AA3003 Heavy Gauge Thickness 0.03-0.13mm Width 200-1200mm .CONTAINER FOIL
AA3003 Heavy Gauge Thickness 0.03-0.13mm Width 200-1200mm .CONTAINER FOIL
AA3003 Heavy Gauge Thickness 0.03-0.13mm Width 200-1200mm .CONTAINER FOIL
AA3003 Heavy Gauge Thickness 0.03-0.13mm Width 200-1200mm .CONTAINER FOIL
AA3003 Heavy Gauge Thickness 0.03-0.13mm Width 200-1200mm .CONTAINER FOIL
AA3003 Heavy Gauge Thickness 0.03-0.13mm Width 200-1200mm .CONTAINER FOIL
AA3003 Heavy Gauge Thickness 0.03-0.13mm Width 200-1200mm .CONTAINER FOIL
AA3003 Heavy Gauge Thickness 0.03-0.13mm Width 200-1200mm .CONTAINER FOIL
Specifications
Brand Name :
GBS
Model Number :
GBS-RQB
Certification :
ISO
Place of Origin :
CHINA
MOQ :
5mts
Payment Terms :
L/C, D/P, T/T
Supply Ability :
600mts per month
Delivery Time :
4-7 weeks
Packaging Details :
wooden box
alloy :
non alloy
surface :
mill finish
gauge :
0.03-0.13mm
application :
for container foil and describes the quality attributes of the master foil rolls.
packing :
strong wooden suspended box
Material :
silver
Description

GBS CONTAINER FOIL SPECIFICATION

Product Description

PURPOSE

To establish definitive quality standards on foil rolls, thereby minimizing claims attributable to any lack of understanding between supplier and customer.

OBJECTIVE

This specification covers 3003 alloy foil master rolls for container foil and describes the quality attributes of the master foil rolls.

PHYSICAL REQUIREMENTS

ALLOY AND TEMPER

Alloy and temper should correspond to Table 1.

Table 1

Alloy Temper
3003 H24

SPECIFICATION AND TOLERANCE

The specification is as below Table 2.

Table 2

Gauge

mm

Gauge Tolerance

mm

Width

mm

Width Tolerance

mm

ID

mm

OD

mm

 Core Material
0.03~0.13 ±5% 200~ 1200 ±1

Æ 76.2

Æ 150

Æ 152

600max to ID 76.2

900max to ID 150 & 152

Aluminium

&

Steel

CHEMICAL COMPOSITION

The chemical composition should correspond to Table 3.

Table 3

Alloy Si Fe Cu Mn Zn Others Al
Single Total Up
3003 0.6 0.7 0.05～0.20 1.0～1.5 0.10 0.05 0.15 ＞99.35

MECHANICAL PROPERTIES

Mechanical properties should correspond to Table 4.

Table 4

Alloy Temper

Gauge

mm

Tensile Strength

Mpa

Elongation

%

Erichsen

mm
3003 H24 0.03～0.13 140-190 ≥6.0 ≥4.5

SURFACE CONDITION

The surface shall be cleaned and free from inclusions, scratches, wrinkles, cracks, overlapping or other internal defects.

Pin-holes

The pin-holes should correspond to Table 5.

Table 5

Gauge 0.030～0.050 0.050～0.13
Pinholes/m2 ≤30 0

Spice

The splices are as below Table 6.

Table 6

Gauge,mm Splices
≤0.06 ≤1
＞0.06 0

a) All splices to be ultrasonic/tape.

b) It is allowed one splice per roll. (Max. once per 2000m)

c) Marked at the roll edge with a film, placed close to the splice.

AA3003 Heavy Gauge Thickness 0.03-0.13mm Width 200-1200mm .CONTAINER FOIL AA3003 Heavy Gauge Thickness 0.03-0.13mm Width 200-1200mm .CONTAINER FOIL
