8mm Mineral Insulated Metal Sheathed Cable Sensor Control
8mm Mineral Insulated Metal Sheathed Cable Sensor Control
Specifications
Brand Name :
MICH
Model Number :
HTOMISCCA
Certification :
ISO9001
Place of Origin :
China
MOQ :
1 meter
Price :
USD0.5-USD5 per meter
Supply Ability :
10 million meters per year
Delivery Time :
in one month
Packaging Details :
plywood crates
Conductor :
Different Metals
Sheath :
Stainless Steel
Cores :
2
Application :
Engine Sensor Signaling
Insulation :
Inorganic Material
Function :
Detection
Property :
long servicing time
Cable Diameter :
0.5-8 mm
Description

High Temperature Outlet MI Sensor and Control Cable for Automotive, with the maximum continuous operation temperature of 900 ℃ and instant operation temperature of 950 ℃, is used to transmit various signals from the internal high temperature area to the external area detected by high temperature exhaust gas sensor of automobile internal combustion engine.

It is composed of a conductor, mineral insulation layer (normally Magnesium Oxide) and metal sheath. The maximum manufacturing length of a single cable can reach 400m. It can be supplied in sections according to real needs.

The structural materials are as follows

-----Conductor: nickel chromium alloy, inconel 600, pure nickel, 310S or 310H;

-----Insulation: high purity magnesia powder (MgO), alumina powder (Al2O3) or silica powder (SiO2);

-----Sheath: 304L, 321, 316L, 310S, 310h, Inconel 600 or 825 alloy.

8mm Mineral Insulated Metal Sheathed Cable Sensor Control

Technical data

Parameters Technical data
Conductor Cores 2
OD,mm 0.5
Insulation thickness,mm 0.3 - 1.0
Cable OD,mm 2.5 - 6.0
Sheath thickness,mm 0.3 - 0.6

Insulation resistance

 Room temp. ≥ 20 MΩ
300℃ ≥ 5 MΩ
600℃ ≥ 3 MΩ
900℃ ≥ 40 kΩ

Operation temp.

 Continuous ,℃ ≤ 900
Short ,℃ 950

Structure materials

(optional)

 Conductor Ni-Cr alloy,Inconel 600,pure nickle,310S,310H
Insulation High-pure MgO,Al2O3,SiO2
Sheath 304L,321,316L,310S,310H,Inconel 600,Alloy825
