Speed Adjustable 12V Dc Gear Motor Gearbox 60rpm Low Rpm Micro Brushless
Speed Adjustable 12V Dc Gear Motor Gearbox 60rpm Low Rpm Micro Brushless
Speed Adjustable 12V Dc Gear Motor Gearbox 60rpm Low Rpm Micro Brushless
Speed Adjustable 12V Dc Gear Motor Gearbox 60rpm Low Rpm Micro Brushless
Speed Adjustable 12V Dc Gear Motor Gearbox 60rpm Low Rpm Micro Brushless
Speed Adjustable 12V Dc Gear Motor Gearbox 60rpm Low Rpm Micro Brushless
Speed Adjustable 12V Dc Gear Motor Gearbox 60rpm Low Rpm Micro Brushless
Speed Adjustable 12V Dc Gear Motor Gearbox 60rpm Low Rpm Micro Brushless
Speed Adjustable 12V Dc Gear Motor Gearbox 60rpm Low Rpm Micro Brushless
Speed Adjustable 12V Dc Gear Motor Gearbox 60rpm Low Rpm Micro Brushless
Specifications
Brand Name :
TYHE
Model Number :
TJZ37R3650BL
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
120pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
37mm diameter
Voltage :
12~24V or customized
Speed :
50rpm or customized
Torque :
2.0N.m
Gear material :
Powder metallurgy, steel gears
Commutation :
Brushless
Type :
BLDC Mini Gear Motor, Micro Motor
Keywords :
Speed adjustable 37mm gearbox 12v 24v 300rpm 50rpm 60rpm low rpm high torque 2nm 15w micro brushless dc geared motor for cleaner
Description

Products Description

Speed adjustable 37mm gearbox 12v 24v 300rpm 50rpm 60rpm low rpm high torque 2nm 15w micro brushless dc geared motor for cleaner

2D drawing

Speed Adjustable 12V Dc Gear Motor Gearbox 60rpm Low Rpm Micro Brushless

Model End cover dimensions Motor type Regular Shaft Weight
TJZ37R3650BL φ37mm 3650BL 6mm-D cut 300g


Speed Adjustable 12V Dc Gear Motor Gearbox 60rpm Low Rpm Micro Brushless

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
3650BL 12 5000 350 4000 1.07 19.20 8.04 62.83 57.60 6.50
3650BL 24 5000 120 4000 0.47 17.80 7.46 65.86 53.40 3.50
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 12V-5000RPM Input 24V-5000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
22.5 81 4.6 869.6 6.51 71.54 214.62 869.6 6.04 66.32 198.97
22.5 81 5.9 678.0 6.51 91.76 275.27 678.0 6.04 85.07 255.20
22.5 73 8.4 476.2 5.9 117.73 353.20 476.19 5.44 109.15 327.45
22.5 73 10.6 377.4 5.9 148.57 445.71 377.36 5.44 137.74 413.21
22.5 73 13.5 296.3 5.9 189.22 567.65 296.30 5.44 175.42 526.26
24.5 65.6 19.3 207.3 5.28 243.09 729.26 207.3 4.89 225.36 676.09
24.5 65.6 24.4 163.9 5.28 307.32 921.97 163.9 4.89 284.91 854.74
24.5 65.6 31.6 126.6 5.28 398.01 1194.02 126.6 4.89 368.99 1106.96
26.5 59 45.0 88.9 4.7 509.76 1529.28 88.89 4.40 472.59 1417.77
26.5 59 57.0 70.2 4.7 645.70 1937.09 70.18 4.40 598.61 1795.84
26.5 59 73.6 54.3 4.7 833.74 2500.00 54.35 4.40 772.95 2318.84
29.5 53 105.0 38.1 4.26 1068.48 2500.00 38.1 3.95 990.57 2500.00
29.5 53 133.0 30.1 4.26 1353.41 2500.00 30.1 3.95 1254.72 2500.00
29.5 53 172.0 23.3 4.26 1750.27 2500.00 23.3 3.95 1622.65 2500.00
32.5 47.8 245.0 16.3 3.8 2248.51 2500.00 16.33 3.56 2084.56 2500.00
32.5 47.8 310.0 12.9 3.8 2500.00 2500.00 12.90 3.56 2500.00 2500.00
32.5 47.8 401.0 10.0 3.8 2500.00 2500.00 9.98 3.56 2500.00 2500.00

Please let us know your requirements and we will provide you with transmission solutions.
