3338.21 5000.00
DC Motor With Gearbox Technical Data (0.7M)
Gearbox parameters 24V-5000RPM Input 24V-6000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
25.7 81 2.5 1600.0 5.94 35.44 106.31 1920.0 6.84 34.02 102.06
25.7 81 3.1 1290.3 5.94 43.94 131.83 1548.4 6.84 42.18 126.55
25.7 81 3.8 1052.6 5.94 53.87 161.60 1263.2 6.84 51.71 155.13
25.7 81 4.8 833.3 5.94 68.04 204.12 1000.0 6.84 65.32 195.96
25.7 81 6.1 655.7 5.94 86.47 259.40 786.9 6.84 83.01 249.03
25.7 73 6.8 588.2 5.35 86.87 260.61 705.9 6.16 83.40 250.19
25.7 73 8.3 481.9 5.35 106.03 318.10 578.3 6.16 101.79 305.37
25.7 73 10.3 388.3 5.35 131.58 394.75 466.0 6.16 126.32 378.96
25.7 73 12.8 312.5 5.35 163.52 490.56 375.0 6.16 156.98 470.94
25.7 73 16.4 243.9 5.35 209.51 628.53 292.7 6.16 201.13 603.39
25.7 65.6 18.2 219.8 4.81 208.94 626.81 263.7 5.54 200.58 601.74
25.7 65.6 22.2 180.2 4.81 254.86 764.57 216.2 5.54 244.66 733.99
25.7 65.6 27.4 146.0 4.81 314.55 943.66 175.2 5.54 301.97 905.91
25.7 65.6 34.2 117.0 4.81 392.62 1177.85 140.4 5.54 376.91 1130.73
25.7 65.6 43.8 91.3 4.81 502.82 1508.47 109.6 5.54 482.71 1448.13
29.5 59 48.6 82.3 4.32 501.80 1505.39 98.8 4.98 481.72 1445.17
29.5 59 59.3 67.5 4.32 612.27 1836.82 80.9 4.98 587.78 1763.34
29.5 59 73.0 54.8 4.32 753.73 2261.18 65.8 4.98 723.58 2170.73
29.5 59 91.2 43.9 4.32 941.64 2824.92 52.6 4.98 903.97 2711.92
29.5 59 117.0 34.2 4.32 1208.03 3624.08 41.0 4.98 1159.70 3479.11
29.5 59 120.0 33.3 4.32 1239.00 3717.00 40.0 4.98 1189.44 3568.32
32.7 53 130.0 30.8 3.88 1205.75 3617.25 36.9 4.48 1157.52 3472.56
32.7 53 158.0 25.3 3.88 1465.45 4396.35 30.4 4.48 1406.83 4220.50
32.7 53 195.0 20.5 3.88 1808.63 5000.00 24.6 4.48 1736.28 5000.00
32.7 53 243.0 16.5 3.88 2253.83 5000.00 19.8 4.48 2163.67 5000.00
32.7 53 311.0 12.9 3.88 2884.53 5000.00 15.4 4.48 2769.14 5000.00
32.7 53 323.0 12.4 3.88 2995.83 5000.00 14.9 4.48 2875.99 5000.00

Please let us know your requirements and we will provide you with transmission solutions.

All steel gears Customizable 42mm Size 5N.m 24v 12v Dc Gear Motor Low Rpm

All steel gears Customizable 42mm Size 5N.m 24v 12v Dc Gear Motor Low Rpm
