CUT100 Mobile Cut IGBT Plasma Cutter Portable Steel Cutting Machine
CUT100 Mobile Cut IGBT Plasma Cutter Portable Steel Cutting Machine
CUT100 Mobile Cut IGBT Plasma Cutter Portable Steel Cutting Machine
CUT100 Mobile Cut IGBT Plasma Cutter Portable Steel Cutting Machine
CUT100 Mobile Cut IGBT Plasma Cutter Portable Steel Cutting Machine
CUT100 Mobile Cut IGBT Plasma Cutter Portable Steel Cutting Machine
CUT100 Mobile Cut IGBT Plasma Cutter Portable Steel Cutting Machine
CUT100 Mobile Cut IGBT Plasma Cutter Portable Steel Cutting Machine
Specifications
Brand Name :
GOWELLDE
Model Number :
CUT100
Certification :
CE
Place of Origin :
GUANGDONG,CHINA
MOQ :
100 Pieces
Price :
NEGOTIATION
Payment Terms :
T/T, L/C, Western Union, D/A, D/P
Supply Ability :
30000PCS/MONTH
Delivery Time :
30 DAYS
Packaging Details :
CARTON
Product name :
CUT100
Warranty :
1 Year
Weight :
40
Duty cycle(%) :
100
Dimension(l*w*h) :
510*265*500
Type :
cnc plasma/flame cutter machine
Rated input voltage :
AC380V
Power factor :
0.93
control mode :
IGBT inverter
Using plasma gas :
Compressed air
Description

Cut100 Mobile Cut Igbt Plasma Cutter Function Portable Steel Cutting Machine

Product charactics

1. Preset current function, can preset accurate cutting current with infinite adjusting way to cut different thickness plate.

2. Better external and dynamic characteristic than transformer type cutting machine, With excellent performance like high successful rates of arc striking, good arc stiffness, smooth cut.

3. Current rising slowly when arc starting, effectively extend the life of electrode and nozzle.

4. Very stable cutting current, it doesn't influence the cutting current when voltage fluctuates within 10%.

5. High duty cycle, no stop at max cutting current.

6. With non-contact arc striking, excellent instant arc strike function.

Product parameters

Type

CUT100

control mode

IGBT inverter

Rated input voltage

AC380V

Rated input current(A)

22

Rated input capacity(KVA)

14.5

Rated output current(A)

100

Cable cross-sectional area

mains input(mm2)

4

power output(mm2)

16

ground wire(mm2)

4

Rated output voltage(V)

120

Duty cycle(%)

100

Rated no-load voltage(V)

285

Current adjustment range(A)

30-100

Quality cutting thickness (carbon steel)(mm)

1~30

Maximum cutting thickness (carbon steel)(mm)

35

Using plasma gas

Compressed air

Gas pressure range(MPa)

0.4-0.5

Applicable air compressor capacity(m3)

≥0.3

Arc ignition mode

High pressure non-contact

Enclosure rating

IP21S

Insulation rating

F

Cooling method

Air

Power factor

0.93

Dimensions(mm)

510*265*500

Host weight(KG)

40

CUT100 Mobile Cut IGBT Plasma Cutter Portable Steel Cutting Machine

CUT100 Mobile Cut IGBT Plasma Cutter Portable Steel Cutting Machine

CUT100 Mobile Cut IGBT Plasma Cutter Portable Steel Cutting Machine

FAQ

Q:Can you make your welding machines under my brand?

A:Yes, we can welding machines under your logo and it has the Minimum Order Quantity .

Q:I have not heard of General Welder company before, are you a new company?

A:General Welder company was established since 2012 by a team of members with welding machines exceptional knowledge and with over 10 years of experience in the welding machines Industry.

Q:.Can you offer welding machines for testing?

A:Yes, we can offer welding machines for the test.

Q:What kind of welding machines warranty do you have?

A:We provide a 1-year warranty to most of our welding machines product. For more information, please send the product model and send an email to us.
