80BPH Semi Automatic SUS304 18.9L / 5 Gallon Water Bottling Machine
80BPH Semi Automatic SUS304 18.9L / 5 Gallon Water Bottling Machine
80BPH Semi Automatic SUS304 18.9L / 5 Gallon Water Bottling Machine
80BPH Semi Automatic SUS304 18.9L / 5 Gallon Water Bottling Machine
80BPH Semi Automatic SUS304 18.9L / 5 Gallon Water Bottling Machine
80BPH Semi Automatic SUS304 18.9L / 5 Gallon Water Bottling Machine
80BPH Semi Automatic SUS304 18.9L / 5 Gallon Water Bottling Machine
80BPH Semi Automatic SUS304 18.9L / 5 Gallon Water Bottling Machine
Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
QGF-80
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
1300-3000USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10sets per month
Delivery Time :
20-25 working days
Packaging Details :
Sea shipping Wooden case
Application :
5 gallon Bottle water filling
Capavity :
80 bottles per hour(for 18.9L bottle)
Automation level :
Semi-Automatic
Material :
SUS304
Filling head qty :
1
Filling Precision :
99.9%
Power :
0.74KW
Dimensions :
1600 × 510 × 1500 (mm)
Description

Description of 80BPH semi automatic SUS304 18.9L / 5 gallon water bottling machine

Application of 80BPH 5 gallon bottle water filling machine:
CGF-80 semi-automatic gallon bottle washer filler capper is a filling equipment for pure water plant or mineral water plant dedicated irrigation 3 gallons , 5 gallons bucket.

Operating procedures of 80BPH 5 gallon bottle water filling machine:

First put the empty barrel perpendicular to the position of pulling out the lid, step on the cylinder switch with your foot, and the lid will fall from the unloading port, then open the cover, put the empty barrel perpendicular to the frame, close the lid, the machine will work automatically, passing the inside and outside Brush, spray inside and outside to realize the cleaning action. The cleaning liquid has a water tank and is recycled through a water pump.

Technical parameters of of 80BPH 5 gallon bottle water filling machine
1)filling head qty: 1
2)capacity: 80-100 B/H
3)bottle type: 18.9L (5 gallon/ 3 gallon with same neck)
4)voltage: AC380V / 50HZ
5) Dimensions: 1600 × 510 × 1500 (mm)
6) Power:0.74KW

The structural characteristics
This machine is divided into: washing, filling, capping and electrical parts.
1.the barrel rinsing part: 1)bottle holder; 2) washing bucket pump;
2.the filling parts: 1) filling pump; 2) filling valve; 3) capping device.
3. the electrical part By the time relay.

Equipment list of 80BPH 5 gallon bottle water filling line:

Items Description Model Size-mm Qty.
1.1 Semi-auto de-capper and brush washer with full SUS304 BS-1 900*900*1250 1set
1.2 Semi-automatic gallon bottle washer filler capper QGF-1 1600*510*1500 1set
1.3 Light checker CL-1 / 1pcs
1.4 Roller conveyor 2 meter / 2m
1.5 Label shrink tunnel / 600*600*1000 1set
1.6 Solid Ink Roll Coding Machine FP-380F 440*345*300 1set
