Specifications
Brand Name :
TYHE
Model Number :
TJZ37FGa
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
37mm size
Voltage :
6V 12V 24V
Speed :
customized
Torque :
No more than 2.5N.m
Gear material :
Powder metallurgy, steel gear
Commutation :
brushed
Type :
Gear Motor, Micro Motor
Usage :
ATM, Household Appliances
Keywords :
Customizable Powder Gear Chain Centric Shaft 37mm Dia 12v 24v 60rpm RS530 Dc Spur Gear Motor For ATM
Description

Products Description

Customizable Powder Gear Chain Centric Shaft 37mm Dia 12v 24v 60rpm RS530 Dc Spur Gear Motor For ATM

2D drawing

Customizable Powder Gear Chain Centric Shaft 37mm Dia 12v 24v 60rpm RS530 Dc Spur Gear Motor For ATM

Model End cover dimensions Motor type Regular Shaft Weight
TJZ37FGa φ37mm RS530 6mm-D cut 260g


Customizable Powder Gear Chain Centric Shaft 37mm Dia 12v 24v 60rpm RS530 Dc Spur Gear Motor For ATM

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
RS530 12 3500 60 2800 0.21 5.30 1.55 61.91 15.90 1.43
RS530 12 5000 160 4000 0.49 8.90 3.73 62.86 26.70 3.05
RS530 24 5000 80 4000 0.25 9.12 3.82 62.83 27.36 1.60
RS530 24 7500 72 6000 0.37 9.25 5.81 64.63 27.75 3.20
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 12V-3500RPM Input 12V-5000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
22.5 81 4.6 608.7 1.26 19.75 59.24 869.6 3.02 33.16 99.48
22.5 81 5.9 474.6 1.26 25.33 75.99 678.0 3.02 42.53 127.60
22.5 81 6.9 405.8 1.26 29.62 88.87 579.7 3.02 49.74 149.23
22.5 73 8.4 333.3 1.13 32.50 97.50 476.2 2.72 54.57 163.72
22.5 73 10.6 264.2 1.13 41.01 123.03 377.4 2.72 68.87 206.60
22.5 73 13.5 207.4 1.13 52.23 156.69 296.3 2.72 87.71 263.13
22.5 73 16.0 175.0 1.13 61.90 185.71 250.0 2.72 103.95 311.86
24.5 65.6 19.3 145.1 1.02 67.10 201.31 207.3 2.45 112.68 338.04
24.5 65.6 24.4 114.8 1.02 84.83 254.50 163.9 2.45 142.46 427.37
24.5 65.6 31.6 88.6 1.02 109.87 329.60 126.6 2.45 184.49 553.48
24.5 65.6 37.0 75.7 1.02 128.64 385.92 108.1 2.45 216.02 648.06
26.5 59 45.0 62.2 0.92 140.72 422.15 88.9 2.20 236.30 708.89
26.5 59 57.0 49.1 0.92 178.24 534.72 70.2 2.20 299.31 897.92
26.5 59 73.6 38.0 0.92 230.15 690.44 54.3 2.20 386.47 1159.42
26.5 59 86.0 32.6 0.92 268.92 806.77 46.5 2.20 451.59 1354.76
26.5 59 95.0 29.5 0.92 297.07 891.20 42.1 2.20 498.85 1496.54
29.5 53 105.0 26.7 0.82 294.95 884.84 38.1 1.98 495.29 1485.86
29.5 53 133.0 21.1 0.82 373.60 1120.79 30.1 1.98 627.36 1882.08
29.5 53 172.0 16.3 0.82 483.15 1449.44 23.3 1.98 811.32 2433.97
29.5 53 201.0 13.9 0.82 564.61 1693.83 19.9 1.98 948.12 2500.00
29.5 53 221.0 12.7 0.82 620.79 1862.37 18.1 1.98 1042.46 2500.00
29.5 53 244.0 11.5 0.82 685.40 2056.19 16.4 1.98 1150.95 2500.00
32.5 47.8 245.0 11.4 0.74 620.68 1862.05 16.3 1.78 1042.28 2500.00
32.5 47.8 310.0 9.0 0.74 785.35 2356.06 12.9 1.78 1318.80 2500.00
32.5 47.8 401.0 7.0 0.74 1015.89 2500.00 10.0 1.78 1705.93 2500.00
32.5 47.8 469.0 6.0 0.74 1188.16 2500.00 8.5 1.78 1995.22 2500.00
32.5 47.8 516.0 5.4 0.74 1307.23 2500.00 7.8 1.78 2195.17 2500.00
32.5 47.8 569.0 4.9 0.74 1441.50 2500.00 7.0 1.78 2420.64 2500.00
32.5 47.8 627.0 4.5 0.74 1588.44 2500.00 6.4 1.78 2500.00 2500.00
32.5 43 1093.0 2.6 0.67 2490.95 2500.00 3.7 1.60 2500.00 2500.00
32.5 43 1205.0 2.3 0.67 2500.00 2500.00 3.3 1.60 2500.00 2500.00
32.5 43 1328.0 2.1 0.67 2500.00 2500.00 3.0 1.60 2500.00 2500.00
32.5 43 1463.0 1.9 0.67 2500.00 2500.00 2.7 1.60 2500.00 2500.00
32.5 43 1613.0 1.7 0.67 2500.00 2500.00 2.5 1.60 2500.00 2500.00
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 24V-5000RPM Input 24V-7500RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
22.5 81 4.6 869.6 3.09 33.98 101.94 1304.3 4.71 34.47 103.40
22.5 81 5.9 678.0 3.09 43.58 130.75 1016.9 4.71 44.21 132.62
22.5 81 6.9 579.7 3.09 50.97 152.92 869.6 4.71 51.70 155.09
22.5 73 8.4 476.2 2.79 55.92 167.77 714.3 4.24 56.72 170.16
22.5 73 10.6 377.4 2.79 70.57 211.71 566.0 4.24 71.58 214.73
22.5 73 13.5 296.3 2.79 89.88 269.63 444.4 4.24 91.16 273.48
22.5 73 16.0 250.0 2.79 106.52 319.56 375.0 4.24 108.04 324.12
24.5 65.6 19.3 207.3 2.51 115.47 346.40 310.9 3.81 117.11 351.34
24.5 65.6 24.4 163.9 2.51 145.98 437.94 245.9 3.81 148.06 444.18
24.5 65.6 31.6 126.6 2.51 189.05 567.16 189.9 3.81 191.75 575.25
24.5 65.6 37.0 108.1 2.51 221.36 664.08 162.2 3.81 224.52 673.55
26.5 59 45.0 88.9 2.25 242.14 726.41 133.3 3.43 245.59 736.76
26.5 59 57.0 70.2 2.25 306.71 920.12 105.3 3.43 311.08 933.23
26.5 59 73.6 54.3 2.25 396.03 1188.08 81.5 3.43 401.67 1205.02
26.5 59 86.0 46.5 2.25 462.75 1388.25 69.8 3.43 469.35 1408.04
26.5 59 95.0 42.1 2.25 511.18 1533.53 63.2 3.43 518.46 1555.39
29.5 53 105.0 38.1 2.02 507.53 1522.58 57.1 3.08 514.76 1544.29
29.5 53 133.0 30.1 2.02 642.87 1928.61 45.1 3.08 652.03 1956.10
29.5 53 172.0 23.3 2.02 831.38 2494.14 34.9 3.08 843.23 2500.00
29.5 53 201.0 19.9 2.02 971.55 2500.00 29.9 3.08 985.40 2500.00
29.5 53 221.0 18.1 2.02 1068.23 2500.00 27.1 3.08 1083.45 2500.00
29.5 53 244.0 16.4 2.02 1179.40 2500.00 24.6 3.08 1196.21 2500.00
32.5 47.8 245.0 16.3 1.83 1068.04 2500.00 24.5 2.78 1083.27 2500.00
32.5 47.8 310.0 12.9 1.83 1351.40 2500.00 19.4 2.78 1370.67 2500.00
32.5 47.8 401.0 10.0 1.83 1748.10 2500.00 15.0 2.78 1773.02 2500.00
32.5 47.8 469.0 8.5 1.83 2044.54 2500.00 12.8 2.78 2073.68 2500.00
32.5 47.8 516.0 7.8 1.83 2249.43 2500.00 11.6 2.78 2281.49 2500.00
32.5 47.8 569.0 7.0 1.83 2480.48 2500.00 10.5 2.78 2500.00 2500.00
32.5 47.8 627.0 6.4 1.83 2500.00 2500.00 9.6 2.78 2500.00 2500.00
32.5 43 1093.0 3.7 1.64 2500.00 2500.00 5.5 2.50 2500.00 2500.00
32.5 43 1205.0 3.3 1.64 2500.00 2500.00 5.0 2.50 2500.00 2500.00
32.5 43 1328.0 3.0 1.64 2500.00 2500.00 4.5 2.50 2500.00 2500.00
32.5 43 1463.0 2.7 1.64 2500.00 2500.00 4.1 2.50 2500.00 2500.00
32.5 43 1613.0 2.5 1.64 2500.00 2500.00 3.7 2.50 2500.00 2500.00

Please let us know your requirements and we will provide you with transmission solutions.
