Automated Food Sterilization Equipment Microwave Food Drying Machine
Automated Food Sterilization Equipment Microwave Food Drying Machine
Automated Food Sterilization Equipment Microwave Food Drying Machine
Automated Food Sterilization Equipment Microwave Food Drying Machine
Automated Food Sterilization Equipment Microwave Food Drying Machine
Automated Food Sterilization Equipment Microwave Food Drying Machine
Automated Food Sterilization Equipment Microwave Food Drying Machine
Automated Food Sterilization Equipment Microwave Food Drying Machine
Specifications
Brand Name :
HUOLI
Model Number :
HL-30KW
Certification :
CE, ISO
Place of Origin :
Xi'an China
MOQ :
1 Set
Supply Ability :
20 Sets Per Month
Delivery Time :
10 Days After Confirmation
Packaging Details :
Wooden Case, Iron-Pallet
Material :
Food grade Stainless Steel
Condition :
New
Power :
30HMV
Function :
Drying, Sterilization, Dehyration
Warranty :
12 Months
HS Code :
84380000
Description

Automatic Food Steriliztion Equipment / Microwave Food Sterilizing Equipment


Features:


1. Tunnel microwave drying machine is a new type of drying equipment, high efficiency, low operating cost, it is an efficient and environmentally friendly energy-saving equipment; especially for dry food containing both bactericidal preservation. This equipment has been extensively involved in the pharmaceutical, food, chemical, building materials and other industries.
2. Drying uniformity, China's first low-power microwave multi-tube is manufactured by the company.
3. The machine uses a modular design, touch screen as the user interface, controlled by the PLC, the core electronic components imported.
4. Microwave transmission mode (patented) control waveguide can make full use of microwave energy and improve distribution uniformity microwave.
5. A lack of material protection, and microwave energy into the material to achieve automatic tracking function on and off.
6. The use of advanced water-cooled water-cooled magnetron and oil-immersed transformers, microwave source as the main cooling measures, and easy maintenance, low failure rate.
7. The device is equipped with the United States imported infrared thermometer, temperature measurement accuracy, stable performance, enabling precise temperature control by temperature setting, can be of various materials for automatic on-line adjustment of the size of the microwave power to meet the microwave energy investment. Fluctuations of temperature ≤5 ºC.
8. Adoption of setting far-infrared sensing control and advanced PLC automatic control system can be realized lack of material, blanking the automatic protection.


Main Technical Parameters:

Model
Working Frequency
(MHz)
Output
Power
(kw)
Microwave Leakage
(MW/cm2)
External Dimension(M)(L×W×H)
Adjustable
Productivity of Drying(kg/h)
Productivity of Sterilization(kg/h)
HL-15HMV
2450±50
15
≤5
9.8×1.2×1.6
40-75
150-180
HL-20HMV
2450±50
20
≤5
12.4×1.2×1.6
50-120
200-250
HL-30HMV
2450±50
30
≤5
14.6×1.2×1.6
65-160
300-400
HL-50HMV
2450±50
50
≤5

20.5×1.2×1.6
120-200
500-600
HL-50-80HMV
2450±50
50-80
≤5
30×1.2×1.6
200-300
600-1000
HL-80HMV-L Vertical. Tunnel Microwave Sterilizing & Drying machine
2450±50
7-80
≤5
9-30×1.2×1.8
40-360
60-1000
HL-80HMV Tracked
Tunnel Microwave Sterilizing & Drying
Machine
2450±50
7-80
≤5
9-30×1.2×1.8
40-360
60-1000
