AA5754 Aluminum Plate Sheet

Alloy 5754 Aluminum Plate Sheet Features

Alloy 5754 aluminum plate sheet has excellent corrosion resistance especially to seawater and industrially polluted atmospheres. It has higher strength than 5251. This high strength makes 5754 highly suited to marine applications requiring a combination of strength and resistance to corrosion in sea water. Alloy 5754 aluminum plate sheet is sold basic materials but with high ductility and elongation, also have very good corrosion resistance, very small tension of the basic materials. When making tooling, alloy 5754 aluminum plate sheet has consistent stability in the core of thick plates, have good welding properties as well.

APPLICATIONS

Alloy 5754 aluminum plate sheet is typically used in :

Tooling

Machines and machine parts

Pressure containers

Cans for beverages and grocery

· Tread plate

· Shipbuilding

· Vehicle bodies

· Marine applications

· Drilling rigs

· Transportation equipment

· Fishing industry equipment

Rivets

Food processin

Welded chemical and nuclear structuresg

TEMPER TYPES

The most common tempers for 5754 aluminium are shown below with H114 & H111 being the most common tread plate temper.

O - Soft

H111 - Some work hardening imparted by shaping processes but less than required for H11 temper

H22 - Work hardened by rolling then annealed to quarter hard

H24 - Work hardened by rolling then annealed to half hard

H26 - Work hardened by rolling then annealed to three-quarter hard

Alloy: 5754

Temper: O, H111, H112, H12,H14, H16, H18, H32, H34, H36, H38

Thickness: 0.2mm--200mm

Width: 500mm--2800mm

Length: 1000mm--12000mm

Surface: Mill finish, Bright finish, paper interleaved, one side film, both sides film.

Chemical Properties
