Reversible 42mm Low Noise 24v 12v Dc Gear Motor 300rpm 800rpm 20kgcm 30kgcm
Reversible 42mm Low Noise 24v 12v Dc Gear Motor 300rpm 800rpm 20kgcm 30kgcm
Reversible 42mm Low Noise 24v 12v Dc Gear Motor 300rpm 800rpm 20kgcm 30kgcm
Reversible 42mm Low Noise 24v 12v Dc Gear Motor 300rpm 800rpm 20kgcm 30kgcm
Reversible 42mm Low Noise 24v 12v Dc Gear Motor 300rpm 800rpm 20kgcm 30kgcm
Reversible 42mm Low Noise 24v 12v Dc Gear Motor 300rpm 800rpm 20kgcm 30kgcm
Reversible 42mm Low Noise 24v 12v Dc Gear Motor 300rpm 800rpm 20kgcm 30kgcm
Reversible 42mm Low Noise 24v 12v Dc Gear Motor 300rpm 800rpm 20kgcm 30kgcm
Reversible 42mm Low Noise 24v 12v Dc Gear Motor 300rpm 800rpm 20kgcm 30kgcm
Reversible 42mm Low Noise 24v 12v Dc Gear Motor 300rpm 800rpm 20kgcm 30kgcm
Specifications
Brand Name :
TYHE
Model Number :
TJZ42RG
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
42mm size
Voltage :
12-24V or customized
Speed :
Customized
Torque :
5N.m
Gear material :
Powder metallurgy, steel
Commutation :
Brush brushes brushed
Type :
Gear Motor, Micro Motor
Usage :
Educational robot, programming robot, medical robot, escort robot and etc.
Keywords :
Reversible 42mm gearmotor low noise 9v 12v 24v 300rpm 3rpm 800rpm 20rpm 60rpm 20kgcm 30kgcm 5nm 15w 20w dc gear reduction motor
Description

Reversible 42mm Gearmotor Low Noise 9v 12v 24v 300rpm 3rpm 800rpm 20rpm 60rpm 20kgcm 30kgcm 5nm 15w 20w Dc Gear Motor

Products Description

Reversible 42mm gearmotor low noise 9v 12v 24v 300rpm 3rpm 800rpm 20rpm 60rpm 20kgcm 30kgcm 5nm 15w 20w dc gear reduction motor

Model End cover dimensions Motor type Regular Shaft Weight
TJZ42RG φ42mm RS555 8mm-D cut 420g

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
RS555 12 5700 290 4560 1.07 17.20 8.21 63.81 51.60 7.65
RS555 12 6500 310 5200 1.42 19.50 10.62 62.24 58.50 11.48
RS555 24 5000 150 4000 0.49 17.50 7.33 62.12 52.50 3.20
RS555 24 6000 160 4800 0.53 16.80 8.44 66.18 50.40 3.50
DC Motor With Gearbox Technical Data (0.7M)
Gearbox parameters 12V-5700RPM Input 12V-6500RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
25.7 81 2.5 1824.0 6.65 34.83 104.49 2080.0 8.60 39.49 118.46
25.7 81 3.1 1471.0 6.65 43.19 129.57 1677.4 8.60 48.96 146.89
25.7 81 3.8 1200.0 6.65 52.94 158.82 1368.4 8.60 60.02 180.06
25.7 81 4.8 950.0 6.65 66.87 200.62 1083.3 8.60 75.82 227.45
25.7 81 6.1 747.5 6.65 84.99 254.96 852.5 8.60 96.35 289.05
25.7 73 6.8 670.6 6.00 85.38 256.14 764.7 7.75 96.80 290.39
25.7 73 8.3 549.4 6.00 104.21 312.64 626.5 7.75 118.15 354.45
25.7 73 10.3 442.7 6.00 129.33 387.98 504.9 7.75 146.62 439.86
25.7 73 12.8 356.3 6.00 160.72 482.15 406.3 7.75 182.21 546.62
25.7 73 16.4 278.0 6.00 205.92 617.76 317.1 7.75 233.45 700.36
25.7 65.6 18.2 250.5 5.39 205.35 616.06 285.7 6.97 232.81 698.44
25.7 65.6 22.2 205.4 5.39 250.49 751.46 234.2 6.97 283.98 851.95
25.7 65.6 27.4 166.4 5.39 309.16 927.48 189.8 6.97 350.50 1051.50
25.7 65.6 34.2 133.3 5.39 385.89 1157.66 152.0 6.97 437.49 1312.46
25.7 65.6 43.8 104.1 5.39 494.20 1482.61 118.7 6.97 560.29 1680.87
29.5 59 48.6 93.8 4.85 493.19 1479.58 107.0 6.26 559.14 1677.43
29.5 59 59.3 76.9 4.85 601.78 1805.33 87.7 6.26 682.25 2046.74
29.5 59 73.0 62.5 4.85 740.80 2222.41 71.2 6.26 839.87 2519.60
29.5 59 91.2 50.0 4.85 925.50 2776.49 57.0 6.26 1049.26 3147.77
29.5 59 117.0 39.0 4.85 1187.32 3561.95 44.4 6.26 1346.09 4038.26
29.5 59 120.0 38.0 4.85 1217.76 3653.28 43.3 6.26 1380.60 4141.80
32.7 53 130.0 35.1 4.35 1185.08 3555.24 40.0 5.63 1343.55 4030.65
32.7 53 158.0 28.9 4.35 1440.33 4320.98 32.9 5.63 1632.93 4898.79
32.7 53 195.0 23.4 4.35 1777.62 5000.00 26.7 5.63 2015.33 5000.00
32.7 53 243.0 18.8 4.35 2215.19 5000.00 21.4 5.63 2511.41 5000.00
32.7 53 311.0 14.7 4.35 2835.08 5000.00 16.7 5.63 3214.19 5000.00
32.7 53 323.0 14.1 4.35 2944.47 5000.00 16.1 5.63 3338.21 5000.00
DC Motor With Gearbox Technical Data (0.7M)
Gearbox parameters 24V-5000RPM Input 24V-6000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
25.7 81 2.5 1600.0 5.94 35.44 106.31 1920.0 6.84 34.02 102.06
25.7 81 3.1 1290.3 5.94 43.94 131.83 1548.4 6.84 42.18 126.55
25.7 81 3.8 1052.6 5.94 53.87 161.60 1263.2 6.84 51.71 155.13
25.7 81 4.8 833.3 5.94 68.04 204.12 1000.0 6.84 65.32 195.96
25.7 81 6.1 655.7 5.94 86.47 259.40 786.9 6.84 83.01 249.03
25.7 73 6.8 588.2 5.35 86.87 260.61 705.9 6.16 83.40 250.19
25.7 73 8.3 481.9 5.35 106.03 318.10 578.3 6.16 101.79 305.37
25.7 73 10.3 388.3 5.35 131.58 394.75 466.0 6.16 126.32 378.96
25.7 73 12.8 312.5 5.35 163.52 490.56 375.0 6.16 156.98 470.94
25.7 73 16.4 243.9 5.35 209.51 628.53 292.7 6.16 201.13 603.39
25.7 65.6 18.2 219.8 4.81 208.94 626.81 263.7 5.54 200.58 601.74
25.7 65.6 22.2 180.2 4.81 254.86 764.57 216.2 5.54 244.66 733.99
25.7 65.6 27.4 146.0 4.81 314.55 943.66 175.2 5.54 301.97 905.91
25.7 65.6 34.2 117.0 4.81 392.62 1177.85 140.4 5.54 376.91 1130.73
25.7 65.6 43.8 91.3 4.81 502.82 1508.47 109.6 5.54 482.71 1448.13
29.5 59 48.6 82.3 4.32 501.80 1505.39 98.8 4.98 481.72 1445.17
29.5 59 59.3 67.5 4.32 612.27 1836.82 80.9 4.98 587.78 1763.34
29.5 59 73.0 54.8 4.32 753.73 2261.18 65.8 4.98 723.58 2170.73
29.5 59 91.2 43.9 4.32 941.64 2824.92 52.6 4.98 903.97 2711.92
29.5 59 117.0 34.2 4.32 1208.03 3624.08 41.0 4.98 1159.70 3479.11
29.5 59 120.0 33.3 4.32 1239.00 3717.00 40.0 4.98 1189.44 3568.32
32.7 53 130.0 30.8 3.88 1205.75 3617.25 36.9 4.48 1157.52 3472.56
32.7 53 158.0 25.3 3.88 1465.45 4396.35 30.4 4.48 1406.83 4220.50
32.7 53 195.0 20.5 3.88 1808.63 5000.00 24.6 4.48 1736.28 5000.00
32.7 53 243.0 16.5 3.88 2253.83 5000.00 19.8 4.48 2163.67 5000.00
32.7 53 311.0 12.9 3.88 2884.53 5000.00 15.4 4.48 2769.14 5000.00
32.7 53 323.0 12.4 3.88 2995.83 5000.00 14.9 4.48 2875.99 5000.00

2D drawing

Reversible 42mm Low Noise 24v 12v Dc Gear Motor 300rpm 800rpm 20kgcm 30kgcm


Reversible 42mm Low Noise 24v 12v Dc Gear Motor 300rpm 800rpm 20kgcm 30kgcm

Please let us know your requirements and we will provide you with transmission solutions.

Reversible 42mm Low Noise 24v 12v Dc Gear Motor 300rpm 800rpm 20kgcm 30kgcm

Reversible 42mm Low Noise 24v 12v Dc Gear Motor 300rpm 800rpm 20kgcm 30kgcm
