Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
TB-150-2 / TB-250-2
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
15000-16000USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5sets per month
Delivery Time :
25-30 working days
Packaging Details :
Sea shipping Wooden case
Name :
Double head sleeve shrink labeling machine for both body labels or 1 body label 1 neck label
TB-150-2 Speed :
150-300bottles per minute
TB-250-2 Speed :
250-500bottles per minute
Lable type :
Sleeve label
Material of label :
PVC、 PET、 OPS
Sleeve applicator :
4000*850*2100mm
Steam generator :
12KW / 24KW
Sleeve shrink tunnel :
1500mm / 2000mm
Description
Description of PLC control Double head neck body sleeve applicator bottle labeling machine

Features of Double head sleeve shrink labeling machine for both body labels or 1 body label 1 neck label:
1, It can be fully connected to the production line for operation, or it can be operated on a stand-alone basis

2, Adopting double trays for feeding, which can save time for changing materials and ensure smooth production

3, Adjustable feeding high-speed electric eye, accurately lock the label

4, Double positioning center guide post, stable label delivery, can quickly realize the replacement of different products

5, Synchronous bottle divider design, bottle conveying is not easy to shake

6, The original adjustable cutter head makes the cutting mark smoother, which greatly reduces the imagination of defects and makes it easier to replace the blade

7, Conveyor belt, bottle-separating screw and bottle-belt can be adjusted synchronously to ensure stable and high speed label

8, Advanced control system, color touch screen design with auxiliary buttons, more in line with humanity

9, High-standard electrical configuration, the matching of the feeding cutter is seamless, and the label feeding is soft and smooth.

10, All use international well-known electrical brands, high stability and trustworthy

11, Using Swiss imported wind to preheat and shrink, position the label to be shrink in advance


Optional:

A Floor-standing material rack B Material storage rack C Rotating material rack D Dotted line device

Equipment list of Double head sleeve shrink labeling machine for both body labels or 1 body label 1 neck label:

Items Description Model Size(mm) Qty
Double head 150-300BPM sleeve labeling machine set
1.1 Sleeve applicator TB-150-2 4000*850*2100 1set
1.2 Sleeve shrink tunnel SB-1500 1500*700*2000 1set
1.3 Steam generator 18KW 760*570*1030 1set
1.4 Connection conveyor system / / 4m
1.5 Spare parts / / 1suit
Double head 250-500BPM sleeve labeling machine set
2.1 Sleeve applicator TB-250-2 4000*850*2100 1set
2.2 Sleeve shrink tunnel SB-2000 2000*700*2000 1set
2.3 Steam generator 24KW 730*550*1130 1set
2.4 Connection conveyor system / / 5m
2.5 Spare parts / / 1suit

Parameters of Double head sleeve shrink labeling machine for both body labels or 1 body label 1 neck label:

No. Item Technical data
1 Import Power 6.0KW
2 Import Voltage ∮3, 380/220 VAC
3 Capacity(production speed)

TB-150-2

300 bottles per min

(single label)

TB-250-2

500 bottles per min

(single label)
4 Dimension of Host Machine (mm) L4000 × W850 × H2200
5 Applicable Diameter Container (mm) φ28 mm ~ φ120 mm
6 Applicable Label Length (mm) 30~250 mm
7 Applicable Thickness Label (mm) 0.03~0.13 mm
8 Applicable Inner Diameter of Paper Tube 5''~10''

Configuration table of machine parts

1. Bottle separating mechanism 1set 7. Label carrier drive mechanism 2set
2. Bottle positioning mechanism 1set 8. Cutter mechanism 2set
3. Single material putting place 2set 9. Synchronous label brush-off mechanism 2set
4. Fiber-optical electric eye controlling 2set 10. Automatic platform elevating mechanism 2set
5. Center guide pin 2set

11. Man-machine interface of operation control panel

 1set
6. Shrink oven 1set 12. Hairbrush 2set

Set up of Double head sleeve shrink labeling machine for both body labels or 1 body label 1 neck label

Electrical apparatus Name Brand Model Qty
PLC Mitsubishi Japan FX3SA-30MT 1
Touch screen WEINVIEW-Taiwan TK6071IQ 1
Photo-electricity Sensor Autonice-Korea PR12-4DN 1
High-speed Optical Fiber Sensor SUNX Japan FX-301 1
Photo-electricity Sensor SUNX Japan CX-442 1
Electricity Sensor SUNX Japan PM-L44 1
Label In-feeding Servo Motor Panasonic MHMF082L1U2M 2
Label In-feeding Servo Drive Panasonic

TB-100

MBDLN25SG(400W)

 2

TB-250

MBDLN25SG(750W)

 2
Cutting Head Servo Motor Panasonic MHMF042L1U2M 2
Cutting Head Servo Drive Panasonic MBDLN25SG(400W) 1
Bottle Discharge Variable-frequency Drive SHIHLIN-Taiwan SC3-21-0.75K 1
Bottle Conveyor Variable-frequency Drive SHIHLIN-Taiwan SC3-21-0.75K 1
Label Feeder Variable-frequency Drive SHIHLIN-Taiwan SC3-21-0.75K 1
AC cont-actor Schneider French LC1-D0610M5C 4
Circuit-breaker Schneider French D10 3P 1
