Double Flat Shaft Right Angle Gearbox 10Rpm 1nm High Torque Micro Dc Gear Motor
Double Flat Shaft Right Angle Gearbox 10Rpm 1nm High Torque Micro Dc Gear Motor
Double Flat Shaft Right Angle Gearbox 10Rpm 1nm High Torque Micro Dc Gear Motor
Double Flat Shaft Right Angle Gearbox 10Rpm 1nm High Torque Micro Dc Gear Motor
Double Flat Shaft Right Angle Gearbox 10Rpm 1nm High Torque Micro Dc Gear Motor
Double Flat Shaft Right Angle Gearbox 10Rpm 1nm High Torque Micro Dc Gear Motor
Double Flat Shaft Right Angle Gearbox 10Rpm 1nm High Torque Micro Dc Gear Motor
Double Flat Shaft Right Angle Gearbox 10Rpm 1nm High Torque Micro Dc Gear Motor
Double Flat Shaft Right Angle Gearbox 10Rpm 1nm High Torque Micro Dc Gear Motor
Double Flat Shaft Right Angle Gearbox 10Rpm 1nm High Torque Micro Dc Gear Motor
Double Flat Shaft Right Angle Gearbox 10Rpm 1nm High Torque Micro Dc Gear Motor
Double Flat Shaft Right Angle Gearbox 10Rpm 1nm High Torque Micro Dc Gear Motor
Specifications
Brand Name :
TYHE
Model Number :
TJP65FH
Certification :
CE/ROHS/ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100000pcs per month
Delivery Time :
15 working days after payment
Packaging Details :
Foam wrapped, carton packed
Size :
65mm*48mm
Voltage :
3v 12v 6v 24v or customized
Speed :
1-1000rpm Customized
Torque :
1.51N.m
Gear material :
Powder metallurgy
Commutation :
Brushes, brushed
Type :
Flat Gear Motor
Keywords :
Cheap price 65*48mm right angle gearbox double flat shaft 3v 3.7v 6v 12v 24v 10 rpm 20rpm 1nm high torque micro dc gear motor
Description

Products Description

Cheap price 65*48mm right angle gearbox double flat shaft 3.7v 6v 12v 10 rpm 20rpm 1nm high torque micro dc gear motor

Specifications

DC Motor Technical Data
Model Rated Voltage(V) No-Load Parameters Rated Parameters Stall Parameters
Speed Current Speed Current Torque Output eff Torque Current
rpm mA rpm A mN.m W % mN.m A
ZY3324 6 7000 80 5600 0.37 2.35 1.38 62.78 7.05 2.95
ZY3324 7 4000 30 3200 0.14 1.79 0.60 62.70 5.37 1.10
ZY3324 12 5500 38 4400 0.13 2.13 0.98 64.82 6.39 0.83
ZY3324 12 7300 64 5840 0.27 3.24 1.98 61.30 9.72 2.08
ZY3324 24 4000 15 3200 0.04 1.87 0.63 62.66 5.61 0.23
ZY3324 24 5000 17 4000 0.06 2.27 0.95 63.73 6.81 0.44
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 6V-7000RPM Input 7V-4000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
65 81 8.3 674.7 1.12 15.80 47.40 385.5 0.49 12.03 36.10
65 81 12.0 466.7 1.12 22.84 68.53 266.7 0.49 17.40 52.20
65 73 15.7 356.7 1.01 26.93 80.80 203.8 0.44 20.52 61.55
65 73 18.2 307.7 1.01 31.22 93.67 175.8 0.44 23.78 71.35
65 73 22.6 247.8 1.01 38.77 116.31 141.6 0.44 29.53 88.59
65 73 32.4 172.8 1.01 55.58 166.75 98.8 0.44 42.34 127.01
65 73 37.0 151.4 1.01 63.47 190.42 86.5 0.44 48.35 145.04
65 65.6 81.3 68.9 0.90 125.33 376.00 39.4 0.39 95.47 286.40
65 65.6 111.0 50.5 0.90 171.12 513.35 28.8 0.39 130.34 391.02
65 59 179.0 31.3 0.81 248.18 744.55 17.9 0.35 189.04 567.13
65 59 244.0 23.0 0.81 338.31 1014.92 13.1 0.35 257.69 773.07
65 53 394.0 14.2 0.73 490.73 1472.18 8.1 0.32 373.79 1121.36
65 53 537.0 10.4 0.73 668.83 1500.00 6.0 0.32 509.45 1500.00
65 47.8 866.0 6.5 0.66 972.78 1500.00 3.7 0.29 740.97 1500.00
65 47.8 1181.0 4.7 0.66 1326.62 1500.00 2.7 0.29 1010.49 1500.00
65 43 1905.0 2.9 0.59 1500.00 1500.00 1.7 0.26 1466.28 1500.00
65 43 2597.0 2.2 0.59 1500.00 1500.00 1.2 0.26 1500.00 1500.00
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 12V-5500RPM Input 12V-7300RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
65 81 8.3 530.1 0.79 14.32 42.96 703.6 1.60 21.78 65.35
65 81 12.0 366.7 0.79 20.70 62.11 486.7 1.60 31.49 94.48
65 73 15.7 280.3 0.72 24.41 73.24 372.0 1.45 37.13 111.40
65 73 18.2 241.8 0.72 28.30 84.90 320.9 1.45 43.05 129.14
65 73 22.6 194.7 0.72 35.14 105.42 258.4 1.45 53.45 160.36
65 73 32.4 135.8 0.72 50.38 151.14 180.2 1.45 76.63 229.90
65 73 37.0 118.9 0.72 57.53 172.59 157.8 1.45 87.51 262.54
65 65.6 81.3 54.1 0.64 113.60 340.80 71.8 1.30 172.80 518.39
65 65.6 111.0 39.6 0.64 155.10 465.29 52.6 1.30 235.92 707.77
65 59 179.0 24.6 0.58 224.95 674.85 32.6 1.17 342.18 1026.53
65 59 244.0 18.0 0.58 306.63 919.90 23.9 1.17 466.43 1399.29
65 53 394.0 11.2 0.52 444.79 1334.36 14.8 1.05 676.58 1500.00
65 53 537.0 8.2 0.52 606.22 1500.00 10.9 1.05 922.14 1500.00
65 47.8 866.0 5.1 0.47 881.71 1500.00 6.7 0.95 1341.19 1500.00
65 47.8 1181.0 3.7 0.47 1202.42 1500.00 4.9 0.95 1500.00 1500.00
65 43 1905.0 2.3 0.42 1500.00 1500.00 3.1 0.85 1500.00 1500.00
65 43 2597.0 1.7 0.42 1500.00 1500.00 2.2 0.85 1500.00 1500.00
DC Motor With Gearbox Technical Data (0.5M)
Gearbox parameters 24V-4000RPM Input 24V-5000RPM Input
Length (mm) Transmission Efficiency (%) Gear Ratio Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m) Rated Output Speed (RPM) Rated Output Power (W) Rated Torque (mN.m) Maximum Instantaneous Torque (mN.m)
65 81 8.3 385.5 0.51 12.57 37.72 481.9 0.77 15.26 45.78
65 81 12.0 266.7 0.51 18.18 54.53 333.3 0.77 22.06 66.19
65 73 15.7 203.8 0.46 21.43 64.30 254.8 0.69 26.02 78.05
65 73 18.2 175.8 0.46 24.84 74.53 219.8 0.69 30.16 90.48
65 73 22.6 141.6 0.46 30.85 92.55 177.0 0.69 37.45 112.35
65 73 32.4 98.8 0.46 44.23 132.69 123.5 0.69 53.69 161.07
65 73 37.0 86.5 0.46 50.51 151.53 108.1 0.69 61.31 183.94
65 65.6 81.3 39.4 0.41 99.73 299.20 49.2 0.62 121.07 363.20
65 65.6 111.0 28.8 0.41 136.17 408.50 36.0 0.62 165.29 495.88
65 59 179.0 17.9 0.37 197.49 592.47 22.3 0.56 239.73 719.20
65 59 244.0 13.1 0.37 269.21 807.62 16.4 0.56 326.79 980.37
65 53 394.0 8.1 0.33 390.49 1171.48 10.2 0.50 474.02 1422.06
65 53 537.0 6.0 0.33 532.22 1500.00 7.4 0.50 646.06 1500.00
65 47.8 866.0 3.7 0.30 774.08 1500.00 4.6 0.45 939.66 1500.00
65 47.8 1181.0 2.7 0.30 1055.65 1500.00 3.4 0.45 1281.46 1500.00
65 43 1905.0 1.7 0.27 1500.00 1500.00 2.1 0.41 1500.00 1500.00
65 43 2597.0 1.2 0.27 1500.00 1500.00 1.5 0.41 1500.00 1500.00

2D drawing (Gear ratio≤244)

Double Flat Shaft Right Angle Gearbox 10Rpm 1nm High Torque Micro Dc Gear Motor

2D drawing (Gear ratio＞244)

Double Flat Shaft Right Angle Gearbox 10Rpm 1nm High Torque Micro Dc Gear Motor


Double Flat Shaft Right Angle Gearbox 10Rpm 1nm High Torque Micro Dc Gear Motor

Please let us know your requirements and we will provide you with transmission solutions.
