Aluminium finstock in mill finish ,AA8011/1100/3102.thickness 0.1-0.28mm
Aluminium finstock in mill finish ,AA8011/1100/3102.thickness 0.1-0.28mm
Aluminium finstock in mill finish ,AA8011/1100/3102.thickness 0.1-0.28mm
Aluminium finstock in mill finish ,AA8011/1100/3102.thickness 0.1-0.28mm
Aluminium finstock in mill finish ,AA8011/1100/3102.thickness 0.1-0.28mm
Aluminium finstock in mill finish ,AA8011/1100/3102.thickness 0.1-0.28mm
Aluminium finstock in mill finish ,AA8011/1100/3102.thickness 0.1-0.28mm
Aluminium finstock in mill finish ,AA8011/1100/3102.thickness 0.1-0.28mm
Aluminium finstock in mill finish ,AA8011/1100/3102.thickness 0.1-0.28mm
Aluminium finstock in mill finish ,AA8011/1100/3102.thickness 0.1-0.28mm
Specifications
Brand Name :
GBS
Model Number :
GBS-QSBB
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
5 mts
Payment Terms :
L/C, T/T, D/A, D/P
Supply Ability :
1200mts per month
Delivery Time :
25-35 works day
Packaging Details :
wooden box
surface :
mill finish
appliaction :
Air conditioners Car radiators Automobile heat exchangers
packing :
wooden box or wooden pallets
alloy :
AA8011/1100/3102
Thickness :
0.10--0.28mm
Width :
150-1900mm
Description

ALUMINIUM COILS FOR HYDROPHLIC FINSTOCK

Applications :
  • Air conditioners
  • Car radiators
  • Automobile heat exchangers
Specifications:

flat fin stock has proved its worth in air
conditioners, car radiators and heat exchangers. With the help of high-quality ingots, state-of-the-art gauge and shape control
and precision slitting, we manufacture fin stock that has tight gauge tolerances and excellent slit edges. A tight build-up combined
with internal sound metallurgical properties produce good drawability required for all types of finning;

Dimensions
Parameter Range Tolerance
Thickness (mmz0 0.10-0.28mm +/-0.005 up to 0.12
Partially annealed: 0.10 — 0.25 +/-0.01 for > 0.12
Width (mm) 150 — 1900 +/-0.5 for 100 — 250
+/-1 for > 250
Coil I.D (mm) With core: 70, 76, 150, 203, 300, 508 -
Coil O.D (mm) 300 — 1350
—550		 -
Core Plastic / M.S / AL -

Flatness
Less than 20 I units (typical)

Applicable standards
:: ASTM - B - 209M, Aluminium association — aluminium standards and data

Mechanical properties
Alloy (AA) Temper %E (min) UTS(mpa)
Min Max
1050 H19 1 130 -
H26 4 95 130
1100 O 20 70 110
H14 3 105 140
H16 2 125 150
H22 20 95 130
H24 8 110 145
H26 4 130 165
1200 O 20 70 100
H14 3 105 140
H16 2 125 150
H22 20 95 130
H24 8 110 145
H26 4 130 165
3003 O 20 95 130
H14 3 130 180
H18 2 185 -
8006 H25 8 120 145
O 25 100 130
8011 O 25 85 115

Chemical composition
Alloy (%) AA1050 AA1100 AA1200 AA3003 AA8006 AA8011
Fe 0.40 0.95 1.00 0.70 1.4 0 — 1.60 0.6 — 1.00
Si 0.25 (Fe + Si) (Fe + Si) 0.60 0.02 0.5 — 0.90
Mg 0.05 - - - 0.02 0.05
Mn 0.05 0.05 0.05 1.0 — 1.50 0.4 — 0.50 0.20
Cu 0.05 0.05 — 0.20 0.05 0.05 — 0.20 0.05 0.10
Zn 0.05 0.10 0.10 0.10 0.05 0.10
Ti 0.03 - 0.05 0.1(Ti+Zr) 0.03 0.08
Cr - - - - - 0.05
Each(Others) 0.03 0.05 0.05 0.05 0.05 0.05
Total (Others) - 0.15 0.125 0.15 0.15 0.15
Al 99.50 99.00 99.00 Remainder Remainder Remainder

Packing
GBS flat fin stock is packed on wooden skids in either eye-to-sky or eye-to-wall condition, wrapped in HDPE fabric and
hardboard and strapped with hoop iron. Moisture protection is ensured with silica gel packets and as the final step, the entire
packed product is placed in a wooden cage.
