Description of 1500BPH 12-12-4 5L bottle washing capping water auto bottle filling machine

5L 12-12-4b automatic three in one filling machine for large bottle water:
This machine is a large bottle water filling machine integrating bottle washing, filling and sealing. Suitable for 3-10l large bottle water filling machine, three in one, shorten the material contact time with the outside world. The bottle punching clamp, filling valve and gland head are specially customized. The design of this equipment is reasonable, stable and safe. PLC automatic control system and touch screen operation are adopted in the whole process. It has the characteristics of no bottle filling and no bottle capping.

1. The filling volume regulation system is composed of variable frequency motor, PLC, touch screen, solenoid valve, material cylinder, actuator, etc. through control setting, the filling volume regulation is convenient, simple operation and accurate measurement.
2. The container positioning system is completed by air cylinder. Customers can adjust the container according to different specifications and shapes. The method is simple and accurate.
3. The anti dripping system is controlled by air cylinder, which not only blocks the filling nozzle, but also adopts the recovery device of leakage tank, which further overcomes the dripping phenomenon.
4. Some filling materials are easy to bubble when filling. We design the filling nozzle to be external blocking type, which can solve the bubble problem. At the same time, we use the "PLC" program to control the whole filling head to rise while filling, so that the filling measurement is more accurate.

We can also provide supporting equipment: bottle blowing machine, water treatment, automatic labeling machine, automatic labeling machine, automatic film wrapping machine, automatic carton packing machine.

Parameters of 3 in 1 big bottle Filling Machine:
