Specifications
Brand Name :
TYHE
Model Number :
TJX42R4260BL
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
42mm dia
Voltage :
24v or customized
Speed :
1-1000rpm Customized
Torque :
16N.m
Gear material :
Steel gears
Commutation :
Brushless
Type :
BLDC Planetary Gear Motor, Small Motor
Keywords :
42mm Diameter 40w 24 Volt 12v 15nm Torque Brushless Dc Planetary Gear Motor For Robots
Description

Products Description

42mm Diameter 40w 24 Volt 12v 15nm Torque Brushless Dc Planetary Gear Motor For Robots

2D drawing

42mm 15nm Brushless DC Gear Motor With Planetary Gearbox 40W 24 Volt For Robots


42mm 15nm Brushless DC Gear Motor With Planetary Gearbox 40W 24 Volt For Robots

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
4260BL 12 5000 620 4000 2.26 43.54 18.24 67.39 130.62 13.25
4260BL 24 5000 350 4000 1.18 45.88 19.22 67.80 137.64 6.56
DC Motor With Gearbox Technical Data (0.6M)
Gearbox parameters 12V-5000RPM Input 24V-5000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
29.7 90 3.7 1081.1 16.41 144.99 434.96 1081.1 17.30 152.78 458.34
29.7 90 5.2 769.2 16.41 203.77 611.30 769.2 17.30 214.72 644.16
39.4 81 13.7 292.0 14.77 483.16 1449.49 292.0 15.57 509.13 1527.39
39.4 81 19.2 208.3 14.77 677.13 2031.40 208.3 15.57 713.53 2140.58
39.4 81 26.9 148.7 14.77 948.69 2846.08 148.7 15.57 999.68 2999.04
39.4 81 35.0 114.3 14.77 1234.36 3703.08 114.3 15.57 1300.70 3902.09
49.1 73 51.0 78.4 13.31 1620.99 4862.98 78.4 14.03 1708.11 5124.34
49.1 73 71.0 56.3 13.31 2256.68 6770.03 56.3 14.03 2377.96 7133.88
49.1 73 100.0 40.0 13.31 3178.42 9535.26 40.0 14.03 3349.24 10047.72
49.1 73 139.0 28.8 13.31 4418.00 13254.01 28.8 14.03 4655.44 13966.33
60.3 65.6 189.0 21.2 11.96 5398.26 16194.79 21.2 12.61 5688.39 17065.16
60.3 65.6 264.0 15.2 11.96 7540.43 22621.29 15.2 12.61 7945.68 23837.05
60.3 65.6 369.0 10.8 11.96 10539.47 25000.00 10.8 12.61 11105.90 25000.00
60.3 65.6 514.0 7.8 11.96 14680.99 25000.00 7.8 12.61 15470.00 25000.00
60.3 65.6 721.0 5.5 11.96 20593.38 25000.00 5.5 12.61 21700.14 25000.00
71.5 59 699.0 5.7 10.76 17956.33 25000.00 5.7 11.34 18921.37 25000.00
71.5 59 977.0 4.1 10.76 25000.00 25000.00 4.1 11.34 25000.00 25000.00
71.5 59 1367.0 2.9 10.76 25000.00 25000.00 2.9 11.34 25000.00 25000.00
71.5 59 1911.0 2.1 10.76 25000.00 25000.00 2.1 11.34 25000.00 25000.00
71.5 59 2672.0 1.5 10.76 25000.00 25000.00 1.5 11.34 25000.00 25000.00
71.5 59 3736.0 1.1 10.76 25000.00 25000.00 1.1 11.34 25000.00 25000.00

Please let us know your requirements and we will provide you with transmission solutions.
