Specifications
Brand Name :
GBS
Model Number :
GBS-JYB
Certification :
ISO
Place of Origin :
CHINA
MOQ :
5mts
Payment Terms :
L/C, D/P, T/T
Supply Ability :
600mts per month
Delivery Time :
4-7 weeks
Packaging Details :
wooden box
alloy :
AA1235/8011
surface :
Bright or dull
gauge :
0.01-0.05mm
application :
hous hold
packing :
strong wooden suspended box
Description


GBS HOUSEHOLD FOIL SPECIFICATION


Product Description

1. PURPOSE


To establish definitive quality standards on foil rolls, thereby minimizing claims attributable to any lack of understanding between supplier and customer.

2. OBJECTIVE


This specification covers 8011 or 1235 alloy foil master rolls for household foil and describes the quality attributes of the master foil rolls. The roll can be cut into small rolls and be used to pack and freshen the household food.

3. PHYSICAL REQUIREMENTS

3.1 ALLOY AND TEMPER


Alloy and temper should correspond to Table 1.
Table 1

AlloyTemper
8011O
1235O

3.2 SPECIFICATION AND TOLERANCE


The specification is as below Table 2.
Table 2

Gauge mm

Gauge Tolerance

mm

Width mm

Width Tolerance

mm

ID

mm

OD

mm

0.010~0.050±5%40~ 1600±1Æ 76.2600max to ID 76.2
Æ 150900max to ID 150 & 152
Æ 152


3.3 CHEMICAL COMPOSITION


The chemical composition should correspond to Table 3.

Table 3

Alloy

Chemical Composition %

Si

Fe

Cu

Mn

Mg

Zn

Ti

Other

Al

Single

Total up

80110.58~0.660.63~0.850.050.030.030.100.02~0.040.050.15Remainder
12350.12~0.160.45~0.520.020.010.010.010.020.03 >99.35

3.4 MECHANICAL PROPERTIES


Mechanical properties should correspond to Table 4.


Table 4

Alloy-Temper

Gauge mm

Tensile Strength Mpa

Elongation %

8011/1235-O

0.010-0.02580-110≥1.5
0.025-0.0580-110≥2.5

3.5 SURFACE CONDITION


3.5.1 The surface shall be cleaned and free from inclusions, scratches, wrinkles, cracks, overlapping or other internal defects.

3.5.2 There will be no adhesion or tearing when the roll is unfolded, and the free uncoiling length should be 1.5m max.

3.5.3 One side is bright, the other side is dull. The bright surface is usually at the outer side of the roll, and the dull surface is at the inner side of the roll.
3.5.4 Pin-holes

The pin-holes should correspond to Table 5.


Table 5

Gauge0.010~0.012>0.012~0.015>0.015~0.020>0.020
Pinholes/m2(max)10050200
Note: When the customer has special requirement, it has to be negotiated with supplier and demander.




3.5.5 Spice
The splices are as below Table 6.
Table 6

Roll Diameter,mmSplices
≤400≤1
>400≤2


a) All splices to be ultrasonic/tape.
b) It is allowed one splice per roll. (Max. once per 2000m)
c) Marked at the roll edge with a film, placed close to the splice.

3.5.6 Wettability
The wettability corresponds to A grade quality.

4. PACKINGAND SHIPPING REQUIREMENTS


4.1 Quantities – As specified on the purchase order with a tolerance of +/- 10% unless otherwise stated on the order.

4.2 Packaging – Foil rolls are to be packed in collapsible aluminum racks or steel racks as specified in such a manner that normal handling by common carrier will ensure safe transportation without damage to the foil. This includes wrapping to protect the foil from water stain and corrosion.

4.3 Identification – Each roll shall be identified with the following:

a) Order number (release number)
b) Part number (from RMC Purchase Order)
c) Gauge (mm)
d) Width (mm)
e) Net weight (kg)


Aluminium Household Foil Gauge 0.010~0.050mm Waterproof
