Specifications
Brand Name :
GBS
Model Number :
GBS-QSBB
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
5mts
Payment Terms :
L/C, T/T, D/A, D/P
Supply Ability :
1200mts per month
Delivery Time :
25-35 works day
Packaging Details :
wooden box
surface :
light blue, dark blue, golden, special white
appliaction :
cooling exchanger,air conditionersREDIATORS
packing :
wooden box or wooden pallets
alloy :
AA8011/1100/3102
Thickness :
0.089--0.35mm
Width :
150-1650mm
Description

HYDROPHLIC ALUMINIUM FOILS FOR FINS OF RADIATORS,HEAT EXCHANGER

Product Description


Alloy 1100/8011
temper H18/H22
thickness 30-200micron
width 30-1300MM
surface treatment coating or embossed or both
coating water-based paint coating(epoxy,polyester,lacquer and so on with different colors)
embossed orange peel or other different patterns
ID 76/152MM aluminum or steel core
Roll weight about 400kgs
Application Polyurethane &Phenolic Insulation panels for roof and wall
PIR Insulation panel for air ductwork
PUR Insulation panel for air duct
Thermaboard insulation panel for ventilating duct
Polyurethane insulation panel for central air condition duct
PUR/PIR Foam Pre-insulated Duct Panelfor central air condition duct
sandwich panel for air conditioning duct

Coating types:

(1)Film with corrosive resistance inorganic resin

(2)Hydrophilic film: organic resin

Characteristic of hydrophilic aluminium foil

  • excellent hydrophilicity and corrosion resistance
  • good formability and no wear on the mold
  • a strong resistance to stamping oily, soluble, heat resistance
  • air flow resistance, heat exchange rate can generally increase 10% -15%.

Advantages comparing to Bare aluminium fin stock:

  • Can increase the anti-corrosion, anti-mold, no smell of the function;
  • The heat sink surface of the accumulation of condensate evenly distributed on the surface, not because of the formation of water droplets caused by heat accumulation between the block, affecting the heat exchange conditions, thereby improving the heat exchange rate of 5%;
  • Because the water no beads, the corresponding also reduced the noise caused by vibration;
  • To prevent air conditioning powder into the room to adversely affect the human body, in line with environmental requirements

Coating performance

SERIAL NO ITEMS TESTING METHODS RESULTS
1 superficies and appearance by eyes golden, blue, black
2 film thickness calculated from weight of film 2-3μm
3 original hydrophilicity test hydrophilicity directly ≥8mm
4 initial hydrophilicity dip in vaporing oil 3min (20±15℃) →vertical situation 7min at normal temperature → 210±10℃ dry 2mic → dip in pure water 10min → dry 10min/cycle at normal temperature, 10 circle → test hedrophilicity ≥6.0mm
5 salt-spray resistance JIS-Z-2371 (5%x35℃x72hours continuious slat spray ≥R.NO9.5
6 heat resistance A:200℃x10mins
B:400℃x10mins		 A:no changes B:turns light brown
7 oil resistance dip in press oil 24hours → wash in flowing water → peel test no delamenation
8 adhensive force A,bending 180°
B,peel test
C,erichsen value = 5mm		 100% no delamination
9 odor by nose after dipping in water, and drying naturally no odor
Corrosion Resistance Coloured Aluminium Foil , Industrial Aluminum Foil Rolls
Corrosion Resistance Coloured Aluminium Foil , Industrial Aluminum Foil Rolls
