Specifications
Brand Name :
HUOLI
Model Number :
HL-50HMV
Certification :
ISO,CE
Place of Origin :
XI'AN CHINA
MOQ :
1 Set
Supply Ability :
20 Sets Per Month
Delivery Time :
10 Days After Confirmation
Packaging Details :
Wooden Case, Iron-Pallet
Material :
Stainless steel
Condition :
New
Type :
Dryer
Transmission speed :
0-10m(adjustable)
Temperature :
0-100C(asjustable)
HS Code :
8438800000
Description

Tunnel Microwave Drying Machine For Peanut Walnut Nuts Hazelnuts Pine nuts

● Application

The series of tunnel microwave drying & sterilizing equipment are patent product of HUOLI. They are widely applied to drying and sterilizing of solid Traditional Chinese Medicine(TCM), oral liquids, syrups, flowers, plants, meats, papers, woods and many kinds of chemical materials.

● Structure & Function

☆ Composed of electric pre-heat box, microwave heat component, microwave suppressor, wind-humidity release part, transfer system and PLC control system.

☆ Combination of microwave heat units.

☆ Modularize design for easy cleaning, assembly-disassembly and maintenance.

☆ The core components are all imported from U.S., Germany and Japan to ensure the stable high efficiency and perfect performance.

☆ 90% quality stainless steel structure guarantee the comform to GMP and FDA standard.

☆ Materials be dried and sterilized with high microwave energy under a low temperature that make a tiny loss of active ingredient, nutrition and specific features.

☆ Customized manufactures are available and welcome.

●Parameter sheet

Model No. HL-15KW HL-20KW HL-30KW HL-50KW HL-80KW HL-80KW
Working Frequency(MHz) 2450/915(optional)
Output Power(KW) 15 20 30 50 80 7-80
Microwave Leakage(MW/㎡) ≤5
Dehydrating Capacity(Kg/KW.h) 0.8-1.0
Exhaust volume of Moisture(m³/h) 3000-5000 3000-5000 5000-6500 5500-7500 6000-7500 1500-7500
Sterilizing Capacity(Kg/h) 150-180 200-250 300-400 500-600 600-1000 60-1000

Size of Shape(M)

(LxWxH)

6.2x1.2x1.8

4.0-6.2x1.2

x1.8-2.3

6.0-10.6x1.4

x1.6-2.5

6-10.6x1.4

x1.6-3.5

Tunnel Microwave Drying Machine Sterilizing Equipment For Nuts / Pet Food / Meat
