Description of 1500BPH drinking water 0-2L PET auto bottle filling machine

This filling machine is composed of three parts, a 12-head bottle washing machine, a 12-head filling machine, and a single-head capping machine. The three parts are connected by conveyer. The output is 1500-2000BPH, suitable for 0-5L bottles. We can configure water treatment, labeling machine, coding machine, and film shrink packing machine to form a complete water production line.

Parameters of Washer:

Rising heads: 12 pcs

Capacity: 0-3000BPH (each bottle rinsing time 4s)

Power: 0.92KW

Dimension: 1050*950*1700mm

Weight: 700KG

Applicable bottle: D∮50-100mm,H 50-350mm

Principle of filler:
This filler is developed on the basis of digesting and absorbing advanced technology introducing from abroad and is with international advanced level. It is mainly used for filling non carbonated drink. It is advanced in construction , steadily in performance, safe in operation , easy in maintenance high in production efficiency, and the speed can be regulated infinitively. The filler is the ideal choice for drink factories of small and middle size.

The bottles will be taken into filler by conveyor, the dia plate will turn each bottle to be caught by holding clap, with driven energy of motor, the holding claps will go up and down as main axis, when clap hold bottle, it will go up to press bottle mouth closely to filling head, at the meantime, filling value open and start to fill, when the bottle mouth leave the filling head, filling stop.

The whole machine is made of SUS304. The filling head is spring type without dead angel, no dripping. Easy for clean and maintenance. The holding clap model is suitable for all bottles with same bottle neck, it is easy for change bottle shape and volumes.

Parameters of filler:

Filling heads: 12 pcs

Power: 1.1KW

Dimension: 1100*1050*1850mm

Weight: 800KG

Parameters of capper:

Capping head: 1 pc

Power: 1.1KW

Dimension: 1000*850*2000mm

Weight: 600KG
