Description of 300BPH L type with rinser filler capper 5 gallon water bottling machine

1. Automatic barrel loading device: The empty barrel is automatically sent into the barreled water filling machine through the action of the air cylinder.
2. Bottled water filling machine: it integrates disinfection, washing, filling and capping. Its working process is: two sprays of hot disinfectant, one drip, two sprays of normal temperature and low concentration disinfectant, One drip drying, two recycling water spray washing, one drip drying, two finished product water spray washing, and one drip drying. In this process, the outside of the barrel is also sprayed with a nozzle, and the nozzle is raised and deep into the inside of the empty barrel. , Disinfect and spray the inside of the barrel. The cleaned empty barrel is sent to the filling position through the automatic barrel lowering device, and the filling is carried out. During the process, the overflowing water will be returned to the pure water tank to avoid the waste of finished water. The filled barrel is hung and sealed by the conveyor chain in turn.
3. Light inspection equipment: artificially visually detect whether there are impurities in the bottled water, eliminate defective products, and provide consumers with healthy bottled aquatic products.
4. Steam shrink film machine: It generates high-temperature steam through electric heating, and uses high-temperature steam to shrink the barrel mouth film and attach it tightly to the barrel mouth surface.

The barreled water production line is suitable for producing large barrels of water with 3 gallons and 5 gallons (18.9L). At present, according to market demand, the output of barreled water equipment can reach 100 barrels/hour, 200 barrels/hour, 300 barrels/hour, 450 barrels/hour, 600 barrels/hour, 900 barrels/hour, 1200 barrels /Hour~2000 barrels/hour. (Including the whole line price and processing process)

Equipment list of Lype 300BPH 5 gallon bottle water filling line:

The package information for the whole line:
