WR112 6dB Waveguide Fixed Attenuator
WR112 6dB Waveguide Fixed Attenuator
Specifications
Place of Origin :
Chengdu,China
Model Number :
112FA-06-1
Frequency Range :
7.05-10.0GHz
Waveguide Port :
WR112
Flange Type :
FBP84(Compatible with UBR84)
Material :
Aluminium
Brand Name :
Zysen
MOQ :
1pc
Delivery Time :
2-4 Weeks
Price :
Negotiable
Payment Terms :
T/T, L/C,D/A
Certification :
ISO9001
Description

WR112 6dB Waveguide Fixed Attenuator

Waveguide Fixed Attenuator & Waveguide Variable Attenuator,WR10 to WR650, Power handling 0.25 to 100watts. Custom desgin according to requirment.


P/N

Frequency Range

(GHz)

 WG Size

Attenuation

(dB)

Power

(W)

 VSWR Flange Type
650FA-dB-P 1.12-1.70 WR650 3~30 0.25~100 1.25 FDP14/FDM14
510FA-dB-P 1.45-2.20 WR510 3~30 0.25~100 1.25 FDP18/FDM18
430FA-dB-P 1.70-2.60 WR430 3~30 0.25~100 1.25 FDP22/FDM22
340FA-dB-P 2.20-3.30 WR340 3~30 0.25~100 1.25 FDP26/FDM26
284FA-dB-P 2.60-3.95 WR284 3~30 0.25~100 1.25 FDP32/FDM32
229FA-dB-P 3.30-4.90 WR229 3~30 0.25~100 1.25 FDP40/FDM40
187FA-dB-P 3.95-5.85 WR187 3~30 0.25~100 1.25 FDP48/FDM48
159FA-dB-P 4.90-7.05 WR159 3~30 0.25~100 1.25 FDP58/FDM58
137FA-dB-P 5.85-8.20 WR137 3~30 0.25~100 1.25 FDP70/FDM70
112FA-dB-P 7.05-10.0 WR112 3~30 0.25~100 1.25 FBP84/FBM84/FBE84
90FA-dB-P 8.20-12.4 WR90 3~30 0.25~100 1.25 FBP100/FBM100/FBE100
75FA-dB-P 10.0-15.0 WR75 3~30 0.25~60 1.25 FBP120/FBM120/FBE120
62FA-dB-P 12.4-18.0 WR62 3~30 0.25~60 1.25 FBP140/FBM140/FBE140
51FA-dB-P 15.0-22.0 WR51 3~30 0.25~60 1.25 FBP180/FBM180/FBE180
42FA-dB-P 18.0-26.5 WR42 3~30 0.25~50 1.25 FBP220/FBM220/FBE220
34FA-dB-P 22.0-33.0 WR34 3~30 0.25~50 1.25 FBP260/FBM260/FBE260
28FA-dB-P 26.5-40.0 WR28 3~30 0.25~50 1.25 FBP320/FBM320/FBE320
22FA-dB-P 33.0-50.0 WR22 3~30 0.25~10 1.30 FUGP400
19FA-dB-P 40.0-60.0 WR19 3~30 0.25~5 1.30 FUGP500
15FA-dB-P 50.0-75.0 WR15 3~30 0.25~2 1.30 FUGP620
12FA-dB-P 60.0-90.0 WR12 3~30 0.25~2 1.30 FUGP740
10FA-dB-P 75.0-110.0 WR10 3~30 0.25~2 1.30 FUGP900
Ordering Information WR Mod -dB -P
Example part number: 112 FA -30 5
Waveguide Size: WR10 to WR650
Model FA: Fixed Attenuator
Attenuation: 3~30dB
P: Power

Example P/N:

112FA-30-5 is WR112 Fixed Attenuator with 30dB attenuation and 5W power.
