Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
MT-50G
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
1900USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30sets per month
Delivery Time :
7-15 working days
Packaging Details :
Sea shipping Wooden case
Name :
Semi-auto wet glue labeling machine
Lable type :
Paper lable
Labeling speed :
15-25 bottles / min
Paper label size :
Length: 80mm-280mm; Width: 40mm-175mm
Size of machine :
630mm*430mm*330mm
Weight :
37kg
Labeling precision :
±1mm
Voltage :
Customizable
Description
Description of Semi-auto wet cold glue paper medicine PE bottle labeling machine

Basic use of Semi-auto wet glue labeling machine:
It is suitable for the paste labeling of various round bottles, paper separation, gluing, labeling, and labeling are automatically completed, reducing manual labeling procedures and improving labeling efficiency. Glue is evenly applied, with filamentous stripes, no wrinkles, and improves packaging quality. It is especially suitable for labeling production of small and medium batches, such as labeling of food and wine.
Features of Semi-auto wet glue labeling machine:
The operation is simple, and the simple operation of manually loading and unloading bottles can complete the entire labeling process.
The adjustment is simple, especially suitable for small batch production. It is simple and quick to switch varieties and label, which improves efficiency.
Save glue, the thickness of the glue can be adjusted according to needs, the glue is evenly spread, and glue waste is eliminated.
The labeling is accurate, the overlap of the label head and tail is high, and the label is positioned accurately on the bottle body.
The labeling quality is high, the silk stripes can be adjusted, the labeling is flat, no wrinkles, no warpage, and the packaging level is improved.
Scope of application of Semi-auto wet glue labeling machine:
Applicable label: paper label (paste required).
Applicable products: products that require paste labels to be affixed to the circumferential surface.
Application industry: widely used in food, medicine, wine and other industries.
Application examples: food can labeling, wine bottle paste labeling, glass bottle paste labeling, etc.
working principle of Semi-auto wet glue labeling machine:
＊Core working principle: The equipment gets the signal of placing the product in place, the equipment automatically separates a label, and the label is applied to the set position of the product after being glued. The label is applied and relabeled at the same time as the product is rotating, and the label is applied and covered On the product, the attaching action of a label is completed;
＊Operation process: put the product> paper separation + paper feeding + glue application + labeling + labeling (automatically realized by the equipment)> take out the labeled product.

Technological parameter:

Labeling precision: ±1mm Labeling speed: 15-25 b/min

Round bottle type: Dia: 30mm-120mm; Height:30mm-230mm Paper label type: Length: 80mm-280mm; Width: 40mm-175mm Overall dimension (L*W*H): 630mm*430mm*330mm

Power: 220V AC 60HZ

Weight: about 37kg

Configuration:

Main machine

 Item Description Qty. Material
1 Feeding mechanism 1 pc SUS, Aluminum alloy
2 Sizing mechanism 1 pc SUS, Aluminum alloy
3 Covering mechanism 1 pc SUS, Sponge tube
4 Base 1 pc Aluminum alloy

5

Screw down mechanism

1 pc

Aluminum alloy, POM

6

Paper inserting mechanism

1 pc

SUS
7 Leading mechanism 1 pc Aluminum alloy

8

Adjustment mechanism

1 pc

 Copper, SUS, Aluminum alloy
9 Cover frame 1 pc Painting metal plate
