1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
Specifications
Place of Origin :
Shanghai, China
Brand Name :
Clirik
Packaging Details :
wooden box
Supply Ability :
100 Set/Sets per Month
Price :
$15,890.00/sets 1-4 sets
Brand Brand :
Siemens
Control System :
PLC
Color :
As Request
Application :
Minerals (stone) Powder processing
Feeding size :
0-20 mm
Output size :
50-450 mesh
Factory Visit :
Welcomed Warmly
Usage :
10-15 years
Description
1 Ton Per Hour Limestone Caco3 Mica Grinding Mill Powder Raymond Mill 4R Grinder1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
Product Description
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
YGM series Raymond roller mill is also called Raymond grinding mill, Raymond pulverizer. YGM series Raymond roller mill is the new type Raymond mill of our company, which is suitable for processing various non-flammable and non-explosive mineral materials with Moh's hardness less than 9.3 and humidity less than 6%.
The main parts of Raymond roller mill is grinding roller, grinding ring, grinding roller assembly, the plum flower frame, air
flue, coupling, perching knife and so on.
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R

Technology Date of Raymond Mill

Note: This specification is just referencing, any changes are subject to the products.
Model
Diameter(mm)
InputSize(mm)
FinalSize(mesh)
Host Power(KW)
Capacity(T/H)
Dimension <L*W*H>(mm)
YGM9720
970
20
80-600
97
1.5-7.5
8200*6010*7200
YGM1280
1280
20
80-600
145
2-10
8500*7500*8200
YGM1300
1300
20
80-400
222
2-14
10100*9300*8330
YGM1620
1620
30
80-400
322
2.5-18
10250*8090*10510
YGM1720
1720
35
80-325
442
6-30
12500*12250*10400
YGM2150
2150
35
80-325
572
12-40
12000*11600*11000
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
Raymond roller mill can be widely used in the fields of metallurgy, construction, chemical industry, mining, highway construction etc,. The granularity of the finished powder size can be adjusted between 30 and 425 mesh. Examples of processing materials include quartz, feldspar, barite, calcite carbonate, limestone, talc, ceramic, iron ore, carborundum, bauxite, rock phosphate, coal and other materials, about 400 kinds of materials in total.
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
Working Principle of Raymond Mill
The working principle is as follows: load the stuff for grinding evenly and continuously into the grinding chamber of the main frame. Due to the centrifugal force in rotation, the roller swings go outward and presses closely upon the ring. The shovel carries the stuff to the space between the roller and ring. When the roller rolls, the stuff is thus grind. After being grind, the stuff is to be routed to the classifier along wind belt of the blower and the rough powder will be put back to the grinder for regrinding.

The fine powder flows into the cyclone collector together with air flow and is expelled from the powder output pipe as product. In the grinding chamber, since the stuff contains moisture to some extent, the heat generated during grinding makes the moisture evaporate; since the pipeline joints are not airtight, the external air is sucked in and the circulation air mass increases. In order to enable the grinder to work in negative pressure, the increased air flow is guided to the duster and sequentially to the atmosphere after purification.
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
Advantages of Raymond Mill
1. Higher output. Its output increases by 10%-20% comparing with Raymond mill under the same power condition.

2. Larger range of final fineness. Size of final product can be 0.613 mm (30 mesh) –0.033 mm (425 mesh). Some can reach the fineness of 0.013 mm (1000 mesh).

3.Good dust control. High Pressure Suspension Mill meets the requirement of national dust-dump standard.

4.Easy to operate. The whole system is combined by some independent systems, and the cohesion between the systems is good.

5. Excellent sealing. The multi-class seals are adopted to keep the grinding equipment tight closed.
Related Products---Raymond Mill
If you are interested in our mining equipment, and want to know more details about the stone powder production line project, you are welcome to visit our---
Online Store
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
Ball Mill
----------------------------------------------------------------
uniform powder size production
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
HGM Ultra Fine Mill
----------------------------------------------------------------
150-3000 mesh powder processing
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
Jaw Crusher
----------------------------------------------------------------
And other stone crushing machine
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Certifications
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
Packing & Delivery
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
Company Profile
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
SHANGHAI CLIRIK MACHINERY CO., LTD located in PUDONG New district of Shanghai china as a pioneer enterprise, which is specializing in research, manufacture and sales of all kinds of mining equipment. Our company has already formed a full set of modern production line, equipped with intelligent, standardized testing and controlling laboratories, owned a professional team for R&D, production, sales and service. So far, we have established a whole production chain, the products cover micro powder grinding mill, high pressure grinding mill, European version coarse grinding mill, hammer crusher, jaw crusher, screw conveyor, bucket elevator and so on. They are widely used in the industry of mining, construction materials, chemicals, metallurgy, transportation, hydraulic engineering and so on. Specially we independently developed HGM micro powder grinding mill, which are not only renowned in domestic market, but also have been sold widely in Eastern Europe, Middle East, Africa, South Asia, Southeast Asia, Oceania, and America, etc. We still insist on the communication and cooperation with prestigious scientific research institutions from both home and abroad to make our development ability always is in the domestic front. Based on the principle of constant innovation and quality guarantee, customer foremost, we are able to provide our customers not only the highest quality products at the most favorable price but also the most reasonable solution, such as the selection of the equipment, optimized process configuration and a full range of technical support, therefore we always follow your steps, pursue your value and achieve your benefit.
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
Exhibition
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
Customer Photos
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
1 TPH Limestone Caco3 Mica Micro Powder Grinding Mill Raymond 4R
Customer Site on the World
So far, we have established a whole production chain, the products cover micro powder grinding mill, high pressure grinding mill,
European version coarse grinding mill, hammer crusher, jaw crusher, screw conveyor, bucket elevator and so on. They are widely
used in the industry of mining, construction materials, chemicals, metallurgy, transportation, hydraulic engineering and so on.
Specially we independently developed HGM micro powder grinding mill, which are not only renowned in domestic market, but also have
been sold widely in Eastern Europe, Middle East, Africa, South Asia, Southeast Asia, Oceania, and America, etc.
FAQ
1. who are we?
We are based in Shanghai, China, start from 2010,sell to Mid East(30.00%),Africa(20.00%),Southeast Asia(19.00%),South Asia(15.00%),North America(3.00%),South America(3.00%),Domestic Market(3.00%),Southern Europe(2.00%),Eastern Europe(00.00%),Eastern Asia(00.00%),Western Europe(00.00%),Central America(00.00%),Northern Europe(00.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Grinding Mill

4. why should you buy from us not from other suppliers?
1. CE, ISO9001 2. factory sell directly 3. 30 years experience, professional 4. Sales market all over the world 5. good after sales serive

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CPT,DDU,Express Delivery；
Accepted Payment Currency:USD;
Accepted Payment Type: T/T,L/C,Western Union;
Language Spoken:English,Chinese,French
