12v 200rpm DC Worm Gear Motor 2nm 58mm*40mm With Encoder
12v 200rpm DC Worm Gear Motor 2nm 58mm*40mm With Encoder
12v 200rpm DC Worm Gear Motor 2nm 58mm*40mm With Encoder
12v 200rpm DC Worm Gear Motor 2nm 58mm*40mm With Encoder
12v 200rpm DC Worm Gear Motor 2nm 58mm*40mm With Encoder
12v 200rpm DC Worm Gear Motor 2nm 58mm*40mm With Encoder
Specifications
Brand Name :
TYHE
Model Number :
TJW58FX
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
58mm*40mm
Voltage :
12v~24v or customized
Speed :
10-200rpm or Customized
Torque :
5N.m Customized
Gear material :
Powder gears
Commutation :
Brushed
Type :
Worm Gear Motor
Keywords :
Factory 5840 worm gearmotor 12v 24v 18v 100 rpm 200rpm 10rpm low speed high torque 10kg 15kg 2nm dc worm gear motor with encoder
Description

Products Description

Factory 5840 gearmotor 12v 24v 100 rpm 200rpm low speed high torque 10kg 15kg 2nm dc worm gear motor with encoder

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
ZY3157 12 5000 210 4000 0.46 8.30 3.48 63.44 24.90 1.70
ZY3157 24 5000 100 4000 0.22 8.40 3.52 66.63 25.20 0.84
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 12V-5000RPM Input 24V-5000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
38.3 90 3.7 1081.1 3.13 27.64 82.92 1081.1 3.17 27.97 83.92
38.3 90 5.2 769.2 3.13 38.84 116.53 769.2 3.17 39.31 117.94
51.4 81 13.7 292.0 2.82 92.11 276.32 292.0 2.85 93.21 279.64
51.4 81 19.2 208.3 2.82 129.08 387.24 208.3 2.85 130.64 391.91
51.4 81 26.9 148.7 2.82 180.85 542.55 148.7 2.85 183.03 549.08
51.4 81 35.0 114.3 2.82 235.31 705.92 114.3 2.85 238.14 714.42
64.6 73 51.0 78.4 2.54 309.01 927.03 78.4 2.57 312.73 938.20
64.6 73 71.0 56.3 2.54 430.19 1290.57 56.3 2.57 435.37 1306.12
64.6 73 100.0 40.0 2.54 605.90 1817.70 40.0 2.57 613.20 1839.60
64.6 73 139.0 28.8 2.54 842.20 2526.60 28.8 2.57 852.35 2557.04
80 65.6 189.0 21.2 2.28 1029.07 3087.20 21.2 2.31 1041.47 3124.40
80 65.6 264.0 15.2 2.28 1437.43 4312.28 15.2 2.31 1454.75 4364.24
80 65.6 369.0 10.8 2.28 2009.13 5000.00 10.8 2.31 2033.34 5000.00
80 65.6 514.0 7.8 2.28 2798.63 5000.00 7.8 2.31 2832.35 5000.00
80 65.6 721.0 5.5 2.28 2798.63 5000.00 5.5 2.31 3973.00 5000.00
95 59 699.0 5.7 2.05 3423.00 5000.00 5.7 2.08 3464.24 5000.00
95 59 977.0 4.1 2.05 4784.37 5000.00 4.1 2.08 4842.01 5000.00
95 59 1367.0 2.9 2.05 5000.00 5000.00 2.9 2.08 5000.00 5000.00
95 59 1911.0 2.1 2.05 5000.00 5000.00 2.1 2.08 5000.00 5000.00
95 59 2672.0 1.5 2.05 5000.00 5000.00 1.5 2.08 5000.00 5000.00
95 59 3736.0 1.1 2.05 5000.00 5000.00 1.1 2.08 5000.00 5000.00

2D drawing

12v 200rpm DC Worm Gear Motor 2nm 58mm*40mm With Encoder


12v 200rpm DC Worm Gear Motor 2nm 58mm*40mm With Encoder

Please let us know your requirements and we will provide you with transmission solutions.

12v 200rpm DC Worm Gear Motor 2nm 58mm*40mm With Encoder

12v 200rpm DC Worm Gear Motor 2nm 58mm*40mm With Encoder
