Specifications
Brand Name :
TYHE
Model Number :
TJZ37FGb
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
D37mm
Voltage :
6V- 24V customized
Speed :
15-800rpm
Torque :
≤2.49N.m
Gear material :
Powder metallurgy, steel
Type :
DC Geared Motor
Usage :
Medical appliance
Keywords :
Manufacturer 37mm gearmotor 1 nm 15kg/cm 10kg load torque 6 volt 12v 24v 14.4v low rpm 20rpm mini dc geared motor
Color :
Silver
Description

Manufacturer 37mm Gearmotor 1 Nm 15kg/Cm 10kg Load Torque 6 Volt 12v 24v 14.4v Low Rpm 20rpm Mini Dc Geared Motor

Products Description

IE3 Steel Gear Micro 37mm Rs545 Brushed 24v 500rpm 0.5N.M Dc Gear Reduction Motor Ce Rohs

Model End cover dimensions Motor type Regular Shaft Weight
TJZ37FGb 40*40mm RS545 6mm-D cut 300g

2D drawing

37mm Gearmotor Mini Dc Geared Motor 6V 12v 24v 14.4v 15kg/Cm 10kg Load Low Rpm


37mm Gearmotor Mini Dc Geared Motor 6V 12v 24v 14.4v 15kg/Cm 10kg Load Low Rpm

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
RS545 6 3200 280 2560 0.81 11.20 3.00 61.65 33.60 4.70
RS545 12 2000 70 1600 0.20 8.95 1.50 63.54 26.85 1.10
RS545 24 6000 160 4800 0.60 17.50 8.80 61.25 52.50 4.30
RS545 24 8300 200 6640 0.88 19.30 13.42 63.90 57.90 6.90
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 6V-3200RPM Input 12V-2000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
22.5 81 4.6 556.5 2.43 41.73 125.19 347.8 1.21 33.35 100.04
22.5 81 5.9 433.9 2.43 53.52 160.57 271.2 1.21 42.77 128.32
22.5 73 8.4 304.8 2.19 68.68 206.04 190.5 1.09 54.88 164.64
22.5 73 10.6 241.5 2.19 86.67 260.00 150.9 1.09 69.26 207.77
22.5 73 13.5 189.6 2.19 110.38 331.13 118.5 1.09 88.20 264.61
24.5 65.6 19.3 132.6 1.97 141.80 425.40 82.9 0.98 113.31 339.94
24.5 65.6 24.4 104.9 1.97 179.27 537.82 65.6 0.98 143.26 429.77
24.5 65.6 31.6 81.0 1.97 232.17 696.51 50.6 0.98 185.53 556.59
26.5 59 45.0 56.9 1.77 297.36 892.08 35.6 0.88 237.62 712.87
26.5 59 57.0 44.9 1.77 376.66 1129.97 28.1 0.88 300.99 902.97
26.5 59 73.6 34.8 1.77 486.35 1459.05 21.7 0.88 388.64 1165.93
29.5 53 105.0 24.4 1.59 623.28 1869.84 15.2 0.79 498.07 1494.20
29.5 53 133.0 19.2 1.59 789.49 2368.46 12.0 0.79 630.89 1892.66
29.5 53 172.0 14.9 1.59 1020.99 2500.00 9.3 0.79 815.88 2447.65
32.5 47.8 245.0 10.4 1.44 1311.63 2500.00 6.5 0.72 1048.13 2500.00
32.5 47.8 310.0 8.3 1.44 1659.62 2500.00 5.2 0.72 1326.21 2500.00
32.5 47.8 401.0 6.4 1.44 2146.79 2500.00 4.0 0.72 1715.52 2500.00
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 24V-6000RPM Input 24V-8300RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
22.5 81 4.6 1043.5 7.12 65.21 195.62 1443.5 10.87 71.91 215.74
22.5 81 5.9 813.6 7.12 83.63 250.90 1125.4 10.87 92.23 276.70
22.5 73 8.4 571.4 6.42 107.31 321.93 790.5 9.80 118.35 355.04
22.5 73 10.6 452.8 6.42 135.42 406.25 626.4 9.80 149.34 448.03
22.5 73 13.5 355.6 6.42 172.46 517.39 491.9 9.80 190.20 570.60
24.5 65.6 19.3 248.7 5.77 221.56 664.69 344.0 8.80 244.35 733.06
24.5 65.6 24.4 196.7 5.77 280.11 840.34 272.1 8.80 308.92 926.77
24.5 65.6 31.6 151.9 5.77 362.77 1088.30 210.1 8.80 400.08 1200.24
26.5 59 45.0 106.7 5.19 464.63 1393.88 147.6 7.92 512.42 1537.25
26.5 59 57.0 84.2 5.19 588.53 1765.58 116.5 7.92 649.06 1947.18
26.5 59 73.6 65.2 5.19 759.92 2279.76 90.2 7.92 838.08 2500.00
29.5 53 105.0 45.7 4.66 973.88 2500.00 63.2 7.11 1074.05 2500.00
29.5 53 133.0 36.1 4.66 1233.58 2500.00 49.9 7.11 1360.46 2500.00
29.5 53 172.0 27.9 4.66 1595.30 2500.00 38.6 7.11 1759.39 2500.00
32.5 47.8 245.0 19.6 4.20 2049.43 2500.00 27.1 6.41 2260.22 2500.00
32.5 47.8 310.0 15.5 4.20 2500.00 2500.00 21.4 6.41 2500.00 2500.00
32.5 47.8 401.0 12.0 4.20 2500.00 2500.00 16.6 6.41 2500.00 2500.00

Please let us know your requirements and we will provide you with transmission solutions.
