120BPH 5 Gallon 10L 20L Barrel Bottle Single Cavity Blow Molding Machine
120BPH 5 Gallon 10L 20L Barrel Bottle Single Cavity Blow Molding Machine
120BPH 5 Gallon 10L 20L Barrel Bottle Single Cavity Blow Molding Machine
120BPH 5 Gallon 10L 20L Barrel Bottle Single Cavity Blow Molding Machine
120BPH 5 Gallon 10L 20L Barrel Bottle Single Cavity Blow Molding Machine
120BPH 5 Gallon 10L 20L Barrel Bottle Single Cavity Blow Molding Machine
120BPH 5 Gallon 10L 20L Barrel Bottle Single Cavity Blow Molding Machine
120BPH 5 Gallon 10L 20L Barrel Bottle Single Cavity Blow Molding Machine
Specifications
Brand Name :
BOTTLING MACHINERY
Model Number :
BL-120
Certification :
CE/ISO9001-2008
Place of Origin :
Zhangjiagang city Jiangsu provice China
MOQ :
1
Price :
11000-12000USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10sets per month
Delivery Time :
20-25 working days
Packaging Details :
Sea shipping Wooden case
Name :
1 cavity semi-auto blow molding system for 3-5 gallon bottle
Capavity :
120 bottles per hour(for 5 gallon bottle)
Cavity :
1 cavity
Finished bottle :
3 - 5 gallon bottle
Structure :
1 Inner preform heater +1 Outer Preform heater+ 1 blower
Inner preform heater :
15Kw
Outer Preform heater :
12Kw
Weight :
1880KG
Description
Description of 120BPH 5 gallon 10L 20L barrel bottle single cavity blow molding machine


BL-120 blow molding machine is especially used to produce 3 gallon and 5 gallon bottles and is widely used to produce any shape of plastic from PET with neck finishes from 30mm-120mm.

The five gallon blow molding machine is divided into two major control systems (customers can choose freely), one is controlled by a time relay, and the other is controlled by a PLC touch screen computer, which can control technical parameters more accurately, and the machine is easy to operate , Safe, and adopts double emergency stop control in different positions
Machine features of 120BPH 1 cavity semi-auto blow molding system for 3-5 gallon bottle:
1. Especially used to make PET bottles with a capacity of not more than 6 gallons
2. Suitable for the production of 25-liter jars with a 200 mm inner diameter bottleneck
3. Infrared heating is used to achieve the uniform heating effect of the preform bottle wall.
4. A special reheating device is used to ensure the ideal heating effect for thick-walled preforms of 850 grams.
5. The specially designed cooling system in the drying tunnel ensures that the heating furnace provides a continuous and uninterrupted heat source, so that the preform can be heated completely.
6. The cooling system guarantees the quality of the neck of the preform.
7. Using one mold, the output of 5 gallon bottles can reach 90 blowing bottles per hour
Auxiliary machine of 120BPH 1 cavity semi-auto blow molding system for 3-5 gallon bottle:
The piston in an ordinary air compressor is of poor quality and is easily damaged, and the piston has a short service life, which leads to insufficient pumping capacity of the air compressor, which leads to more defective bottles. The air compressor we provide to our customers is special for bottle blowing, and the piston is wear-resistant and durable. Yongchang promises to customers that the air compressor will be damaged for objective reasons within one year, and we will return it for you free of charge.
The air filter mainly filters the water, impurities, oily residue, etc. in the air and high-pressure gas. The treated gas enters the bottle to ensure that the bottle has no peculiar smell and gloss. The filter we provide to our customers is mainly composed of a filter element and a filter screen, which makes the oil and water separated cleanly. After primary and secondary treatment, the quality of the bottle is ensured.
Regarding the air storage tank, its material is iron. After a long time of use, it is easy to rust due to the influence of water vapor, which seriously causes the gas storage tank and brings huge safety hazards to the workshop. The thickness of the gas tank we configure for you is 3 times that of ordinary, stable use and long life.
The function of the air dryer is to process high-pressure gas and moisture in the air to quickly dry the bottle wall and improve production efficiency. Our cold dryer is equipped with precision filter processing, so that the blown out bottle is bright and the cooling speed is fast.


Equiment list of 120BPH 1 cavity semi-auto blow molding system for 3-5 gallon bottle:

Items Name of machine Model Size(mm) Qty.
1,1 cavity semi-auto blow molding system for 3-5gallon
1.1 1cavity blow molding machine


BL-120

 2350*750*1900 1set
1.2 Outer Preform heater 12Kw 2670*680*1650 1set
1.3 Inner preform heater 15Kw 400*350*1200 1set
1.4 HP Air Compressor with air tank 1.2m3/min 30Kg 1880*850*1050 1set
1.5 Air Filters 2.0m3/min 30Kg 750*350*350 2sets
1.6 Blow mould 5gallon 1cavity 1set
OPTION
1.7 Mould water chiller 3HP 850*560*1040 1set
1.8 Air dryer 2.0m3/min 30Kg 1050*650*1100 1set

Parameter of 120BPH 1 cavity semi-auto blow molding system for 3-5 gallon bottle:
Model BL-120



Container

 Product material PET
Volume 10L-20L(3-5Gallon)
Output 150PCS/H
Max bottle length 430mm
Max bottle diameter 300mm


Moulding

 Stretching stroke 450mm
Clamping force 6000kg
Mould opening stroke 360mm


Machine size and weight

 Main machine (L x W x H) 2350*750*1900mm
Main machine weight 1500Kg
Heater (L x W x H) 2670*680*1650mm
Heater weight 380Kg
Power 40kw
