Micro D33mm 14.4v 7.2v 12v 24v Dc Gear Motor For Fish Feeder 1.5nm 60rpm 100rpm
Micro D33mm 14.4v 7.2v 12v 24v Dc Gear Motor For Fish Feeder 1.5nm 60rpm 100rpm
Micro D33mm 14.4v 7.2v 12v 24v Dc Gear Motor For Fish Feeder 1.5nm 60rpm 100rpm
Micro D33mm 14.4v 7.2v 12v 24v Dc Gear Motor For Fish Feeder 1.5nm 60rpm 100rpm
Micro D33mm 14.4v 7.2v 12v 24v Dc Gear Motor For Fish Feeder 1.5nm 60rpm 100rpm
Micro D33mm 14.4v 7.2v 12v 24v Dc Gear Motor For Fish Feeder 1.5nm 60rpm 100rpm
Micro D33mm 14.4v 7.2v 12v 24v Dc Gear Motor For Fish Feeder 1.5nm 60rpm 100rpm
Micro D33mm 14.4v 7.2v 12v 24v Dc Gear Motor For Fish Feeder 1.5nm 60rpm 100rpm
Micro D33mm 14.4v 7.2v 12v 24v Dc Gear Motor For Fish Feeder 1.5nm 60rpm 100rpm
Micro D33mm 14.4v 7.2v 12v 24v Dc Gear Motor For Fish Feeder 1.5nm 60rpm 100rpm
Specifications
Brand Name :
TYHE
Model Number :
TJP33RM
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
φ33mm
Voltage :
3v 12v 24V or customizable
Speed :
30-1000rpm
Torque :
1.55N.m
Gear material :
Powder metallurgy
Commutation :
Brush brushed
Type :
Gear Motor, mini Motor
Usage :
Massager Car
Keywords :
Wholesale Micro D33mm 12v 24v 14.4v 7.2v 60 Rpm 100rpm 10 Watt 8watts 1.5nm Dc Gear Motor For Fish Feeder
Description

Products Description

Wholesale Micro D33mm 12v 24v 14.4v 7.2v 60 Rpm 100rpm 10 Watt 8watts 1.5nm Dc Gear Motor For Fish Feeder

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
ZY2847 12 4500 100 3600 0.30 5.89 2.22 61.68 17.67 1.70
ZY2847 12 7500 160 6000 0.60 7.17 4.50 62.57 21.51 4.80
ZY2847 24 5000 50 4000 0.20 7.25 3.04 63.26 21.75 1.14
ZY2847 24 5300 60 4240 0.22 7.38 3.28 62.06 22.14 1.30
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 12V-4500RPM Input 12V-7500RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
21.3 81 7.7 467.5 1.80 36.74 110.21 779.2 3.65 44.72 134.16
21.3 81 9.0 400.0 1.80 42.94 128.81 666.7 3.65 52.27 156.81
21.3 73 18.4 195.7 1.62 79.11 237.34 326.1 3.29 96.31 288.92
21.3 73 21.6 166.7 1.62 92.87 278.62 277.8 3.29 113.06 339.17
21.3 73 25.4 141.7 1.62 109.21 327.64 236.2 3.29 132.95 398.84
21.3 65.6 44.2 81.4 1.46 170.78 512.35 135.7 2.96 207.90 623.69
21.3 65.6 51.9 69.4 1.46 200.53 601.60 115.6 2.96 244.11 732.34
21.3 65.6 61.0 59.0 1.46 235.69 707.08 98.4 2.96 286.91 860.74
21.3 65.6 71.6 50.3 1.46 276.65 829.95 83.8 2.96 336.77 1010.32
22.5 59 106.0 34.0 1.31 368.36 1105.08 56.6 2.66 448.41 1345.24
22.5 59 125.0 28.8 1.31 434.39 1303.16 48.0 2.66 528.79 1586.36
22.5 59 146.0 24.7 1.31 507.36 1522.09 41.1 2.66 617.62 1852.87
22.5 59 172.0 20.9 1.31 597.72 1793.15 34.9 2.66 727.61 2000.00
22.5 59 202.0 17.8 1.31 701.97 2000.00 29.7 2.66 854.52 2000.00
24.7 53 255.0 14.1 1.18 796.03 2000.00 23.5 2.39 969.03 2000.00
24.7 53 299.0 12.0 1.18 933.39 2000.00 20.1 2.39 1136.23 2000.00
24.7 53 351.0 10.3 1.18 1095.72 2000.00 17.1 2.39 1333.84 2000.00
24.7 53 413.0 8.7 1.18 1289.26 2000.00 14.5 2.39 1569.44 2000.00
24.7 53 484.0 7.4 1.18 1510.90 2000.00 12.4 2.39 1839.25 2000.00
24.7 53 569.0 6.3 1.18 1776.25 2000.00 10.5 2.39 2000.00 2000.00
27.2 48 612.0 5.9 1.07 1730.25 2000.00 9.8 2.16 2000.00 2000.00
27.2 48 718.0 5.0 1.07 2000.00 2000.00 8.4 2.16 2000.00 2000.00
27.2 48 843.0 4.3 1.07 2000.00 2000.00 7.1 2.16 2000.00 2000.00
27.2 48 990.0 3.6 1.07 2000.00 2000.00 6.1 2.16 2000.00 2000.00
27.2 48 1163.0 3.1 1.07 2000.00 2000.00 5.2 2.16 2000.00 2000.00
27.2 48 1365.0 2.6 1.07 2000.00 2000.00 4.4 2.16 2000.00 2000.00
27.2 48 1603.0 2.2 1.07 2000.00 2000.00 3.7 2.16 2000.00 2000.00
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 24V-5000RPM Input 24V-5300RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
21.3 81 7.7 519.5 2.46 45.22 135.65 550.6 2.65 46.03 138.09
21.3 81 9.0 444.4 2.46 52.85 158.56 471.1 2.65 53.80 161.40
21.3 73 18.4 217.4 2.22 97.38 292.15 230.4 2.39 99.13 297.38
21.3 73 21.6 185.2 2.22 114.32 342.95 196.3 2.39 116.37 349.10
21.3 73 25.4 157.5 2.22 134.43 403.29 166.9 2.39 136.84 410.52
21.3 65.6 44.2 90.5 1.99 210.22 630.65 95.9 2.15 213.98 641.95
21.3 65.6 51.9 77.1 1.99 246.84 740.51 81.7 2.15 251.26 753.79
21.3 65.6 61.0 65.6 1.99 290.12 870.35 69.5 2.15 295.32 885.95
21.3 65.6 71.6 55.9 1.99 340.53 1021.59 59.2 2.15 346.64 1039.91
22.5 59 106.0 37.7 1.79 453.42 1360.25 40.0 1.93 461.55 1384.64
22.5 59 125.0 32.0 1.79 534.69 1604.06 33.9 1.93 544.28 1632.83
22.5 59 146.0 27.4 1.79 624.52 1873.55 29.0 1.93 635.71 1907.14
22.5 59 172.0 23.3 1.79 735.73 2000.00 24.7 1.93 748.92 2000.00
22.5 59 202.0 19.8 1.79 864.06 2000.00 21.0 1.93 879.55 2000.00
24.7 53 255.0 15.7 1.61 979.84 2000.00 16.6 1.74 997.41 2000.00
24.7 53 299.0 13.4 1.61 1148.91 2000.00 14.2 1.74 1169.51 2000.00
24.7 53 351.0 11.4 1.61 1348.72 2000.00 12.1 1.74 1372.90 2000.00
24.7 53 413.0 9.7 1.61 1586.95 2000.00 10.3 1.74 1615.41 2000.00
24.7 53 484.0 8.3 1.61 1859.77 2000.00 8.8 1.74 1893.12 2000.00
24.7 53 569.0 7.0 1.61 2000.00 2000.00 7.5 1.74 2000.00 2000.00
27.2 48 612.0 6.5 1.46 2000.00 2000.00 6.9 1.57 2000.00 2000.00
27.2 48 718.0 5.6 1.46 2000.00 2000.00 5.9 1.57 2000.00 2000.00
27.2 48 843.0 4.7 1.46 2000.00 2000.00 5.0 1.57 2000.00 2000.00
27.2 48 990.0 4.0 1.46 2000.00 2000.00 4.3 1.57 2000.00 2000.00
27.2 48 1163.0 3.4 1.46 2000.00 2000.00 3.6 1.57 2000.00 2000.00
27.2 48 1365.0 2.9 1.46 2000.00 2000.00 3.1 1.57 2000.00 2000.00
27.2 48 1603.0 2.5 1.46 2000.00 2000.00 2.6 1.57 2000.00 2000.00

2D drawing

Micro D33mm 14.4v 7.2v 12v 24v Dc Gear Motor For Fish Feeder 1.5nm 60rpm 100rpm


Micro D33mm 14.4v 7.2v 12v 24v Dc Gear Motor For Fish Feeder 1.5nm 60rpm 100rpm

Please let us know your requirements and we will provide you with transmission solutions.
